Chapter 1Introduction
1-2 VS-06 Smart Camera Guide
Product Summary
The VS-06 Smart Camera is a compact industrial smart camera that
provides powerful machine vision capabilities with a small form factor and
intuitive software interface. The VS-06 is designed for industrial
environments where IP65/67 enclosure and rugged M12 connectivity are
required.
Fully-integrated I/O and communications make the VS-06 easy to
incorporate in virtually any machine vision application. Patented liquid
lens autofocus and modular optical zoom enables the VS-06 to inspect
objects at distances from 33 mm to 2 m and beyond.
Pressing the AutoVision button at the back of the VS-06 enables real time
dynamic autofocus. When an object is centered in the field of view and
the AutoVision button is pressed, the camera automatically adjusts focal
distance and sets internal parameters to optimize image captures.
AutoVision software, designed for use with the VS-06, provides an
intuitive interface, step-by-step configuration, and a library of presets that
allow easy setup and deployment. For more complex vision applications,
the system can be upgraded from AutoVision to Visionscape.
Features and Benefits
• Standard and C-Mount models available
• SXGA (1280 x 960), WVGA (752 x 480), and WUXGA (2048 x 1088,
C-Mount model only) resolutions available
• World’s first vision system with liquid lens autofocus (standard models)
• Integrated lighting (standard models)
• Integrated Ethernet
• Flexible programming options for custom applications
• AutoVision button for automatic targeting, calibration, and triggering
• Simplified configuration with AutoVision software
• Fully scalable with Visionscape
• Applications can be ported to Visionscape PC-based machine vision
