DG-SC7369-18
2MP 18x SPEED DOME IP CAMERA
User Manual
V1.0
2017-11-16
As our products undergo continuous development the specifications are subject to change without prior notice
DG-SC7369-18 User Manual
2
COPYRIGHT
Copyright 2017 by Digisol Systems Ltd. All rights reserved.Company has an ongoing policy of
upgrading its products and it may be possible that information in this document is not up-to-date.
Please check with your local distributors for latest information. No part of this document can be
copied or reproduced in any form without written consent from the company.
Trademark
DIGISOLTM is a trademark of Digisol Systems Ltd. All other trademarks are the property of the
respective manufacturers.
DG-SC7369-18 User Manual
3
INDEX
1. Product Introduction...............................................................................................................................................5
1-1 Introduction and safety information............................................................................................................... 5
1-2 Safety Information.......................................................................................................................................... 6
1-3 System Requirements......................................................................................................................................6
1-4 Package Contents............................................................................................................................................ 6
2 Using Network IP Camera by Web Interface......................................................................................................7
2-1 Locate the IP address of Network IP Camera.................................................................................................7
2-2 Connect to IP camera’s Web User Interface................................................................................................... 7
Speed Dome IPC Menu.......................................................................................................................................13
2-3 Log...............................................................................................................................................................14
2-4 Config............................................................................................................................................................14
2-4a Base Config.........................................................................................................................................14
2-4a-1 System..............................................................................................................................................14
2-4a-2 Network............................................................................................................................................... 16
2-4a-3 AV.........................................................................................................................................................17
2-4a-4 Image....................................................................................................................................................18
2-4a-5 Safe...................................................................................................................................................... 20
2-4b Advance Config...................................................................................................................................... 20
2-4b-1 Network............................................................................................................................................... 20
2-4b-2 Event...................................................................................................................................................21
2-4b-3 Store....................................................................................................................................................21
2-4b-4 PTZ.....................................................................................................................................................22
2-4b-5 Status..................................................................................................................................................23
3 PTZ Commands to control via NVR...................................................................................................................24
4. Using CMS software............................................................................................................................................ 25
4-1 Installing CMS Software.............................................................................................................................. 25
4-2 Getting familiar with CMS Software............................................................................................................28
4-3 CMS Configuration.......................................................................................................................................31
4-3-1 CMS Operation Main Menu..............................................................................................................31
4-3-2 Device display area............................................................................................................................31
4-3-3 Operation area................................................................................................................................... 31
4-3-4 Time................................................................................................................................................... 31
4-3-5 Video disk status area........................................................................................................................ 32
4-3-6 PTZ.................................................................................................................................................... 32
4-3-7 Operation log..................................................................................................................................... 32
4-3-8 Menu Area......................................................................................................................................... 32
4-3-8-1 PTZ control........................................................................................................................................ 34
4-3-8-2 Color Setting...................................................................................................................................... 35
DG-SC7369-18 User Manual
4
4-3-8-3 System................................................................................................................................................ 35
4-3-8-3 a) Device Manager............................................................................................................................. 35
4-3-8-3 b) Local Config.................................................................................................................................. 39
4-3-8-3 c) Remote Config............................................................................................................................... 41
4-3-8-3 d) Account.......................................................................................................................................... 41
4-3-8-3 e) Local Log....................................................................................................................................... 43
4-3-9 Playback.............................................................................................................................................43
4-3-10 Advance........................................................................................................................................... 44
4-3-11 Logout..............................................................................................................................................44
5Appendix..................................................................................................................................................................45
5-1 Specifications................................................................................................................................................45
5-2 Troubleshooting............................................................................................................................................ 46
5-3 Glossary........................................................................................................................................................ 47
DG-SC7369-18 User Manual
5
1. Product Introduction
1-1 Introduction and safety information
Thank you for purchasing DIGISOL IP cameras!!
DIGISOL Speed Dome PTZ IP Camera HD Resolution with IR LED and IR-cut Filter. This camera offers
the latest compression technology with a CMOS sensor & a real time image processing hardware. With its
high performance H.264 compression, users can stream high quality video at low bandwidth and storage
capacity requirements.
It has IR LED for visibility under no light condition. The IR cut filter offers a true image quality during
day/night operations.
This IP camera supports Digital WDR, a software-based technique that enables the camera to produce clearer
images in less than ideal lighting conditions. Digital-WDR balances the contrast of light and shadow to
improve visibility in dark areas within a scene.
Other features of this network IP Camera includes:
2MP 1/2.8" sensor
Supports 1080P Resolution
Supports H.264 Compression
8 LED lamps Up to 120m
Day/ Night Mode (Auto ICR)
Support DWDR
18x Optical Zoom
IP66 Compliant
DG-SC7369-18 User Manual
6
1-2 Safety Information
In order to keep the safety of users and your properties, please follow the safety instructions as
mentioned below. The warranty will become void if you disobey these safety instructions.
This Network IP Camera is sophisticated electronic device; DO NOT drop it from a height.
DO NOT place this IP Camera at hot / humid places, and avoid direct sunlight.
Accessories of this IP Camera like power supply are dangerous to small children. KEEP THIS
IP CAMERA OUT OF REACH OF CHILDREN.
If you want to use this IP Camera at any place that may be spilled by water or dirt, a secure and
water-proof camera housing is required.
DO NOT pull any cord that is connected to this IP Camera by force.
The IP Camera will get heated up when used for a long time. (This is normal and is not a
malfunction). DO NOT put this IP camera on paper, cloth, or other flammable materials.
If the IP Camera falls into water when powered, DO NOT attempt to retrieve it back yourself!
Find a qualified electrical technician for help.
1-3 System Requirements
Windows XP, Vista or Win 7 operating system (both 32 or 64 bits version)
2GB of system memory
1GB of Display card memory
20GB of available hard disk space on system drive
1-4 Package Contents
Before you start using this IP camera, please check if there’s anything missing in the package, and
contact your dealer of purchase to claim for missing items:
DG-SC7369-18 Speed Dome Camera
Quick Installation Guide
Installation Guide CD (includes user manual, QIG & CMS software)
Power Adapter 12V 4A
Mounting Accessories
DG-SC7369-18 User Manual
7
2 Using Network IP Camera by Web Interface
2-1 Locate the IP address of Network IP Camera
You must know the IP address of IP Camera before you can connect to it.
By default the IP camera is on Static IP & default IP address is 192.168.1.160. Connect the camera
to router or a switch & set it on DHCP.
2-2 Connect to IP camera’s Web User Interface
When you know the IP address of IP camera, you can connect to it by Internet Explorer web
browser by entering its IP address in the address bar. The user login screen will appear when you get
connected:
IP Camera’s administrator username and password are admin & 12345 by default. Click ‘OK’
button or press ‘ENTER’ key on your keyboard when you finish entering username and password.
Note:
If you have several network connections, such as "Wireless Function”, disable the
"Wireless functions" or other network connections that are not connected to the IP camera, as
utility may fail to search IP camera.
DG-SC7369-18 User Manual
8
Click OK to display the camera video.
There are various controls on the web page; here is the description of every control item:
Icon
Illustration
To control horizontal/ vertical movement of the
camera & open/close automatic scan
zoom
focus
iris
PTZ Speed Adjustment
Open/ Close Lamp light
Wipers (optional)
Close/open video
Main/Sub code stream
3D function switch
Sound Monitor (Optional)
DG-SC7369-18 User Manual
9
Full screen
Preview Tab:
To close/open video, by default it is opened.
To modify Mainstream/ Substream, by default default is Mainstream.
For camera with audio function, by default is mute.
3D function switch, by default is disabled.
Switch to Full screen, by default is disabled.
PTZ button
Up; Down; Left; Right;
Left top; Right top; Left down; Right down;
Automatic scan; Zoom in and zoom out ; Focus; ;Aperture;
Pan&tilt speed;
IR light; Wipers(optional)
DG-SC7369-18 User Manual
10
Preset setup
a) Setting Presets
To configure preset, turn the PTZ cam to desired position and click to setup, click to call,
click to delete
b) Setting Cruise
You can configure 8 cruise on this IPC & each cruise supports 16 presets each.
Click
Click to add the desired preset, set the cruise time/ speed & click OK.
After adding desired preset, click to save the cruise, as shown below
