Installation, Operation, and

Maintenance Manual

4.0

www.ayrdyne.com

Edition notice

DenTech Industrial

1975 N. Reading Rd.

Denver, PA 17517

For customer support, please contact

our service technicians.

Phone: (717) 335-4899

Email: service@dentechindustrial.com

Or visit dentechindustrial.com/customer-support

AD-IOM

Revised December 2021

Printed in the USA.

www.ayrdyne.com

. . . . . . 20

. . . . . . . . 22

. . . . . . . 24

. . . . . 25

. . . . . . . . . 26

. . . . . . . . . . . . . 28

. . . . . . . . . . 30

. . . . . . . . . . 32

. . . . . . 34

1.1 Introduction

1.2 Safety

2.1 System

2.2 Filters

2.3 Airow

2.4 Discharge

2.4 Safety

3.1 Alarms

4.1 Removal of HMI

4.2 Installation of HMI

4.3 Installation and Removal of PLC

4.4 Installation and Replacement

of the Battery

5.1 Glossary

TABLE OF CONTENTS

1OVERVIEW

OPERATION

TROUBLESHOOTING

INSTALLATION &

REMOVAL

GLOSSARY

. . . . . . . . . . . . . . . . 2

. . . . . . . . . . . . . . . . . . . 3

. . . . . . . . . . . . . . . . . . 38

. . . . . . . . . . . . . . 40

. . . . . . . . . . . . 43

. . . . . 44

. . . . . . . . . . . . . . 44

. . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . 20

. . . . . . . . . . . . . . . . . . 26

. . . . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . . . . . . 36

2.2.1 Status Bar Overview

2.1.2 Navigation Bar Overview

2.1.3 Main Screen Overview

2.1.4 Metrics (Static Pressure)

2.1.5 Alarms

2.1.6 Settings – Users

2.1.7 Settings – I/O

2.1.8 Settings – Devices

2.2.1 Primary Information

2.2.2 Primary Settings

2.2.3 Primary Solenoids

2.2.4 Secondary Information

2.3.1 Static Pressure

2.3.2 Velocity

2.3.3 VFD Settings

2.4.1 Rotary Valve

2.4.2 Double Dump Valve

2.5.1 Safety Circuit & Isolation Valve

. . . . . . . 6

. . . . . 7

. . . . . . 8

. . . . 10

. . . . . . . . . . . . . 12

. . . . . . . . 14

. . . . . . . . . 16

. . . . . . . 18

www.ayrdyne.com

INTRODUCTION

OVERVIEW

The purpose of this document is to outline

proper installation, maintenance, operation,

and care of the AyrDyne®Monitoring System

Human Machine Interface (HMI). This

document is in no way intended to be used

to determine the reliability of this product

outside of its originally intended application.

It is the duty of the end user or integrator to

perform the appropriate risk analysis in order

to determine the relevance of its use within any

specic application.

All pertinent state, regional, and local

safety regulations must be observed when

installing and using this product. For reasons

of safety and to help ensure compliance

with documented system data, only the

manufacturer should perform repairs to

components.

Failure to follow the guidelines outlined in

this manual may result in injury, harm, or

improper operating results. Failure to observe

this information may also result in equipment

damage, premature wear, or failure.

www.ayrdyne.com

SAFETY

OVERVIEW

The installation, maintenance, operation, and

care of the AyrDyne®Monitoring System Human

Machine Interface (HMI) should only be performed

by individuals who are qualied and trained

to do so. A “qualied” person in this context is a

person who has skills and knowledge related to the

construction and operation of electrical equipment

and its installation through both work experience

and training. Additionally, a qualied person is one

who has received and undergone safety training

specic to electrical maintenance. Anyone who has

not undergone safety training specic to this system

should not operate or perform maintenance on the

system.

In terms of maintenance of this system, “lock out tag

out” safety protocol applies. This means that any

time maintenance on this system is performed, the

machine must be shut down, unplugged, and tagged

or labeled, explaining that maintenance is taking

place.

DenTech is not liable for any

consequences arising from misuse of

this system. If you are unsure of whether you

are qualied to use or maintain this system, please

contact an electrician or other qualied professional

for assistance. Failure to follow safety protocol for

this and any other system could result in serious

bodily harm or other injury. No responsibility is

assumed by DenTech for any consequences arising

out of the use of this material.

1.2

This symbol indicates that an electrical hazard

exists which could result in personal injury if

the instructions are not followed.

This safety alert symbol is used to alert you

to potential personal injury hazards. Obey all

safety messages that follow this symbol to

avoid possible injury or death.

4www.ayrdyne.com

www.ayrdyne.com 5

SYSTEM

This section covers the navigation and operation of the standard AyrDyne Monitoring System. The

operation and functionality of each screen is covered in detail in later sections. The table below shows the

layout of the screens. Available screens depend on system requirements and conguration.

Airow

Safety

System

Filters

Discharge

Alarms

Settings

Overview

Primary Info

Airow Control

Primary Solenoids

Metrics

Primary Settings

VFD Settings

Secondary Info

Alarms monitoring and control

User settings, IO settings, and analog and digital device

settings

Contains all monitoring, settings, and controls related to airow

Contains all monitoring, settings, and controls related to safety

An overview of the system and the rst screen to display

when power is applied

Primary lter dierential pressure monitoring and cleaning

Airow monitoring and control settings

Primary lter cleaning system monitoring and manual

control

Contains system wide monitoring, settings, and controls

Contains all monitoring, settings, and controls related to the lters

Contains all monitoring, settings, and controls related to the discharge system

System Metrics

Primary lter cleaning settings

VFD monitoring and parameter entry

Secondary lter dierential pressure monitoring

OPERATION

2.1 OPERATION OVERVIEW

2.1

6www.ayrdyne.com

SYSTEM

2.1.1 STATUS BAR OVERVIEW

The status bar is visible in all screens. This bar displays system information, active alarm description, and

corrective action.

USER

Shows the user that is currently logged in.

Pressing the user icon will logout the current

user.

TIME AND DATE

This graphic display shows the internal date

and time. Pressing the time and will display a

pop-up entry page where the date and time

can be adjusted.

LOGO

This graphic display shows the logo

of the company that you may contact

for information on the system, spare or

replacement parts ordering and help with

the system. Pressing the logo will display the

contact information. Once on the information

screen, you may press anywhere on the

screen to return to the home screen.

SYSTEM STATE INDICATOR

This graphic display shows the current

system state.

SYSTEM FAULTS

This text display shows details of any active

faults as well as corrective actions.

System is Stopped

System is Running

System is Cleaning

System is Faulted

2.1

OPERATION

4 5321

www.ayrdyne.com

The navigation bar is located at the bottom of each screen.

The blue line and white font indicate the section currently displayed.

An orange bubble with an exclamation point denotes a warning.

A red bubble with an exclamation point denotes an alarm.

SYSTEM

2.1.2 NAVIGATION BAR OVERVIEW

START

This button starts the system.

STOP

On the rst press, this button initiates

shutdown of blower. On the second press,

this button initiates shutdown of components

pertaining to downtime cleaning sequence.

Note:When there is an active fault, the

Clear Faults button displays instead of the

Stop button. After the corresponding fault

conditions have been eliminated, press the

Clear Faults button to clear all faults.

2 3

SYSTEM

This button displays system screen.

FILTERS

This button displays the lters screen.

AIRFLOW

This button displays the airow screen.

DISCHARGE

This button displays the discharge screen.

SAFETY

This button displays the safety screen.

2.1

OPERATION

www.ayrdyne.com

SYSTEM

2.1.3 MAIN SCREEN OVERVIEW

2.1

OPERATION

2 4 5
