8555-M260-O1 Rev J •750EU Owner’s 1

750EU

WEIGHT INDICATOR

With Body Mass Index Features

Owner’s Manual

Cardinal Scale Mfg. Co.

8555-M260-O1 Rev J 203 E Daugherty, Webb City, MO 64870 USA

01/17 Ph: 417-673-4631 •Fax: 417-673-2153 Printed in USA

www.detecto.com

Technical Support: Ph: 866-254-8261 •tech@cardet.com

8555-M260-O1 Rev J •750EU Owner’s

8555-M260-O1 Rev J •750EU Owner’s 1

PRECAUTIONS

Before using this indicator, read this manual

and pay special attention to all "WARNING"

symbols:

IMPORTANT ELECTRICAL

WARNING

TABLE OF CONTENTS

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1

Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1

Optional Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1

EUROPEAN DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . Page 2

SITE PREPARATION REQUIREMENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

Interconnections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

Optional AC Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

Battery Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

Battery Installation/Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

KEYPAD FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

Basic Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

Body Mass Index Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 8

ANNUNCIATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

Basic Weighing Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

Body Mass Index (BMI) Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

SETUP AND CALIBRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 11

SETUP REVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17

ERROR AND STATUS DISPLAYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17

BEFORE YOU CALL SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18

CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18

EVENT COUNTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 19

PARTS IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

APPENDIX A – INDICATOR MOUNTING BRACKETS . . . . . . . . . . . . . . . . . . . . Page 23

Serial Number ______________________

Date of Purchase ___________________

Purchased From ____________________

___________________________________

RETAIN THIS INFORMATION FOR FUTURE USE

8555-M260-O1 Rev J •750EU Owner’s

pictorial content, in any manner, is prohibited. No patent liability is assumed with respect to

the use of the information contained herein.

DISCLAIMER

While every precaution has been taken in the preparation of this manual, the Seller assumes

no responsibility for errors or omissions. Neither is any liability assumed for damages

resulting from use of the information contained herein. All instructions and diagrams have

been checked for accuracy and ease of application; however, success and safety in working

with tools depend largely upon the individual accuracy, skill and caution. For this reason, the

Seller is not able to guarantee the result of any procedure contained herein. Nor can they

assume responsibility for any damage to property or injury to persons occasioned from the

procedures. Persons engaging in the procedures do so entirely at their own risk.

FCC COMPLIANCE STATEMENT

This equipment generates, uses and can radiate radio frequency, and if not installed and used

in accordance with the instruction manual, may cause interference to radio communications. It

has been designed within the limits for a Class A computing device pursuant to Subpart J of

Part 15 of FCC rules to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area may

cause interference in which case the user will be responsible to take whatever measures

necessary to correct the interference.

You may find the booklet “How to Identify and Resolve Radio TV Interference Problems”

prepared by the Federal Communications Commission helpful. It is available from the U.S.

Government Printing Office, Washington, D.C. 20402. Request stock No. 001-000-00315-4.

PROPER DISPOSAL

When this device reaches the end of its useful life, it must be properly disposed of. It must not

be disposed of as unsorted municipal waste. Within the European Union, this device should

be returned to the distributor from where it was purchased for proper disposal. This is in

accordance with EU Directive 2002/96/EC. Within North America, the device should be

disposed of in accordance with the local laws regarding the disposal of waste electrical and

electronic equipment.

It is everyone’s responsibility to help maintain the environment and to reduce

the effects of hazardous substances contained in electrical and electronic

equipment on human health. Please do your part by making certain that this

device is properly disposed of. The symbol shown to the right indicates that

this device must not be disposed of in unsorted municipal waste programs.

CAUTION

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN

INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE

INSTRUCTIONS.

ATTENTION: RISQUE D'EXPLOSION SI LA BATTERIES EST REMPLACE'E PAR

UN TYPE INCORRECT. REJETEZ LES BATTERIES UTILISE'ES SELON LES

INSTRUCTIONS.

8555-M260-O1 Rev J •750EU Owner’s 1

INTRODUCTION

Thank you for purchasing our Model 750EU Weight Indicator. It has been manufactured with

quality and reliability and has been tested before leaving our factory to insure accuracy and

dependability for years to come.

This manual is provided to guide you through installation, operation and maintenance of your

indicator. Please read it thoroughly before attempting to install or operate your 750EU and

keep it handy for future reference.

SPECIFICATIONS

Power Requirements . . . . . . . . 6 “AA” Ni-Cad or NiMH batteries (not included) OR an

optional 110 to 240 VAC 50/60Hz 12 VDC 1A wall plug-in

UL/CSA listed AC power adapter (Cardinal part number

6800-1045).

Operating Temperature . . . . . . 14 to 104 ºF (-10 to +40 ºC)

Display . . . . . . . . . . . . . . . . . . . Six digit, seven segment, 0.7 inch high LCD

Sensitivity . . . . . . . . . . . . . . . . . 0 to 2.4 mV/V

Signal Input Range . . . . . . . . . 0 to 12mV max.

Transducer Excitation . . . . . . . 5.0 VDC

Resolution . . . . . . . . . . . . . . . . 2,500 divisions

Capacities . . . . . . . . . . . . . . . . up to 10,000 divisions noncommercial

Division Value . . . . . . . . . . . . . 1, 2, or 5

Sample Rate . . . . . . . . . . . . . . 1 to 16 samples per second

Auto Zero Range . . . . . . . . . . . 0.5 or 1 through 9 divisions

Weighing Units . . . . . . . . . . . . . Pounds, kilograms, pounds/kilograms and

kilograms/pounds

Keyboard . . . . . . . . . . . . . . . . . Membrane type with 5 keys and 4 directional arrows

Enclosure Size . . . . . . . . . . . . . 6.125" W x 6.75" H x 1.75" D (16 cm x 17 cm x 4 cm)

Construction . . . . . . . . . . . . . . . Painted Steel

Standard Features:

•Metric Conversion •Selectable Sleep-Mode

•Auto Shut-Off Feature •Selectable Filtering

Optional Features:

•Optional 12VDC AC Power Adapter

8555-M260-O1 Rev J •750EU Owner’s

EUROPEAN DECLARATION OF CONFORMITY

Manufacturer: Cardinal Scale Manufacturing Company

PO Box 151

203 East Daugherty

Webb City, Missouri 64870 USA

Telephone No. 417 673 4631

Fax No. 417 673 5001

Product: Non-automatic Weight Indicating Instrument

Model Number 750

Serial Number EXXXYY-ZZZ

where XXX = day of year

YY = last two digits of year

ZZZ = sequential number

The undersigned hereby declares, on behalf of Cardinal Scale Manufacturing Company of

Webb City, Missouri, that the above-referenced product, to which this declaration relates, is

in conformity with the provisions of:

European Standard EN 45501: 1992 and equivalent International

Recommendation OIML R76, edition 1992

Test Certificate Number DK 0199-R76-07.01

Report No. DANAK-199836

Council Directive 2006/95/EC Low Voltage Directive

Council Directive 90/384/EEC (20 June, 1990) on the Harmonization

Of the Laws of Member States relating to non-automatic weighing

Systems as amended by:

Council Directive 93/68/EEC (22 July, 1993)

Council Directive 89/336/EEC (3 May, 1989) on Electromagnetic Compatibility

EN 55022:1998 Class B (CISPR 22:1997, Class B)

EN 61000-3-2:2000

EN 61000-3-3:1995+A1

The Technical Construction File required by this Directive is maintained at the corporate

headquarters of Cardinal Scale Manufacturing Company, 203 East Daugherty, Webb City,

Missouri.

_____________________

Mark Levels

Quality Assurance Administrator

8555-M260-O1 Rev J •750EU Owner’s 3

SITE PREPARATION REQUIREMENTS

The Model 750EU Weight Indicator is a precision weight indicating instrument. As with any

precision instrument, it requires an acceptable environment to operate at peak performance

and reliability. This section is provided to assist you in obtaining such an environment.

Environmental

The Model 750EU Weight Indicator meets or exceeds all certification requirements within a

temperature range of 14 to 104 °F (-10 to +40 °C).

In order to keep cooling requirements to a minimum, the indicator should be placed out of

direct sunlight and to provide adequate air circulation, keep the area around the indicator clear.

Do not place the indicator directly in front of a heating or cooling vent. Such a location will

subject the indicator to sudden temperature changes, which may result in unstable weight

readings.

Insure that the indicator has good, clean AC power and is properly grounded. In areas subject

to lightning strikes, additional protection to minimize lightning damage, such as surge

suppressors, should be installed.

Electrical Power

The 750EU indicator has been designed to operate from a 110 to 240 VAC 50/60Hz 12 VDC

1A wall plug-in UL/CSA listed AC power adapter (Cardinal part number 6800-1045). Note that

a special order is not required for operation at 240 VAC.

The socket-outlet supplying power to the indicator should be on a separate circuit from the

distribution panel and dedicated to the exclusive use of the indicator.

The socket-outlet shall be installed near the equipment and shall be easily accessible.

The wiring should conform to national and local electrical codes and ordinances and should

be approved by the local inspector to assure compliance.

On installations requiring 240 VAC power, it is the responsibility of the customer to have

a qualified electrician install the proper power adapter plug that conforms to national

electrical codes and local codes and ordinances.

8555-M260-O1 Rev J •750EU Owner’s

INSTALLATION

Unpacking

Carefully remove indicator from shipping carton and inspect it for any damage that may have

taken place during shipment. Keep carton and packing material for return shipment if it should

become necessary. The purchaser is responsible for filing all claims for any damages or loss

incurred during transit.

Should your indicator come already installed on a scale, the following installation

information does not apply to you.

Mounting

To install the indicator on the bracket, place the screw heads on the back of the indicator into

the large end of the slotted holes in the bracket. Pull down to secure the indicator. The spring

plunger will lock the indicator to the bracket. See Figures No. 1, 2 and 3.

Figure No. 1 Figure No. 2

Figure No. 3

Interconnections

The load cell input and power connections are made at the bottom rear panel of the indicator.

Refer to Figure No. 1 for the rear panel layout.

Load

Cell

Cable

Spring

Plun

AC Power

Ada

ter

Spring

Plunger

Release

NOTE! The mounting

bracket on your scale

may be different than

the one shown in

Figures No. 2 and 3.

Refer to Appendix A for

other bracket types.

8555-M260-O1 Rev J •750EU Owner’s 5

INSTALLATION, CONT.

Optional AC Power Adapter

To power the 750EU using the optional 12 VDC wall plug-in AC power adapter, connect the

plug from the adapter into the power jack on the back of the indicator and then plug the power

adapter into the proper electrical outlet. Refer to Figure 1. On models requiring 240 VAC, it is

the customer’s responsibility to obtain the correct power adapter plug.

Batteries

The 750EU indicator can use 6 "AA" size Ni-Cad or NiMH batteries (not included). You must

first obtain and install batteries before operations can begin. Batteries are contained in a battery

holder inside the indicator. Access is via a removable panel on the back of the indicator.

IMPORTANT! The 750EU can be operated from Ni-Cad or NiMH batteries. All six

(6) batteries must be of the same type. They must all be all Ni-Cad or all NiMH. DO

NOT mix Ni-Cad and NiMH batteries.

IMPORTANT! The AC power adapter is also used to recharge the batteries, when

the 750EU is operated from Ni-Cad or NiMH batteries. Make sure the niCAd setup

option is enabled (set to 1). Refer to Setup and Calibration or Setup Review.

CAUTION

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN

INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE

INSTRUCTIONS.

ATTENTION: RISQUE D'EXPLOSION SI LA BATTERIES EST REMPLACE'E PAR

UN TYPE INCORRECT. REJETEZ LES BATTERIES UTILISE'ES SELON LES

INSTRUCTIONS.

Battery Status

The 750EU indicator will operate for up to 100 hours on fully charged Ni-Cad or NiMH batteries

depending on the condition of the batteries (from new to about 500 recharges). The battery

bar graph on the display indicates the battery capacity in 4 steps:

4 segments - the full battery capacity is available,

3 segments - the battery is at 75% of capacity,

2 segments - the battery is at 50% of capacity,

1 segment: - the battery is at 25% capacity.

When the battery voltage drops too low for accurate weighing, the indicator will show LoBAt

and then shut off. You will be unable to turn the indicator back on until the batteries have been

replaced or the AC power adapter is connected to the indicator to operate it and recharge the

batteries.

Battery Charging

To recharge the Ni-Cad or NiMH batteries, the AC power adapter must be connected to a

power outlet and plugged into the indicator. It will take approximately 8 to 10 hours to fully

recharge the batteries in the display. Charging the batteries for more than 10 hours will not

damage them. NOTE! The indicator may be operated while the batteries are charging.

8555-M260-O1 Rev J •750EU Owner’s

INSTALLATION, CONT.

Battery Installation/Replacement

To install or remove the batteries, the following steps should be followed:

1. Make sure the AC power adapter is

unplugged.

2. Remove the indicator from the scale

mounting bracket. (Referring to

Figure No. 3, pull the spring plunger

down and slide the indicator away

from the bracket).

3. Turn the indicator over so that the

display is facing away from you.

4. Locate the rectangular panel on the

back of the indicator.

5. To install or replace the batteries, first

remove the battery holder cover by

pushing in on the tab and lifting it up.

Refer to Figure No. 4.

6. If installing new batteries, proceed to

step 7. If replacing the batteries,

remove all 6 batteries from the battery

holder and then proceed to step 7.

7. Install the 6 new “AA” size batteries in

the battery holder, noting the polarity

markings located in the battery

holder. Refer to Figure No. 5.

8. After placing all 6 batteries in the

holder, replace the battery cover.

9. Turn the indicator over (display facing

up) and press the ON / OFF key.

10. If display turns on, batteries have

been installed correctly. If not,

remove panel and check for one or

more improperly positioned batteries.

11. Return the indicator to the scale

mounting bracket.

12. The indicator is now ready for

operation.

Push in and

lift here

Battery

Cover

Figure No. 4

Figure No. 5

- +

+ -

- +

AC Power

ter

Table des matières

Autres manuels Detecto Instrument de mesure

Detecto

Detecto 758C Manuel

Detecto

Detecto MedVue MV2 Manuel utilisateur

Detecto

Detecto MedVue MVWIFI Guide rapide

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
