Dewenwils HOYS22A Manuel utilisateur

HOYS22A

Digital

Align four tabs on stake with four holes on back of timer. Push

tabs down, then up, until they lock into place. Shown as Figure

Before programming, all settings should be reset. The reset hole which is

identified by “R” is just located below the “R/RECALL” button. Use a paper

clip or ball point pen to stick it. See Figure 1.

1. Reset

Before initial use, plug the timer in for at least 30 minutes to charge the

internal battery. After the screen displays, the unit is ready for programming.

2. Set the Current Time

a. Keep the “CLOCK” button pressed the entire setting operation.

b. Press the “HOUR” button to set hours.

c. Press the “MIN” button to set minutes.

d. Press the “WEEK” button to select the correct day of the week.

e. Release the “CLOCK” button. The time will be set.

Overload Protection

Switch

Indicator

Outlets

a. Press the “PROG” button once , Figure 2 will appear. There are a total

of 20 ON/OFF settings.

3. ON/OFF Program Setting

b. Press the “HOUR” or “MIN” buttons to set ON time.

c. Press the “WEEK” button to select the day(s).

d. Press the “PROG” button to save and proceed to the “1 OFF ” setting.

See Figure 3

e. Repeat steps a-e to set ON/OFF times. Press the “PROG” button again

will advance to the other 19 ON/OFF settings.

Note:Timer should operate in the “AUTO ON” or “AUTO OFF” mode.

See “Switching Mode Indication” section.

4. Reset Button

a. Press the “PROG” button to select the ON/OFF setting that needs to be

changed.

b. Press the “ R/RECALL” button to reset the current ON/OFF setting (See

Figure 4) without having to scroll through all the hours.

5. Switching Mode Indication

The actual mode is shown on the display as “ON”, “AUTO ON”, “OFF”, or

“AUTO OFF” together with the time of day. Press the “ON/AUTO/OFF”

button to adjust to the desired setting mode.

6. Manual Override Setting

As an independent programming, it is possible at any given time to advance

to the next switching command by constantly pressing the “MANUAL” button,

as shown below:

ON = Always ON;

OFF = Always OFF;

AUTO ON = Timer is ON currently and ON/OFF program is activated.

AUTO OFF = Timer is OFF currently and ON/OFF program is activated.

7. Daylight Saving Time (DST)

Press and hold the “CLOCK” button for 3 seconds to advance to the current

time 1 hour, “+1h” icon will appear on the display. Press and hold the

“CLOCK” button for 3 seconds again to decrease 1 hour and the “+1h” icon

will disappear. See Figure 8.

8. Power Back-up Feature

In the event of a power failure, the timer will retain its settings for an

estimated 3 months if the power backup is fully charged.

15A Resistive

1000W Tungsten

1 HP

14/3C

E-
