DGSHAPE MonoFab SRM-20 Manuel utilisateur

Guide for Cutting

with MODELA Player 4

Guide for Cutting

with SRP Player

Preparing the Machine

Double Sided Cutting Manual

This manual provides basic instructions on how to perform double-sided

cutting using one of the two included software programs: SRP Player and

MODELA Player 4. For information on any use of SRP Player or MODELA

Player 4 not covered herein, see the Help for each software program.

"User’s Manual “Display Help Dialog”

For information on basic operation, one-sided cutting, maintenance, and

other procedures, refer to the User’s Manual.

Contents

Contents .....................................................2

Preparing the Machine .......................................4

Preparing the Machine........................................5

Flow Diagram ...........................................5

STEP 1 : Turning the Power On ...........................6

STEP 2 : The Machine Run-in .............................7

STEP 3 : Conrm the Command Set.......................9

STEP 4 : Register the Cutting Tool You Want to Use

(when you are using SRP Player)........................ 10

STEP 5 : Attach the Cutting Tool ........................ 11

Guide for Cutting with SRP Player........................... 14

The Flow of Double-Sided Cutting .......................... 15

The Flow of Double-Sided Cutting ..................... 15

Items Necessary for Cutting ................................. 16

Items to Prepare Yourself............................... 18

Preparing the Material ...................................... 19

STEP 1 : Attach the Material to the Scrap Board ......... 19

STEP 2 : Install the Cutting Tool......................... 21

STEP 3 : Set the Origin Point............................ 22

STEP 4 : Level the Scrap Board Surface.................. 26

STEP 5 : Perform the Surface Leveling of the Material ... 28

STEP 6 : Level the Bottom Surface of the Material ....... 30

Creating an SRP Player File .................................. 31

STEP 1 : Measure the Thickness of the Material.......... 31

STEP 2 : Determine the Size and

Orientation of the Model. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

STEP 3 : Determine What to Do......................... 35

STEP 4 : Create the Cutting Data........................ 37

STEP 5 : Preview the Result of Cutting .................. 40

Cutting (Double Sided). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

STEP 1 : Set the Origin Point............................ 41

STEP 2 : Perform the Roughing ......................... 42

STEP 3 : Perform the Finishing.......................... 47

STEP 4 : Set the Drilling Process ........................ 52

STEP 5 : Drill the Scrap Board........................... 56

STEP 6 : Reverse the Material ........................... 60

STEP 7 : Cut the Bottom Surface ........................ 62

STEP 8 : Remove the Cut Material....................... 63

STEP 9 : Turning the Power O ......................... 64

Guide for Cutting with MODELA Player 4.................... 65

The Flow of Double-Sided Cutting .......................... 66

The Flow of One Side Cutting .......................... 66

Items Necessary for Cutting ................................. 67

Items to Prepare Yourself............................... 69

Contents

Creating a MODELA Player 4 File............................. 70

STEP 1: Load the Cutting Data.......................... 70

STEP 2 : Set the Machine Selection ..................... 70

STEP 3 : Set the Origin Point of the

Model and Orientation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

STEP 4 : Set the Material ............................... 72

STEP 5 : Set the Number of Cutting Surfaces ............ 72

STEP 6 : Set the Margin................................. 73

STEP 7 : Set the Surface leveling

Process of the Scrap Board ............................. 74

STEP 8 : Conrm the Cutting Preview ................... 81

STEP 9 : Set the Surface leveling

Process of the Material................................. 83

STEP 10 : Set the Roughing Process..................... 88

STEP 11 : Set the Finishing Process ..................... 93

STEP 12 : Set the Drilling Process ....................... 97

STEP 13 : Set the Bottom Surface Process ..............103

Cutting (Double Sided). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

STEP 1 : Attach the Material to the Scrap Board ........106

STEP 2 : Set the Origin Point...........................108

STEP 3 : Perform the Surface Leveling

of the Scrap Board ....................................112

STEP 4 : Perform the Surface Leveling of the Material ..115

STEP 5 : Perform the Roughing .......................116

STEP 6 : Perform the Finishing.........................118

STEP 7 : Perform the Drilling in the Material............120

STEP 8 : Perform the Drilling in the Scrap Board ........122

STEP 9 : Reverse the Material ..........................123

STEP 10 : Cut the Bottom Surface......................126

STEP 11 : Remove the Cut Material ....................126

STEP 12 : Turning the Power O .......................127

http://www.dgshape.com/

Company names and product names are trademarks or registered trademarks

of their respective holders.

Preparing the Machine

Preparing the Machine ..........................5

Flow Diagram .............................................. 5

STEP 1 : Turning the Power On............................... 6

STEP 2 : The Machine Run-in ................................ 7

STEP 3 : Conrm the Command Set.......................... 9

STEP 4 : Register the Cutting Tool You Want to Use

(when you are using SRP Player)............................10

STEP 5 : Attach the Cutting Tool ............................11

Preparing the Machine

Flow Diagram

1. “STEP 1 : Turning the Power On” (p. 6)

2. “STEP 2 : The Machine Run-in” (p. 7)

3. “STEP 3 : Conrm the Command Set” (p. 9)

4. “STEP 4 : Register the Cutting Tool You Want to Use

(when you are using SRP Player)”

(p. 10)

5. “STEP 5 : Attach the Cutting Tool” (p. 11)

*Work is unnecessary in some cases. For detail, please conrm procedure contents.

Preparing the Machine

STEP 1 : Turning the Power On

Procedure

1. Close the front cover.

2. Press the [ ] (Power) button.

The LED lamp starts ashing and it stays lit after initialization completes.

●〇〇〇〇

Preparing the Machine

STEP 2 : The Machine Run-in

When the machine must be run-in

• When the machine is rst set up

• When the consumable part is replaced

• When the machine is not used for a prolonged period

Go to the “STEP 3 : Conrm the Command Set” (p. 9), when the

machine does not need to run-in.

Procedure

1. If a material, or cutting tool is mounted on the machine, remove it.

2. Start VPanel.

"User's Manual “Start VPanel”

3. Click at the upper left of a screen, and click [Maintenance].

〇●〇〇〇

Preparing the Machine

4. Click [Conrm] tab. 5. Click [Start] of “Idling.”

*Required time : Approx. 10 minutes

When operation is completed, click [OK] and close a [Maintenance] screen.

Preparing the Machine

STEP 3 : Conrm the Command Set

Select the appropriate command mode to match the software to be used.

"User's Manual “Command Set”

NC Code le outputting

"User's Manual “NC Code”

CAUTION

If a command that is sent to the machine is dierent from the command set

selected on the VPanel, an error occurs and cutting becomes impossible.

Command Set Setting

Procedure

1. Click [Setup] on the VPanel.

2. Select the suitable command set.

"Piano.stl" : [RML-1] [OK]

〇〇●〇〇

Preparing the Machine

STEP 4 : Register the Cutting Tool You Want to Use (when you

are using SRP Player)

Before you can use a particular cutting tool type, you need to register it with

SRP Player.

You cannot use any cutting tool that has not yet been

registered. Be sure to make a registration before

creating an SRP Player le.

MEMO

If you are using MODELA Player 4 rather than SRP Player, proceed to ”STEP

5 : Attach the Cutting Tool” (p. 11).

Procedure

1. On the menu bar of SRP Player, click [Options] [My Tools...].

2. Register the cutting tool.

Select the check box next to the cutting tool you want to register and then

click .

In the following example, “2 mm Square” and “3 mm Square” are selected.

〇〇〇●〇
