DHS Systems TM 95263 00 Manuel utilisateur
TM 95263 00
TECHNICAL MANUAL
OPERATOR AND FIELD MAINTENANCE MANUAL
FOR
Audio-Visual Component System (AVCS)
33 Kings Highway, Orangeburg, NY 10962 Phone: 845-359-6066
Fax: 845-365-2114
Hotline: 800-977-3647
DHS MANUAL PART NUMBER 95263 00 Web: www.drash.com
Email: [email protected]
18 SEP 2008
ISO 9001: 2000 Registered
Quality Management System
DHS Systems, LLC TM 95263 00
a
No rights are conveyed except as indicated in the legend on the cover of this document.
SAFETY STEPS TO FOLLOW IF SOMEONE IS
THE VICTIM OF ELECTRICAL SHOCK.
SEND FOR HELP AS SOON AS POSSIBLE.
DO NOT TRY TO PULL OR GRAB THE INDIVIDUAL.
IF POSSIBLE, TURN OFF THE ELECTRICAL POWER.
IF YOU CANNOT TURN OFF THE ELECTRICAL POWER, PULL, PUSH OR
LIFT THE PERSON TO SAFETY USING A DRY WOODEN POLE, OR A
DRY ROPE, OR SOME OTHER INSULATING MATERIAL.
AFTER THE INJURED PERSON IS FREE OF CONTACT WITH THE
SOURCE OF ELECTRICAL SHOCK, MOVE THE PERSON A SHORT
DISTANCE AWAY AND IMMEDIATELY START ARTIFICIAL
RESUSCITATION.
DHS Systems, LLC TM 95263 00
b
No rights are conveyed except as indicated in the legend on the cover of this document.
WARNING
HIGH VOLTAGE
is used in operation of this equipment.
DEATH ON CONTACT
may result if personnel fail to observe safety precautions.
Never work on electronic equipment unless there is another person nearby who is familiar with operation and hazards
of the equipment and who is competent in administering first aid. When operators aid the technician, the technician
must warn operators about dangerous areas.
When possible, shut off power supply to equipment before beginning work on equipment. Take particular care to
ground every capacitor that could potentially store a dangerous electrical charge. Turn off power when working inside
equipment. Always ground every part of equipment before touching it.
Be careful to not contact high-voltage connections or 115 VAC input connections when installing or operating
equipment.
Whenever the nature of operation permits, keep one hand away from equipment to reduce hazard of current flowing
through the body.
WARNING: Do not be misled by the term “low voltage.” Under adverse conditions, potentials as low as 50 volts may
cause death.
For Artificial Respiration, refer to FM 4-25.11.
DHS Systems, LLC TM 95263 00
c
No rights are conveyed except as indicated in the legend on the cover of this document.
ELECTRICAL HAZARD
Under adverse conditions, voltage used in this equipment can cause death or serious injury. Observe the following
safety precautions:
GROUND THE EQUIPMENT Before connecting primary power cables; connect grounding cable from
ground lug on power control box to earth ground. Do not remove grounding
cable until signal cables and primary power cables have been disconnected
and generator has been shut down.
AVOID THE POWER INPUT Be careful not to contact 115 VAC input connections when installing or
servicing equipment.
DO NOT SERVICE ALONE Never work on equipment unless there is another person nearby who is
familiar with operation and hazards of equipment and who can administer
first aid.
USE ONLY ONE HAND Whenever possible, use only one hand to service equipment. Keep other
hand away to reduce hazard of current flowing through vital organs of the
body.
WARNING
BURN HAZARD
Equipment may be hot to touch. Allow unit to cool before handling or use gloves when handling.
Failure to observe this warning can result in serious injury.
DHS Systems, LLC TM 95263 00
d
No rights are conveyed except as indicated in the legend on the cover of this document.
WARNING
HEAVY EQUIPMENT
Improperly lifting or carrying heavy equipment can result in serious injury or death. Refer to the
following weight limits as guidelines:
Handling Function One-Person
Max. Lift Two-Person
Max. Lift Two-Person Max.
Lift (Male Only)
Lift object from floor and place it on surface not
greater than 5 feet above floor. 37 lb. 74 lb. 112 lb.
Lift object from floor and place it on surface not
greater than 3 feet above floor. 44 lb. 88 lb. 174 lb.
Carry object 33 feet or less. 42 lb. 84 lb. 164 lb.
DHS Systems, LLC TM 95263 00
e
No rights are conveyed except as indicated in the legend on the cover of this document.
WARNING
HIGH VOLTAGE Is produced when this unit is in operation. Death or severe burns may result if personnel
fail to observe safety precautions.
WARNING
Do not operate the AVCS until the ground terminal stud has been connected to a suitable ground.
WARNING
Remove all rings, watches, and other jewelry when performing maintenance on this equipment. Secure all
loose fitting clothing to prevent from being caught in moving or rotating parts. Death or loss of limb may
result.
WARNING
Do not attempt to service or otherwise make any adjustments, connections or reconnection of wires or cables
until AVCS is shut down and completely de-energized. Death or severe burns may result.
WARNING
Trichlorotrifluoroethane, trichloroethane, and similar chemical solvents threaten public health and the
environment by destroying ozone in earth’s upper atmosphere. Use only nonhazardous cleaning material
such as clean cloth, water, and mild detergent.
DHS Systems, LLC TM 95263 00
A
No rights are conveyed except as indicated in the legend on the cover of this document.
INSERT LATEST CHANGED PAGES/WORK PACKAGES. DESTROY SUPERSEDED DATA.
LIST OF EFFECTIVE PAGES/WORK PACKAGES
NOTE: The portion of text affected by the changes is indicated by a vertical line in the outer margins of the
page. Changes to illustrations are indicated by miniature pointing hands. Changes to wiring diagrams
are indicated by shaded areas.
Dates of issue for original and changed pages/work packages are:
Original: 19 SEPTEMBER 2008
TOTAL NUMBER OF PAGES FOR FRONT AND REAR MATTER IS 135 AND TOTAL
NUMBER OF WORK PACKAGES IS 59 CONSISTING OF THE FOLLOWING:
Page/WP
No. * Change
No. Page/WP
No. * Change
No.
Cover-1 0 Chp 5 title page 0
Cover-2 blank 0 WP 0017 00 (2 pgs) 0
a – j 0 WP 0018 00 (2 pgs) 0
A-B 0
i – vii 0
viii blank 0
Chp 1 title page 0
WP 0001 00 (6 pgs) 0
WP 0002 00 (10 pgs) 0
WP 0003 00 (2 pgs) 0
Chp 2 title page 0
WP 0004 00 (8 pgs) 0
WP 0005 00 (36 pgs) 0
WP 0006 00 (4 pgs) 0
WP 0007 00 (10 pgs) 0
WP 0008 00 (2 pgs) 0
WP 0009 00 (2 pgs) 0
Chp 3 title page 0
WP 0010 00 (4 pgs) 0
WP 0011 00 (12 pgs) 0
WP 0012 00 (2 pgs) 0
Chp 4 title page 0
WP 0013 00 (14 pgs) 0
WP 0014 00 (16 pgs) 0
WP 0015 00 (16 pgs)
WP 0016 00 (16 pgs)
* Zero in this column indicates an original page or work package.
