Digital Night Vision Mononuclar
Operating Manual
Model: DENVER NVI-450
【Contents】
Introduction······························3
Operating Hints···························4
Components Introduction···················5
Operating Instructions······················7
Battery Installation························7
Power On·······························8
Power Off·······························8
Scenery Observation······················9
Brightness Adjustment····················10
Photo Shooting··························13
Playback·······························14
Video Shooting··························16
Monitors Connection·······················17
PCs Connection···························17
Auto Power Off····························17
Power management·························18
Basic Parameters···························19
Configuration Standard······················21
Operating Environment and Announcements·····22
【Name】 Digital Night Vision
【Model】 DENVER NVI-450
【Features】
● It is a night vision monocular which can be used to
observe objects in the dark and low light situation.
Two lighting modes are available to use. The
viewing distance in the low light environment will
be at infinity, 200 meters viewing distance in the
dark environment.
● Easy to exchange data with other instruments，
having USB, AV OUT and DC IN sockets.
● It can be used normally in the day or night, owning
the photo shooting, video shooting, playback and other
functions. 5X fixed zoom and 5X digital zoom.
● It is the best auxiliary tool of extending human’s
visual senses.
【Operating Hints】
● It is a night vision monocular which can be used to
observe objects in the dark and low light situation. Two
lighting modes are available to use.
● It is suitable to use in full dark environment.
● Turn the auxiliary light on to observe the objects
when it works in the dark situation. Adjusting the
brightness by the distance of the objects. CCD is used in
this viewer. If there is any light resource existed, the
auxiliary light could not be turned on, please adjust the
focal distance only to get the sharp image of objects.
● Work time: 1 hour under auxiliary light mode; 1.5
hour without using auxiliary light mode.
Contents
DENVER NVI-450
1
Introduction
DENVER NVI-450
3
Operating Hints
DENVER NVI-450
4
Contents
DENVER NVI-450
2
