Denver ACT-1303 Manuel utilisateur
ACT-1303
www.facebook.com/denverelectronics
HD ACTION
CAM
Appearance
_ENG 01 _
1. Lens
2. Recording button
3. Take photos button
1
3
2
4.Micro USB Port;
5. Battery Power switch
6.Page Up Button
7. Power on Button
8. Shutter Button
9.Page Down Button
10.LCD
11.Busy indicator light(blue)
Charge indicator light(red)
12.Speaks
13.Microphone
14.Micro SD Card Slot
_ENG 02 _
4
5
13
6 7 8 9
10
12
11
14
Start to use
_ENG 03 _
1.Charge the built-in lithium battery
The camera is equipped with External 3.7V lithium battery. Please ensure power available for the camera and
timely charge it in case of low battery.
Connect the camera to computer for charging under shutdown status. The charging indicator will be on when
charging,
and will be off when the battery is fully charged. Generally, the battery can be fully charged after about
3 hours.
_ENG 04 _
2.How to use the memory card
2.1. Properly insert the TF card into the card holder as per the instructions indicated near the card holder.
2.2.
To remove the TF card, press the end of memory card gently, the card will be ejected.
Note: The camera is not equipped with built-in memory. Please insert memory card before using.
Before
using the camera,
it is a must to format the memory card on the camera.
3.Power on/off
Please switch the Battery power switch to 1 status before you turn on the camera
3.1. Power on: Short-press the power Button the screen will be on and the camera will be started.
3.2. Power off: Hold on Power Button for 3 seconds when the camera is in the idle state to turn it off.
3.3. Auto screen off: The screen will be turned off automatically when the time that the camera is in the idle state
for automatic screen off to save power.
3.4.
Power off when the camera is lack of electricity. When electrical quantity of the battery is very low, an icon
of
will be displayed on the LCD screen, prompting you to charge it in time. When the icon flickers the
camera
will be turned off automatically.
Tips: When you end the camera to use, please switch the Battery Power switch to O status.
_ENG 05 _
_ENG 06 _
After power is on,the camera will enter video recording mode directly and in preview mode,short-press Recording
Button
to start video recording; short-press it again to stop shooting.Short-press page up button or page
down button
to choice color effect of images.there are seven kinds of color effects,such as normal,black and white,
retro,negative,
red,green,blue.
4.1. Recording Mode
4.Recording mode ,photo mode,playback mode and system settings
When you turn on your camera,you can short-press the take photos button to enter photo mode,
short-press it again to capture your photo. Then short-press page up button or page down button
to join different frames.
4.2. Photo Mode
4.3. Playback mode
In recording mode or photo mode,you can short-press the power on button .The LCD display will show as
follow:
You can short-press page up button and page down button to change modes .Then short-press shutter
button to confirm mode you choice .then short-press power on button to exit it.
_ENG 07 _
: Recording mode
: photo mode
: playback mode
: system settings
You view the captured videos and photos in one of the following ways:
1.Please press button enter the Playback mode as above steps,then press down button to select the video or
photo as desired.To playback a video,press shutter button to star, press shutter button again to pause playing
videos and press power on button to stop playing videos.In playback section ,press page up button or page
down button to scroll the photos and videos.you can press power on button to enter to the mode choice.
2.Connect your camera to a computer using the supplied USB cable to view your captured videos and photos.
OK
_ENG 8 _
4.4. System settings
You can enter to system settings as above steps,short-press page up button or page down button to
choiceand short-press the shutter button to confirm.then short-press power on button to exit menu.
The functionsas follows:
1.Resolution :1M（1280×960), 3M（2048×1536), 5M（2592×1944）2.Movie Size: HD(1280×720),640(640×480）3.Power frequency:50HZ ,60HZ
4.Power save:Select OFF/1 min/3 min/5 min/Exit.To conserve battery power.the camera will shut off if no key are
pressed within the selected time
5.Date&Time:setting the date and time of the cameras
6.Language: setting the language of the cameras
7.Format:Erase all data on the SD Card
8.Reset All:Reset settings of the camera to factory default
OK
Technical parameters
_ENG 9 _
5.Connect to PC
The camera has a plug-and-play function. Connect the power-on device to the computer with the USB cable,
and the mode can be automatically switched to the removable hard disk. Removable disk icon will appear in the
"My Computer" window. The pictures and video files you shot stored in the removable disk H: \ DCIM\100MEDIA
folder (H is this equipment removable disk);
Note: During file downloading, it is prohibited to disconnect USB connection, and plugging out the memory
card when USB connected is also prohibited to avoid loss of data.
Image sensor 1.3 mega-pixel CMOS image sensor-
Function mode Recording, ,photo, playback
LCD screen 1.77'' LCD Screen
