Never Allow Any Unauthorized or Untrained Person To Operate
This Machine
Lockout and tagout any time maintenance is performed on this
machine
WARNING
NEVER GRIND OR SAND ANY ALUMINUM OR MAGNESIUM, OR ANY
SPARK CREATING PRODUCT ON THIS MACHINE
Filters are the main need of maintenance, the cleaner the filters are kept the better the machine will
perform. This machine is equipped with timers to clean the filters, every so many minutes a pulse of
air will be released into one of the filters, and a few minutes later the other filter will be pulsed, the
time is needed to refill the tank. The time between pulses are adjustable, refer to the electrical
diagram. Warning if the time is reduced between pulses the filter may plug up reducing the
machines performance. The filters can also be pulsed with the machine off, it may blow dust back
into the work area, so caution should be used here, pulse the machine then turn machine on to pull
dust back into the filters.
The filters will clean better with machine off,
you may shut machine off and before it slows
down to a complete stop, pulse the filter and
allow the fan to prevent the dust from exiting
the filter compartment.
Filter replacement number is on the inside of
the filter door.Be sure to replace with same
type of filter or a filter made of polyester
media.
Cartridge Filters 99.95% efficeincy
down to .5 micron
The exhaust air will exit through
opening to the floor, if muffler
is added the plate on the end will
be located here to force the air
through the muffler
Motor compartment
Dust Drawer Clean
regularly, as needed Filter replacement number
Is on inside of this door.
MUST replace with the
proper fire retardant filter
