Dewenwils HOMT11B Manuel utilisateur
Please pay attention to the warning signs
Read the instructions with caution before operating
and keep it properly
V20718
[Instruction Manual]
Outdoor Mechanical Pin Timer
SKU: HOMT11B
1.The timer must be mounted in a vertical position with the outlet facing
downward and at least 2ft above the ground level.
2.Do not connect any devices which may exceed the maximum ratings of
this timer. 3.Do not immerse in water.
4.Children are not allowed to use the timer without supervision.
5.Do not disassemble or repair the product, but only by authorized service
personnel.
6.Please always unplug and store indoors when not in use.
7. Cord-connected Operating control.
Button Layout
1.Side Switch
The side switch is used to set the timer function: Always ON or Timer
Control.
2. Timer Dial
- Day time :7:00 AM-6:00 PM/ Night time : 7:00PM- 6:00 AM
- Each pin represents 30 minutes: 2 pins= 1 hour
- Pin in down position means ON
- Pin in up position means OFF
3.Outlet
Plug the lights or devices to be controlled by the timer into the outlet.
01
To reduce the risk of fire, electric shock or personal injury, please strictly
follow the instructions.
WARNING:
8
8
9
11
3
7
9
10
1
2
4
5
2
10
11
1
3
4
6
7
5
6
TIME
2
1
3
Input Voltage: 125VAC, 60Hz
Max Power Rating: 15A General 15A Resistive
1875W Tungsten 500 VA Electronic Ballast 1/2HP
Cord: SJTW 14/3C
Specifications:
1.Set the current timer: Turning dial clockwise until the arrow indicates to
current time.
2. Begin with all pins pulled up. Push the pins down for the periods of time
you want the timer to be ON. Pins in down position represents ON and up
position represents OFF, shown as picture.
Note: Pins indicated by the arrow can not be pressed down, rotate the dial
to make itwork.
3.Push the “ON /TIMER” switch to “TIMER” position and plug the timer
into the wall socket. You may override operation of the timer by setting
the switch to “ON” position. The power supply will always be ON. Be sure
to set switch back to the “TIMER” for proper timer function.
4.Plug your electrical device directly into the timer. Make sure the device
is in ON state so the timer can control it to work properly.
5.If blackout, reset the timer as indicated above.
Operating Instructions
02
One Year Limited Warranty
Supported by our professional R&D team and QC team, we provide One
Year Warranty for materials and workmanship from the purchase date.
Please note that the warranty does not cover damage caused by personal
misuse or improper installation.
Please attatch your Order ID and Name so that our dedicated customer
service team can help you better.
03
