DFI G586IPB Manuel utilisateur
G586IPB/W
Rev. 0+
System Board
User’s Manual
-D28951005-
vCopyright 1995 by DFI, Inc.
All rights reserved.
No part of this document may be copied, reproduced in
any form, or by any means or used to make any trans-
formation/adaptation without the prior written consent
of DFI, Inc.
DFI, Inc. makes no warranties with respect to this
documentation and disclaims any implied warranties of
merchantability, quality, or fitness for any particular
purpose. The information in this document is subject to
change without notice. DFI, Inc. reserves the right to
make revisions to this publication and to make changes
to any and/or all parts of its content, at any time,
without obligation to notify any person or entity of such
changes. Further, DFI, Inc. assumes no responsibility
for any errors that may appear in this document.
DFI is a registered trademark, and G586IPB/W is a
trademark of Diamond Flower, Inc. All other product
names mentioned are trademarks or registered trade-
marks of their respective companies.
vFCC Statement on Class B
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
the receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio TV
technician for help.
Notice:
1. The changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
2. Shielded interface cables must be used in order to
comply with the emission limits.
v Table of Contents v
Introduction ..............................................................................
Features and Specifications .........................................
Package Checklist ........................................................
Installation Overview ...............................................................
Preparing the Area ..............................................................
Handling the System Board ................................................
Tips in Handling the System Board ..............................
Hardware Installation...........................................................
Memory Installation .......................................................
Installing the Modules ............................................
Board Configuration ......................................................
Jumper Settings for Display Type and
CMOS Clean ..........................................................
Jumper Settings for Super I/O Setting and
IRQ Select ..............................................................
Cache Configuration .....................................................
Installing the Cache Module ..................................
VRM Header .................................................................
VRM Header and 3.3V Pentium Processor ...........
VRM Header and Future Low-Voltage CPUs ........
CPU Installation ............................................................
Jumper Settings for CPU .......................................
Jumpers JP11 and JP50 ..............................................
Installing Upgrade CPUs ..............................................
Built-in Ports ........................................................................
Serial Ports ...................................................................
PS/2 Mouse Port ...........................................................
Parallel Port ..................................................................
Floppy Disk Drive Connector ........................................
IDE Hard Disk Interface ................................................
1
2
5
5
5
6
6
7
9
12
13
14
14
16
16
18
18
19
20
21
26
27
32
33
34
35
36
38
Installing Expansion Cards ..................................................
Troubleshooting Checklist .....................................................
Appendix A:Types of Modules ..............................................
Appendix B:Memory and I/O Maps .......................................
Appendix C:PCI I/O Pin Assignments ..................................
Appendix D: ISA I/O Pin Assignments .................................
Appendix E: System Overview ..............................................
Appendis F: Connector Pin Assignments ............................
41
43
44
45
47
48
49
52
G586IPB/W
1
vIntroduction
The G586IPB/W system board offers several advanced
features integrated into the system board. Its design is
based on the new Peripheral Component Interconnect
(PCI) local bus and Industry Standard Architecture
(ISA) standards.
The G586IPB/W provides a 321-pin Zero Insertion
Force (ZIF) CPU socket for PentiumTM processors
running at 75MHz, 90MHz, 100MHz, 120MHz,
133MHz or 150MHz frequencies. This ZIF socket
allows users to easily upgrade their CPUs. It also pro-
vides a VRM (Voltage Regulation Module) header
which lets you to upgrade to future low-voltage CPUs.
The G586IPB/W is equipped with four PCI slots and
three ISA slots.
The G586IPB/W board has two bus master PCI IDE
connectors. Bus mastering reduces CPU use during disk
transfer. The system board is also equipped with two
NS16C550A-compatible serial ports, an SPP parallel
port, a floppy disk drive controller, one PS/2 mouse port
and one PS/2 or AT keyboard connector.
The G586IPB/W can support 8MB to 128MB of
memory using 1Mx36, 2Mx36, 4Mx36 and 8Mx36 72-
pin SIM modules.
G586IPB/W
2
Features and Specifications
Processor
•Intel PentiumTM Processor 75/90/100/120/133/
150MHz
•Future Pentium OverDrive Processor
System Design
•Intel Triton chipset
•Four 72-pin SIMM sockets
•8MB to 128MB onboard memory
•Uses EDO or fast page mode x32 DRAM, 60 or
70ns, 5V
•256KB or 512KB L2 cache, direct-map WB or WT
•Uses 3.3V pipeline burst or asynchronous cache
SRAM on 160-pin cache module
•EDO DRAM and pipeline burst cache SRAM give
optimal performance
•4 PCI slots (all bus masters)
•3 ISA slots (one shared with PCI slot)
•Award BIOS, Windows 95 Plug and Play compliant
•Flash EPROM for easy BIOS upgrades
Energy Efficient Design
•System power management supported
•CPU stopped clock control
•Hardware supports SMI green mode
•Microsoft/Intel APM 1.1 compliant
•External power management switch supported
Two Bus Master PCI IDE Connectors
•PIO Mode 3 & 4 Enhanced IDE (data transfer rate
up to 16.6MB/sec.)
•DMA Mode 2 Bus Master IDE (data transfer rate
up to 22.2MB/sec.)
•Bus mastering reduces CPU utilization during disk
transfer
G586IPB/W
3
•ATAPI IDE CD-ROM supported
Integrated I/O
•Winbond super I/O controller
•One 720KB/1.2MB/1.44MB floppy controller
•Two NS 16C550A-compatible high speed UARTs
•One parallel port
•Plug and Play compliant
Connectors
•Serial ports: 2 connectors
•Parallel port: 1 connector
•IDE: 2 shrouded headers
•Floppy: 1 connector
•PS/2 mouse connector
•PS/2 keyboard connector or AT keyboard connector
CPU Socket
•VRM (Voltage Regulation Module) header allows
upgrade to future low-voltage CPUs
•321-pin ZIF socket (Intel Socket 7)
PCB
•4 layers
•280mm (11.02") x 220mm (8.66")
Slot Limitations
Due to the size of the CPU with its accompanying
heatsink/fan component, the length of the add-in
cards in PCI slots 2, 3 and 4 is limited to 205mm
(measured from the bracket of the card).
The length of the add-in card in PCI slot 1 is
limited to 205mm only if its components protrude
more than 5mm from the components and/or solder
side of the card.
G586IPB/W
4
Package Checklist
The G586IPB/W package contains the following items:
•The G586IPB/W system board
•The G586IPB/W user’s manual
•One 34-pin floppy disk drive cable
•One 25-pin printer port cable for chassis mounting
•One card-edge bracket with serial and mouse port
cables
•Cache module (optional)
If any of these items is missing or damaged, please
contact your dealer or sales representative for assistance.
G586IPB/W
5
vInstallation Overview
This chapter summarizes the steps in installing the
G586IPB/W system board into your system unit. It also
includes a description of the area in which you must
work and directions for memory installation. Before
installing the system board, obtain the memory you plan
to install. Please refer to the memory chart on page 9 for
the number and type of SIM modules needed for the
amount of memory you require.
Preparing the Area
Before unpacking the system board, make sure the
location you have selected is relatively free of dust and
static electricity. Excessive exposure to dust, static
electricity, direct sunlight, excessive humidity, extreme
cold, and water can damage the operational capabilities
of your system board. Avoid placing the unit on surfaces
such as carpeted floors. These areas also attract static
electricity which can damage some circuits on your
system board.
Make sure the power source has a properly grounded,
three-pronged socket. It is essential that the power
connection be properly grounded for correct functioning
of your system board. For further protection, we recom-
mend that you use a surge suppressor. This will protect
the system board from damage that may result from a
power surge on the electrical line.
Move items that generate magnetic fields away from
your system board since magnetic fields can also
damage your system board. Once you have selected the
