HIGHSECURITYANDACCESS CONTROLSYSTEM(DGP-NE96)

PROGRAMMINGGUIDE

Software Version V1.0

DEFAULT INSTALLER CODE

000000(To modify the installer code, refer to section [1000], “Installer Code Programming” on page21)

DEFAULT SYSTEM MASTER CODE

1234 or 123456

HOW DO I ENTER PROGRAMMING MODE?

STEP 1: Press and hold the [0] key

STEP 2: Enter your [INSTALLERCODE]

STEP 3: Enter 4-digit [SECTION]

STEP 4: Enter required [DATA]

DECIMAL AND HEXADECIMAL PROGRAMMING TABLE

Key Value or Action Key Value or Action

[0] to [9] 0 to 9 (Hexa & Decimal) [BYP]E (Hexa Only)

[STAY]A (Hexa Only) [MEM]F (Hexa Only)

[FORCE]B (Hexa Only) [CLEAR]Exit section without saving (Hexa & Decimal)

[ARM]C (Hexa Only) [ENTER]Save current data and advance to next section (Hexa Only)

[DISARM]D (Hexa Only)

DGP-NE96

DigiplexNE DGP-NE96 - 2 - Programming Guide

Table of Contents

Serial Number List................................................................................................................................... 3

Zone Programming.................................................................................................................................6

Zone Report Codes ................................................................................................................................ 9

Zone Labels.......................................................................................................................................... 10

Keyswitch Programming....................................................................................................................... 12

Programmable Outputs......................................................................................................................... 14

User Code Options............................................................................................................................... 21

Arming and Disarming Report Codes................................................................................................... 22

Access Control Sections....................................................................................................................... 23

Keypad Numbering............................................................................................................................... 27

Control Panel Settings.......................................................................................................................... 27

System Options .................................................................................................................................... 27

Dialer Options....................................................................................................................................... 28

Other Options ....................................................................................................................................... 29

Communication Settings....................................................................................................................... 30

System Event Call Direction................................................................................................................. 31

Partition Settings................................................................................................................................... 32

Special and Trouble Report Codes....................................................................................................... 37

Other Settings and Modes.................................................................................................................... 38

Control Panel Hardware Connections .................................................................................................. 43

Trouble Display..................................................................................................................................... 48

DigiplexNE DGP-NE96 - 3 - Programming Guide

Serial Number List

All modules connected to the control panel’s communication network have an 8-digit serial number. Remove the extra serial number sticker from each

module’s PC board and affix in the appropriate spaces provided below (maximum 127 modules).

Module Type & Details Serial # Module Type & Details Serial #

1:______________________________________ _________________ 23:_____________________________________ _________________

2:______________________________________ _________________ 24:_____________________________________ _________________

3:______________________________________ _________________ 25:_____________________________________ _________________

4:______________________________________ _________________ 26:_____________________________________ _________________

5:______________________________________ _________________ 27:_____________________________________ _________________

6:______________________________________ _________________ 28:_____________________________________ _________________

7:______________________________________ _________________ 29:_____________________________________ _________________

8:______________________________________ _________________ 30:_____________________________________ _________________

9:______________________________________ _________________ 31:_____________________________________ _________________

10:_____________________________________ _________________ 32:_____________________________________ _________________

11:_____________________________________ _________________ 33:_____________________________________ _________________

12:_____________________________________ _________________ 34:_____________________________________ _________________

13:_____________________________________ _________________ 35:_____________________________________ _________________

14:_____________________________________ _________________ 36:_____________________________________ _________________

15:_____________________________________ _________________ 37:_____________________________________ _________________

16:_____________________________________ _________________ 38:_____________________________________ _________________

17:_____________________________________ _________________ 39:_____________________________________ _________________

18:_____________________________________ _________________ 40:_____________________________________ _________________

19:_____________________________________ _________________ 41:_____________________________________ _________________

20:_____________________________________ _________________ 42:_____________________________________ _________________

21:_____________________________________ _________________ 43:_____________________________________ _________________

22:_____________________________________ _________________ 44:_____________________________________ _________________

DigiplexNE DGP-NE96 - 4 - Programming Guide

45:_____________________________________ _________________ 69:_____________________________________ _________________

46:_____________________________________ _________________ 70:_____________________________________ _________________

47:_____________________________________ _________________ 71:_____________________________________ _________________

48:_____________________________________ _________________ 72:_____________________________________ _________________

49:_____________________________________ _________________ 73:_____________________________________ _________________

50:_____________________________________ _________________ 74:_____________________________________ _________________

51:_____________________________________ _________________ 75:_____________________________________ _________________

52:_____________________________________ _________________ 76:_____________________________________ _________________

53:_____________________________________ _________________ 77:_____________________________________ _________________

54:_____________________________________ _________________ 78:_____________________________________ _________________

55:_____________________________________ _________________ 79:_____________________________________ _________________

56:_____________________________________ _________________ 80:____________________________________ _________________

57:_____________________________________ _________________ 81:____________________________________ _________________

58:_____________________________________ _________________ 82:____________________________________ _________________

59:_____________________________________ _________________ 83:____________________________________ _________________

60:_____________________________________ _________________ 84:____________________________________ _________________

61:_____________________________________ _________________ 85:____________________________________ _________________

62:_____________________________________ _________________ 86:____________________________________ _________________

63:_____________________________________ _________________ 87:____________________________________ _________________

64:_____________________________________ _________________ 88:____________________________________ _________________

65:_____________________________________ _________________ 89:____________________________________ _________________

66:_____________________________________ _________________ 90:____________________________________ _________________

67:_____________________________________ _________________ 91:____________________________________ _________________

68:_____________________________________ _________________ 92:____________________________________ _________________

Module Type & Details Serial # Module Type & Details Serial #

DigiplexNE DGP-NE96 - 5 - Programming Guide

93:_____________________________________ _________________ 111:_____________________________________ _________________

94:_____________________________________ _________________ 112:_____________________________________ _________________

95:_____________________________________ _________________ 113:____________________________________ _________________

96:_____________________________________ _________________ 114:____________________________________ _________________

97:_____________________________________ _________________ 115:____________________________________ _________________

98:_____________________________________ _________________ 116:____________________________________ _________________

99:_____________________________________ _________________ 117:____________________________________ _________________

100:_____________________________________ _________________ 118:____________________________________ _________________

101:_____________________________________ _________________ 119:____________________________________ _________________

102:_____________________________________ _________________ 120:____________________________________ _________________

103:_____________________________________ _________________ 121:____________________________________ _________________

104:_____________________________________ _________________ 122:____________________________________ _________________

105:_____________________________________ _________________ 123:____________________________________ _________________

106:_____________________________________ _________________ 124:____________________________________ _________________

107:_____________________________________ _________________ 125:____________________________________ _________________

108:_____________________________________ _________________ 126:____________________________________ _________________

109:_____________________________________ _________________ 127:____________________________________ _________________

110:_____________________________________ _________________

Module Type & Details Serial # Module Type & Details Serial #

DigiplexNEDGP-NE96 -6-Programming Guide

Zone Programming

Zone Description Module Section 8-digit Serial Number Input# Section Define Assign Zone Options

1________________________ _______________ [0001] ___/___/___/___/___/___/___/___ ___/___/___ [0101] ___ ___ 1 2 3 4 5 6 7 8

2________________________ _______________ [0002] ___/___/___/___/___/___/___/___ ___/___/___ [0102] ___ ___ 1 2 3 4 5 6 7 8

3________________________ _______________ [0003] ___/___/___/___/___/___/___/___ ___/___/___ [0103] ___ ___ 1 2 3 4 5 6 7 8

4________________________ _______________ [0004] ___/___/___/___/___/___/___/___ ___/___/___ [0104] ___ ___ 1 2 3 4 5 6 7 8

5________________________ _______________ [0005] ___/___/___/___/___/___/___/___ ___/___/___ [0105] ___ ___ 1 2 3 4 5 6 7 8

6________________________ _______________ [0006] ___/___/___/___/___/___/___/___ ___/___/___ [0106] ___ ___ 1 2 3 4 5 6 7 8

7________________________ _______________ [0007] ___/___/___/___/___/___/___/___ ___/___/___ [0107] ___ ___ 1 2 3 4 5 6 7 8

8________________________ _______________ [0008] ___/___/___/___/___/___/___/___ ___/___/___ [0108] ___ ___ 1 2 3 4 5 6 7 8

9________________________ _______________ [0009] ___/___/___/___/___/___/___/___ ___/___/___ [0109] ___ ___ 1 2 3 4 5 6 7 8

10 ________________________ _______________ [0010] ___/___/___/___/___/___/___/___ ___/___/___ [0110] ___ ___ 1 2 3 4 5 6 7 8

11 ________________________ _______________ [0011] ___/___/___/___/___/___/___/___ ___/___/___ [0111] ___ ___ 1 2 3 4 5 6 7 8

12 ________________________ _______________ [0012] ___/___/___/___/___/___/___/___ ___/___/___ [0112] ___ ___ 1 2 3 4 5 6 7 8

13 ________________________ _______________ [0013] ___/___/___/___/___/___/___/___ ___/___/___ [0113] ___ ___ 1 2 3 4 5 6 7 8

14 ________________________ _______________ [0014] ___/___/___/___/___/___/___/___ ___/___/___ [0114] ___ ___ 1 2 3 4 5 6 7 8

15 ________________________ _______________ [0015] ___/___/___/___/___/___/___/___ ___/___/___ [0115] ___ ___ 1 2 3 4 5 6 7 8

16 ________________________ _______________ [0016] ___/___/___/___/___/___/___/___ ___/___/___ [0116] ___ ___ 1 2 3 4 5 6 7 8

17 ________________________ _______________ [0017] ___/___/___/___/___/___/___/___ ___/___/___ [0117] ___ ___ 1 2 3 4 5 6 7 8

18 ________________________ _______________ [0018] ___/___/___/___/___/___/___/___ ___/___/___ [0118] ___ ___ 1 2 3 4 5 6 7 8

19 ________________________ _______________ [0019] ___/___/___/___/___/___/___/___ ___/___/___ [0119] ___ ___ 1 2 3 4 5 6 7 8

20 ________________________ _______________ [0020] ___/___/___/___/___/___/___/___ ___/___/___ [0120] ___ ___ 1 2 3 4 5 6 7 8

21 ________________________ _______________ [0021] ___/___/___/___/___/___/___/___ ___/___/___ [0121] ___ ___ 1 2 3 4 5 6 7 8

22 ________________________ _______________ [0022] ___/___/___/___/___/___/___/___ ___/___/___ [0122] ___ ___ 1 2 3 4 5 6 7 8

Input 2

Hardwired

Device B

Digiplex NE

Control Panel

SN#:

020000A2

APR3-ZX8 Module

SN#: 34000041 Input 5

Addressable

Detector A

SN#: 21000033

OMMUNICATION

ETWORK

Input Terminals

1 2 3 4 5 6 7 8

Input Terminals

1 2 3 4 5 6 7 8

Bus Detector A:

Hardwired Device A:

Hardwired Device B:

Hardwired Device C:

Zone#

1 =

2 =

3 =

4 =

Section#

[0001]

[0002]

[0003]

[0004]

Serial#

21000033

1B000252

020000A2

34000041

Input#

N/A

002

005

DGP2-641

LCD Keypad

SN#: 1B0000252 Keypad Zone

Hardwired

Device C

Hardwired

Device A

When option [1] in section [3030] is enabled for

PGM1 to act as a zone input for two-wire smoke

detectors, the control panel will recognize PGM1 as

input number 255.

DigiplexNEDGP-NE96 -7-Programming Guide

23 ________________________ _______________ [0023] ___/___/___/___/___/___/___/___ ___/___/___ [0123] ___ ___ 1 2 3 4 5 6 7 8

24 ________________________ _______________ [0024] ___/___/___/___/___/___/___/___ ___/___/___ [0124] ___ ___ 1 2 3 4 5 6 7 8

25 ________________________ _______________ [0025] ___/___/___/___/___/___/___/___ ___/___/___ [0125] ___ ___ 1 2 3 4 5 6 7 8

26 ________________________ _______________ [0026] ___/___/___/___/___/___/___/___ ___/___/___ [0126] ___ ___ 1 2 3 4 5 6 7 8

27 ________________________ _______________ [0027] ___/___/___/___/___/___/___/___ ___/___/___ [0127] ___ ___ 1 2 3 4 5 6 7 8

28 ________________________ _______________ [0028] ___/___/___/___/___/___/___/___ ___/___/___ [0128] ___ ___ 1 2 3 4 5 6 7 8

29 ________________________ _______________ [0029] ___/___/___/___/___/___/___/___ ___/___/___ [0129] ___ ___ 1 2 3 4 5 6 7 8

30 ________________________ _______________ [0030] ___/___/___/___/___/___/___/___ ___/___/___ [0130] ___ ___ 1 2 3 4 5 6 7 8

31 ________________________ _______________ [0031] ___/___/___/___/___/___/___/___ ___/___/___ [0131] ___ ___ 1 2 3 4 5 6 7 8

32 ________________________ _______________ [0032] ___/___/___/___/___/___/___/___ ___/___/___ [0132] ___ ___ 1 2 3 4 5 6 7 8

33 ________________________ _______________ [0033] ___/___/___/___/___/___/___/___ ___/___/___ [0133] ___ ___ 1 2 3 4 5 6 7 8

34 ________________________ _______________ [0034] ___/___/___/___/___/___/___/___ ___/___/___ [0134] ___ ___ 1 2 3 4 5 6 7 8

35 ________________________ _______________ [0035] ___/___/___/___/___/___/___/___ ___/___/___ [0135] ___ ___ 1 2 3 4 5 6 7 8

36 ________________________ _______________ [0036] ___/___/___/___/___/___/___/___ ___/___/___ [0136] ___ ___ 1 2 3 4 5 6 7 8

37 ________________________ _______________ [0037] ___/___/___/___/___/___/___/___ ___/___/___ [0137] ___ ___ 1 2 3 4 5 6 7 8

38 ________________________ _______________ [0038] ___/___/___/___/___/___/___/___ ___/___/___ [0138] ___ ___ 1 2 3 4 5 6 7 8

39 ________________________ _______________ [0039] ___/___/___/___/___/___/___/___ ___/___/___ [0139] ___ ___ 1 2 3 4 5 6 7 8

40 ________________________ _______________ [0040] ___/___/___/___/___/___/___/___ ___/___/___ [0140] ___ ___ 1 2 3 4 5 6 7 8

41 ________________________ _______________ [0041] ___/___/___/___/___/___/___/___ ___/___/___ [0141] ___ ___ 1 2 3 4 5 6 7 8

42 ________________________ _______________ [0042] ___/___/___/___/___/___/___/___ ___/___/___ [0142] ___ ___ 1 2 3 4 5 6 7 8

43 ________________________ _______________ [0043] ___/___/___/___/___/___/___/___ ___/___/___ [0143] ___ ___ 1 2 3 4 5 6 7 8

44 ________________________ _______________ [0044] ___/___/___/___/___/___/___/___ ___/___/___ [0144] ___ ___ 1 2 3 4 5 6 7 8

45 ________________________ _______________ [0045] ___/___/___/___/___/___/___/___ ___/___/___ [0145] ___ ___ 1 2 3 4 5 6 7 8

46 ________________________ _______________ [0046] ___/___/___/___/___/___/___/___ ___/___/___ [0146] ___ ___ 1 2 3 4 5 6 7 8

47 ________________________ _______________ [0047] ___/___/___/___/___/___/___/___ ___/___/___ [0147] ___ ___ 1 2 3 4 5 6 7 8

48 ________________________ _______________ [0048] ___/___/___/___/___/___/___/___ ___/___/___ [0148] ___ ___ 1 2 3 4 5 6 7 8

49 ________________________ _______________ [0049] ___/___/___/___/___/___/___/___ ___/___/___ [0149] ___ ___ 1 2 3 4 5 6 7 8

50 ________________________ _______________ [0050] ___/___/___/___/___/___/___/___ ___/___/___ [0150] ___ ___ 1 2 3 4 5 6 7 8

51 ________________________ _______________ [0051] ___/___/___/___/___/___/___/___ ___/___/___ [0151] ___ ___ 1 2 3 4 5 6 7 8

52 ________________________ _______________ [0052] ___/___/___/___/___/___/___/___ ___/___/___ [0152] ___ ___ 1 2 3 4 5 6 7 8

53 ________________________ _______________ [0053] ___/___/___/___/___/___/___/___ ___/___/___ [0153] ___ ___ 1 2 3 4 5 6 7 8

54 ________________________ _______________ [0054] ___/___/___/___/___/___/___/___ ___/___/___ [0154] ___ ___ 1 2 3 4 5 6 7 8

55 ________________________ _______________ [0055] ___/___/___/___/___/___/___/___ ___/___/___ [0155] ___ ___ 1 2 3 4 5 6 7 8

56 ________________________ _______________ [0056] ___/___/___/___/___/___/___/___ ___/___/___ [0156] ___ ___ 1 2 3 4 5 6 7 8

57 ________________________ _______________ [0057] ___/___/___/___/___/___/___/___ ___/___/___ [0157] ___ ___ 1 2 3 4 5 6 7 8

58 ________________________ _______________ [0058] ___/___/___/___/___/___/___/___ ___/___/___ [0158] ___ ___ 1 2 3 4 5 6 7 8

59 ________________________ _______________ [0059] ___/___/___/___/___/___/___/___ ___/___/___ [0159] ___ ___ 1 2 3 4 5 6 7 8

60 ________________________ _______________ [0060] ___/___/___/___/___/___/___/___ ___/___/___ [0160] ___ ___ 1 2 3 4 5 6 7 8

61 ________________________ _______________ [0061] ___/___/___/___/___/___/___/___ ___/___/___ [0161] ___ ___ 1 2 3 4 5 6 7 8

62 ________________________ _______________ [0062] ___/___/___/___/___/___/___/___ ___/___/___ [0162] ___ ___ 1 2 3 4 5 6 7 8

Zone Description Module Section 8-digit Serial Number Input# Section Define Assign Zone Options

DigiplexNEDGP-NE96 -8-Programming Guide

63 ________________________ _______________ [0063] ___/___/___/___/___/___/___/___ ___/___/___ [0163] ___ ___ 1 2 3 4 5 6 7 8

64 ________________________ _______________ [0064] ___/___/___/___/___/___/___/___ ___/___/___ [0164] ___ ___ 1 2 3 4 5 6 7 8

65 ________________________ _______________ [0065] ___/___/___/___/___/___/___/___ ___/___/___ [0165] ___ ___ 1 2 3 4 5 6 7 8

66 ________________________ _______________ [0066] ___/___/___/___/___/___/___/___ ___/___/___ [0166] ___ ___ 1 2 3 4 5 6 7 8

67 ________________________ _______________ [0067] ___/___/___/___/___/___/___/___ ___/___/___ [0167] ___ ___ 1 2 3 4 5 6 7 8

68 ________________________ _______________ [0068] ___/___/___/___/___/___/___/___ ___/___/___ [0168] ___ ___ 1 2 3 4 5 6 7 8

69 ________________________ _______________ [0069] ___/___/___/___/___/___/___/___ ___/___/___ [0169] ___ ___ 1 2 3 4 5 6 7 8

70 ________________________ _______________ [0070] ___/___/___/___/___/___/___/___ ___/___/___ [0170] ___ ___ 1 2 3 4 5 6 7 8

71 ________________________ _______________ [0071] ___/___/___/___/___/___/___/___ ___/___/___ [0171] ___ ___ 1 2 3 4 5 6 7 8

72 ________________________ _______________ [0072] ___/___/___/___/___/___/___/___ ___/___/___ [0172] ___ ___ 1 2 3 4 5 6 7 8

73 ________________________ _______________ [0073] ___/___/___/___/___/___/___/___ ___/___/___ [0173] ___ ___ 1 2 3 4 5 6 7 8

74 ________________________ _______________ [0074] ___/___/___/___/___/___/___/___ ___/___/___ [0174] ___ ___ 1 2 3 4 5 6 7 8

75 ________________________ _______________ [0075] ___/___/___/___/___/___/___/___ ___/___/___ [0175] ___ ___ 1 2 3 4 5 6 7 8

76 ________________________ _______________ [0076] ___/___/___/___/___/___/___/___ ___/___/___ [0176] ___ ___ 1 2 3 4 5 6 7 8

77 ________________________ _______________ [0077] ___/___/___/___/___/___/___/___ ___/___/___ [0177] ___ ___ 1 2 3 4 5 6 7 8

78 ________________________ _______________ [0078] ___/___/___/___/___/___/___/___ ___/___/___ [0178] ___ ___ 1 2 3 4 5 6 7 8

79 ________________________ _______________ [0079] ___/___/___/___/___/___/___/___ ___/___/___ [0179] ___ ___ 1 2 3 4 5 6 7 8

80 ________________________ _______________ [0080] ___/___/___/___/___/___/___/___ ___/___/___ [0180] ___ ___ 1 2 3 4 5 6 7 8

81 ________________________ _______________ [0081] ___/___/___/___/___/___/___/___ ___/___/___ [0181] ___ ___ 1 2 3 4 5 6 7 8

82 ________________________ _______________ [0082] ___/___/___/___/___/___/___/___ ___/___/___ [0182] ___ ___ 1 2 3 4 5 6 7 8

83 ________________________ _______________ [0083] ___/___/___/___/___/___/___/___ ___/___/___ [0183] ___ ___ 1 2 3 4 5 6 7 8

84 ________________________ _______________ [0084] ___/___/___/___/___/___/___/___ ___/___/___ [0184] ___ ___ 1 2 3 4 5 6 7 8

85 ________________________ _______________ [0085] ___/___/___/___/___/___/___/___ ___/___/___ [0185] ___ ___ 1 2 3 4 5 6 7 8

86 ________________________ _______________ [0086] ___/___/___/___/___/___/___/___ ___/___/___ [0186] ___ ___ 1 2 3 4 5 6 7 8

87 ________________________ _______________ [0087] ___/___/___/___/___/___/___/___ ___/___/___ [0187] ___ ___ 1 2 3 4 5 6 7 8

88 ________________________ _______________ [0088] ___/___/___/___/___/___/___/___ ___/___/___ [0188] ___ ___ 1 2 3 4 5 6 7 8

89 ________________________ _______________ [0089] ___/___/___/___/___/___/___/___ ___/___/___ [0189] ___ ___ 1 2 3 4 5 6 7 8

90 ________________________ _______________ [0090] ___/___/___/___/___/___/___/___ ___/___/___ [0190] ___ ___ 1 2 3 4 5 6 7 8

91 ________________________ _______________ [0091] ___/___/___/___/___/___/___/___ ___/___/___ [0191] ___ ___ 1 2 3 4 5 6 7 8

92 ________________________ _______________ [0092] ___/___/___/___/___/___/___/___ ___/___/___ [0192] ___ ___ 1 2 3 4 5 6 7 8

93 ________________________ _______________ [0093] ___/___/___/___/___/___/___/___ ___/___/___ [0193] ___ ___ 1 2 3 4 5 6 7 8

94 ________________________ _______________ [0094] ___/___/___/___/___/___/___/___ ___/___/___ [0194] ___ ___ 1 2 3 4 5 6 7 8

95 ________________________ _______________ [0095] ___/___/___/___/___/___/___/___ ___/___/___ [0195] ___ ___ 1 2 3 4 5 6 7 8

96 ________________________ _______________ [0096] ___/___/___/___/___/___/___/___ ___/___/___ [0196] ___ ___ 1 2 3 4 5 6 7 8

Zone Description Module Section 8-digit Serial Number Input# Section Define Assign Zone Options

DigiplexNEDGP-NE96 -9-Programming Guide

Zone Report Codes

Ademco slow, Silent Knight fast, SESCOA, Ademco express or Pager formats:

Key-in desired 2-digit hexa values from 00 to FF.

Ademco format:

Use section [4032] to program a set of default Ademco report codes from the “Automatic Report Code Programming” on page39. Then to program the remaining report codes or to change some of the

defaults, enter the individual sections and key-in the desired 2-digit hexa value found in the “Contact ID Report Code List” on page42.

SIA format:

Use section [4032] to program a set of SIA report codes from the “Automatic Report Code Programming” on page39. Codes that have not been set to default can be set to default manually by entering FF

in the appropriate section. To disable the reporting of an event, enter 00 in the appropriate section.

ZONE REPORT CODES

Section Zone # Alarm Report

Codes Alarm Restore

Report Codes Tamper Report

Codes Tamper Restore

Report Codes Section Zone # Alarm Report

Codes Alarm Restore

Report Codes Tamper Report

Codes Tamper Restore

Report Codes

[0201] Zone 1 __/__ __/__ __/__ __/__ [0224] Zone 24 __/__ __/__ __/__ __/__

[0202] Zone 2 __/__ __/__ __/__ __/__ [0225] Zone 25 __/__ __/__ __/__ __/__

[0203] Zone 3 __/__ __/__ __/__ __/__ [0226] Zone 26 __/__ __/__ __/__ __/__

[0204] Zone 4 __/__ __/__ __/__ __/__ [0227] Zone 27 __/__ __/__ __/__ __/__

[0205] Zone 5 __/__ __/__ __/__ __/__ [0228] Zone 28 __/__ __/__ __/__ __/__

[0206] Zone 6 __/__ __/__ __/__ __/__ [0229] Zone 29 __/__ __/__ __/__ __/__

[0207] Zone 7 __/__ __/__ __/__ __/__ [0230] Zone 30 __/__ __/__ __/__ __/__

[0208] Zone 8 __/__ __/__ __/__ __/__ [0231] Zone 31 __/__ __/__ __/__ __/__

[0209] Zone 9 __/__ __/__ __/__ __/__ [0232] Zone 32 __/__ __/__ __/__ __/__

[0210] Zone 10 __/__ __/__ __/__ __/__ [0233] Zone 33 __/__ __/__ __/__ __/__

[0211] Zone 11 __/__ __/__ __/__ __/__ [0234] Zone 34 __/__ __/__ __/__ __/__

[0212] Zone 12 __/__ __/__ __/__ __/__ [0235] Zone 35 __/__ __/__ __/__ __/__

[0213] Zone 13 __/__ __/__ __/__ __/__ [0236] Zone 36 __/__ __/__ __/__ __/__

[0214] Zone 14 __/__ __/__ __/__ __/__ [0237] Zone 37 __/__ __/__ __/__ __/__

[0215] Zone 15 __/__ __/__ __/__ __/__ [0238] Zone 38 __/__ __/__ __/__ __/__

[0216] Zone 16 __/__ __/__ __/__ __/__ [0239] Zone 39 __/__ __/__ __/__ __/__

[0217] Zone 17 __/__ __/__ __/__ __/__ [0240] Zone 40 __/__ __/__ __/__ __/__

[0218] Zone 18 __/__ __/__ __/__ __/__ [0241] Zone 41 __/__ __/__ __/__ __/__

[0219] Zone 19 __/__ __/__ __/__ __/__ [0242] Zone 42 __/__ __/__ __/__ __/__

[0220] Zone 20 __/__ __/__ __/__ __/__ [0243] Zone 43 __/__ __/__ __/__ __/__

[0221] Zone 21 __/__ __/__ __/__ __/__ [0244] Zone 44 __/__ __/__ __/__ __/__

[0222] Zone 22 __/__ __/__ __/__ __/__ [0245] Zone 45 __/__ __/__ __/__ __/__

[0223] Zone 23 __/__ __/__ __/__ __/__ [0246] Zone 46 __/__ __/__ __/__ __/__

DigiplexNEDGP-NE96 -10 -Programming Guide

Zone Labels

[0247] Zone 47 __/__ __/__ __/__ __/__ [0272] Zone 72 __/__ __/__ __/__ __/__

[0248] Zone 48 __/__ __/__ __/__ __/__ [0273] Zone 73 __/__ __/__ __/__ __/__

[0249] Zone 49 __/__ __/__ __/__ __/__ [0274] Zone 74 __/__ __/__ __/__ __/__

[0250] Zone 50 __/__ __/__ __/__ __/__ [0275] Zone 75 __/__ __/__ __/__ __/__

[0251] Zone 51 __/__ __/__ __/__ __/__ [0276] Zone 76 __/__ __/__ __/__ __/__

[0252] Zone 52 __/__ __/__ __/__ __/__ [0277] Zone 77 __/__ __/__ __/__ __/__

[0253] Zone 53 __/__ __/__ __/__ __/__ [0278] Zone 78 __/__ __/__ __/__ __/__

[0254] Zone 54 __/__ __/__ __/__ __/__ [0279] Zone 79 __/__ __/__ __/__ __/__

[0255] Zone 55 __/__ __/__ __/__ __/__ [0280] Zone 80 __/__ __/__ __/__ __/__

[0256] Zone 56 __/__ __/__ __/__ __/__ [0281] Zone 81 __/__ __/__ __/__ __/__

[0257] Zone 57 __/__ __/__ __/__ __/__ [0282] Zone 82 __/__ __/__ __/__ __/__

[0258] Zone 58 __/__ __/__ __/__ __/__ [0283] Zone 83 __/__ __/__ __/__ __/__

[0259] Zone 59 __/__ __/__ __/__ __/__ [0284] Zone 84 __/__ __/__ __/__ __/__

[0260] Zone 60 __/__ __/__ __/__ __/__ [0285] Zone 85 __/__ __/__ __/__ __/__

[0261] Zone 61 __/__ __/__ __/__ __/__ [0286] Zone 86 __/__ __/__ __/__ __/__

[0262] Zone 62 __/__ __/__ __/__ __/__ [0287] Zone 87 __/__ __/__ __/__ __/__

[0263] Zone 63 __/__ __/__ __/__ __/__ [0288] Zone 88 __/__ __/__ __/__ __/__

[0264] Zone 64 __/__ __/__ __/__ __/__ [0289] Zone 89 __/__ __/__ __/__ __/__

[0265] Zone 65 __/__ __/__ __/__ __/__ [0290] Zone 90 __/__ __/__ __/__ __/__

[0266] Zone 66 __/__ __/__ __/__ __/__ [0291] Zone 91 __/__ __/__ __/__ __/__

[0267] Zone 67 __/__ __/__ __/__ __/__ [0292] Zone 92 __/__ __/__ __/__ __/__

[0268] Zone 68 __/__ __/__ __/__ __/__ [0293] Zone 93 __/__ __/__ __/__ __/__

[0269] Zone 69 __/__ __/__ __/__ __/__ [0294] Zone 94 __/__ __/__ __/__ __/__

[0270] Zone 70 __/__ __/__ __/__ __/__ [0295] Zone 95 __/__ __/__ __/__ __/__

[0271] Zone 71 __/__ __/__ __/__ __/__ [0296] Zone 96 __/__ __/__ __/__ __/__

Section Zone # Zone Label Section Zone # Zone Label Section Zone # Zone Label

[0301] Zone 1 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0306] Zone 6 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0311] Zone 11 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__

[0302] Zone 2 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0307] Zone 7 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0312] Zone 12 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__

[0303] Zone 3 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0308] Zone 8 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0313] Zone 13 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__

[0304] Zone 4 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0309] Zone 9 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0314] Zone 14 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__

[0305] Zone 5 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0310] Zone 10 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ [0315] Zone 15 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
