DENON AVR/AVC control protocol

Ver. 4.6ａ

Application model :AVR-4306/AVC-4320

Application terminal : RS-232C/ Ethernet

Connector specification

1. RS-232C

Connector type : DB-9pin female type, slave straight connection (DCE type)

( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )

Communication format :

Synchronous system : Tone step synchronization

Communication system : A half duplex

Communication speed : 9600bps

Character length : 8 bits

Parity control : None

Start bit : 1 bit

Stop bit : 1 bit

Communication procedure : Non procedural

Communication data length : 135 bytes (maximum)



Version Date Contents Page

4.6 29.Feb.’06 Original

1.Corrected the command of IPA,IPE,NSA,NSE for iPod control. 14,15,25,26,27 and 284.6a 06.Apr.’06

2.Added item K) 6

06.April.06

2/28

2. Ethernet

Connector type ：RJ-45(10BASE-T/100BASE-TX)

Communication format ：

Communication system : A half duplex

Communication speed : 10Mbps/100Mbps

Communication port : TCP port 23 (telnet)

Communication data length : 135bytes (maximum)

AVR/AVC

Ethernet

Cross cable

AVR/AVC

HUB

Ethernet

Straight

cable

Ethernet

Straight

cable

Example ①

Example ②

06.April.06

3/28

NETWORK SETUP of AVR-4306/AVC-4320

>Procedure of Network Setup mode.

(1)Press SYSTEM SETUP button, then System Setup Menu appears on FL-display(and OSD)

(2)Select Network Setup.

(3)Set parameters described below.

<DHCP> "ON"---Use this setting when DHCP server is on the local network.

"OFF"---Use this setting when DHCP server is not on the local network.

<IP Address> When <DHCP> sets "OFF”, please set IP address.

When <DHCP> sets "ON”, you can confirm the IP address that is set by server.

<Subnet Mask> When <DHCP> sets "OFF”, please set Subnet Mask.

When <DHCP> sets "ON”, you can confirm the Subnet Mask that is set by server.

<Gateway> Set the address of Gateway when Gateway is on the local network.

Do not set this parameter when Gateway is not on the local network.

<Primary DNS> Do not set this parameter.

<Second DNS> Do not set this parameter.

<Proxy> Set this parameter "OFF".

“OFF”---Use this setting when using the AVR-4306/AVC-4320 connected in a network.

“ON”--- Use this setting when not using the AVR-4306/AVC-4320 connected in a network.

This setting is reducing the power consumption in the standby mode.

06.April.06

4/28

Protocol specification

The following three data forms is defined.

COMMAND : The message sent to a system(AVR/AVC) from a controller(Touch Panel etc.)

A command to a system is given from a controller.

EVENT : The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC)

The result is sent, when a system is operated directly and a state changes.

*The form of EVENT presupposes that it is the same as that of COMMAND.

**Refer to the following table for the contents of COMMAND and EVENT.

RESPONSE : The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC)

if the ‘request command’ (COMMAND+?+CR(0x0D)) has came from a controller.

The RESPONSE should be sent within 200ms of receiving the COMMAND.

*The form of RESPONSE presupposes that it is the same as that of EVENT.

Basic specification : The command by ASCII CODE, parameter expression

*ASCII CODE which can be used is from 0x20 to 0x7F : the alphabet and the number of 0-9 , and space (0x20) , Some signs ,

AND carriage return(0x0D)--- It is used only as a pause sign.

Command structure : COMMAND + PARAMETER + CR(0x0D)

COMMAND : ASCII CODE of 2 characters

ex. SI : Select Input source

MS : surround Mode Setting

MV : Master Volume setting

PW : system PoWer setting

PARAMETER : ASCII CODE ( up to 25 characters)

ex. DVD : function name

CDR/TAPE-1 : function name

THX SURROUND EX : surround mode name

SUPER STADIUM : surround mode name

*Special Parameter--- ? : for request command

06.April.06

5/28

The example of a command * <CR> is the meaning of 0x0D.

SIDVD<CR> : Select Input source DVD

MSSTEREO<CR> : surround Mode Set to STEREO

MVUP<CR> : Master Volume UP

PWON<CR> : system PoWer ON

PWSTANDBY<CR> : system PoWer STANDBY

SI?<CR> : Request command for now playing input source >> Return RESPONSE ‘SI***<CR>’

06.April.06

6/28

Others

A) COMMAND is receivable also during transmission of EVENT.

B) Since CHANNEL VOLUME changes simultaneously when the SURROUND MODE changes, the value of the channel volume of all channels

returns as EVENT.

C) CHANNEL VOLUME returns the data of ALL channels by the present SURROUND MODE also including an intact channel. In this case,

the data of an intact channel is set to "50".

D) Since SURROUND MODE changes simultaneously when the INPUT source changes, the SURROUND MODE (andalso the value of the channel

volume of all channels , It described in B) ) returns as EVENT.

E) When SURROUND MODE is the same in between INPUT source change before and after, EVENT of SURROUND MODE and CHANNEL VOLUME

does NOT return.

F) Although EVENT of SURROUND MODE returns when the present SURROUND MODE is set up again, CHANNEL VOLUME does NOT return.

G) When SURROUND MODE is changed, before returning SURROUND MODE after change as EVENT, the present SURROUND MODE is returned.

H) The RESPONSE should be sent as opposed to the request command by all the commands with which an EVENT exists , not need to

the another request commands(ex. SV command).

I) The PARAMETER (with COMMAND and RESPONSE, EVENT) of minimum level of MASTER VOLUME defines “99”.

J) If the MASTER VOLUME & CHANNEL VOLUME set with 0.5dB step, the PARAMETER (with COMMAND and RESPONSE, EVENT) defines three

ASCII characters as bellows.

ex. MASTER VOLUME = +1.0dB : MV81<CR>

+0.5dB : MV805<CR>

0dB : MV80<CR>

-0.5dB : MV795<CR>

-1.0dB : MV79<CR>

| |

-79.5dB : MV005<CR>

-80.0dB : MV00<CR>

--- : MV99<CR>

* At the **.0dB step, only uses two ASCII characters as PARAMETER, same as usual.

K) Four seconds later, please transmit the next COMMAND after transmitting a power on COMMAND（PWON).

06.April.06

7/28

COMMAND and PARAMETER list

COMMAND PARAMETER function example

PW ON POWER ON/STANDBY change PWON<CR>

STANDBY PWSTANDBY<CR>

? Request PW Status PW?<CR>

MV UP MASTER VOLUME UP/DOWN , direct change to **dB MVUP<CR>

DOWN MVDOWN<CR>

** **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) MV80<CR>

? Request MV Status MV?<CR>

CV FL UP CHANNEL VOLUME UP/DOWN , direct change to **dB CVFL UP<CR>

FL DOWN ---FRONT Lch CVFL DOWN<CR>

FL ** **:38 to 62 by ASCII , 50=0dB CVFL 50<CR>

FR UP CVFR UP<CR>

FR DOWN ---FRONT Rch CVFR DOWN<CR>

FR ** **:38 to 62 by ASCII , 50=0dB CVFR 50<CR>

C UP CVC UP<CR>

C DOWN ---CENTERch CVC DOWN<CR>

C ** **:38 to 62 by ASCII , 50=0dB CVC 50<CR>

SW UP CVSW UP<CR>

SW DOWN ---SUBWOOFERch CVSW DOWN<CR>

SW ** **:00,38 to 62 by ASCII , 50=0dB,00=OFF CVSW 50<CR>

SL UP CVSL UP<CR>

SL DOWN ---SURROUND Lch CVSL DOWN<CR>

SL ** **:38 to 62 by ASCII , 50=0dB CVSL 50<CR>

SR UP CVSR UP<CR>

SR DOWN ---SURROUND Rch CVSR DOWN<CR>

SR ** **:38 to 62 by ASCII , 50=0dB CVSR 50<CR>

SBL UP ---SURROUND BACK Lch (SBch 2SP) CVSBL UP<CR>

SBL DOWN CVSBL DOWN<CR>

SBL ** **:38 to 62 by ASCII , 50=0dB CVSBL 50<CR>

SBR UP ---SURROUND BACK Rch (SBch 2SP) CVSBR UP<CR>

SBR DOWN CVSBR DOWN<CR>

SBR ** **:38 to 62 by ASCII , 50=0dB CVSBR 50<CR>

MV , CV COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)

06.April.06

8/28

COMMAND PARAMETER function example

CV SB UP ---SURROUND BACKch (SBch 1SP) CVSB UP<CR>

SB DOWN CVSB DOWN<CR>

SB ** **:00 to 99 by ASCII , 50=0dB CVSB 50<CR>

? Request CV Status CV?<CR>

MU ON OUTPUT MUTE ON/OFF change MUON<CR>

OFF MUOFF<CR>

? Request MU Status MU?<CR>

SI PHONO Select INPUT source SIPHONO<CR>

CD SICD<CR>

TUNER SITUNER<CR>

DVD SIDVD<CR>

VDP SIVDP<CR>

TV SITV<CR>

DBS SIDBS<CR>

VCR-1 SIVCR-1<CR>

VCR-2 SIVCR-2<CR>

VCR-3 ---Invalid at AVR-4306 SIVCR-3<CR>

V.AUX SIV.AUX<CR>

CDR/TAPE SICDR/TAPE<CR>

AUXNET SIAUXNET<CR>

AUXIPOD SIAUXOPOD<CR>

? Request SI Status SI?<CR>

ZM ON MAIN-ZONE ON/OFF change at AVR-4306 ZMON<CR>

OFF ZMOFF<CR>

? Request ZM Status ZM?<CR>

Z2 PHONO MULTI ZONE-2 mode set , and select source at AVR-4306 Z2PHONO<CR>

| ---The name of PARAMETER is |

AUXIPOD the same as that of the time of SI COMMAND. Z2AUXIPOD<CR>

SOURCE MULTI ZONE-2 mode cancel at AVR-4306 Z2SOURCE<CR>

CV , Z2 COMMAND : "*" parameter uses two ASCII characters. (see page4 J) section)

06.April.06

9/28

COMMAND PARAMETER function example

Z2 UP MULTI ZONE-2 VOLUME UP/DOWN , direct change to **dB Z2UP<CR>

DOWN at AVR-4306 Z2DOWN<CR>

** **:10 to 99 by ASCII , 80=0dB, 99=---(MIN) Z280<CR>

ON MULTI ZONE-2 ON/OFF change at AVR-4306 Z2ON<CR>

OFF Z2OFF<CR>

? Request Z2 Status Z2?<CR>

Z2MU ON ZONE2 OUTPUT MUTE ON/OFF change Z2MUON<CR>

OFF Z2MUOFF<CR>

? Request Z2MU Status Z2MU?<CR>

Z3 PHONO MULTI ZONE-3 mode set , and select source at AVR-4306 Z3PHONO<CR>

| ---The name of PARAMETER is |

AUXIPOD the same as that of the time of SI COMMAND. Z3AUXIPOD<CR>

SOURCE MULTI ZONE-3 mode cancel Z3SOURCE<CR>

UP MULTI ZONE-3 VOLUME UP/DOWN , direct change to **dB Z3UP<CR>

DOWN Z3DOWN<CR>

** **:10 to 99 by ASCII , 80=0dB, 99=---(MIN) Z380<CR>

ON MULTI ZONE-3 ON/OFF change at AVR-4306 Z3ON<CR>

OFF Z3OFF<CR>

? Request Z3 Status Z2?<CR>

Z3MU ON ZONE3 OUTPUT MUTE ON/OFF change Z3MUON<CR>

OFF Z3MUOFF<CR>

? Request Z3MU Status Z3MU?<CR>

SR PHONO REC SELECT mode set , and select source SRPHONO<CR>

| ---The name of PARAMETER is |

AUXIPOD the same as that of the time of SI COMMAND. SRAUXIPOD<CR>

SOURCE REC SELECT mode cancel SRSOURCE<CR>

? Request SR Status SR?<CR>

Z3 COMMAND : "*" parameter uses two ASCII characters. (see page4 J) section)

06.April.06

10/28

COMMAND PARAMETER function example

SD AUTO set DIGITAL INPUT AUTO mode SDAUTO<CR>

PCM set DIGITAL INPUT force PCM mode SDPCM<CR>

DTS set DIGITAL INPUT force DTS mode SDDTS<CR>

ANALOG set force ANALOG INPUT mode SDANALOG<CR>

EXT.IN-1 ---Set EXT.IN mode at AVR-4306 SDEXT.IN-1<CR>

EXT.IN-2 ---Invalid at AVR-4306 SDEXT.IN-2<CR>

? Request SD Status SD?<CR>

SV DVD VIDEO SELECT mode set , and select source SVDVD<CR>

VDP SVVDP<CR>

TV SVTV<CR>

DBS SVDBS<CR>

VCR-1 SVVCR-1<CR>

VCR-2 SVVCR-2<CR>

VCR-3 ---Invalid at AVR-4306 SVVCR-3<CR>

V.AUX SVV.AUX<CR>

AUXIPOD SVAUXIPOD<CR>

SOURCE VIDEO SELECT mode cancel SVSOURCE<CR>

? Request SV Status SV?<CR>

MS DIRECT SURROUND mode set MSDIRECT<CR>

PURE DIRECT MSPURE DIRECT<CR>

STEREO MSSTEREO<CR>

MULTI CH IN ---This is received as "SATNDARD". MSMULTI CH IN<CR>

MULTI CH DIRECT MSMULTI CH DIRECT<CR>

MULTI CH PURE D MSMULTI CH PURE D<CR>

DOLBY PRO LOGIC All are received as "STANDARD" , MSDOLBY PRO LOGIC<CR>

DOLBY PL2 the surround mode which changed return as EVENT. MSDOLBY PL2<CR>

DOLBY PL2x MSDOLBY PL2X<CR>

DOLBY DIGITAL MSDOLBY DIGITAL<CR>

DOLBY D EX MSDOLBY D EX<CR>

DTS NEO:6 All are received as "DTS SURROUND" , MSDTS NEO:6<CR>

DTS SURROUND MSDTS SURROUND<CR>

DTS ES DSCRT6.1 MSDTS ES DSCRT6.1<CR>

DTS ES MTRX6.1 MSDTS ES MTRX6.1<CR>

Autres manuels pour MULTEQXT AVR-4306

Ce manuel convient aux modèles suivants

Autres manuels Denon Récepteur

Denon

Denon AVR-X6500H Manuel utilisateur

Denon

Denon AVR-888 Guide de l'administrateur

Denon

Denon AVR-X4200W Manuel utilisateur

Denon

Denon AVR-1709 Manuel utilisateur

Denon

Denon AVR-4308CI Manuel d'utilisation et d'entretien

Denon

Denon AVRX6500HBKE3 Manuel utilisateur

Denon

Denon AVR-X520BT Manuel utilisateur

Denon

Denon DN-202WR Manuel utilisateur

Denon

Denon AVR-1610 Manuel utilisateur

Denon

Denon AV Surround Receiver AVR-5803 Manuel utilisateur

Denon

Denon DRA-100 Manuel utilisateur

Denon

Denon AVR 4308CI - AV Network Receiver Manuel utilisateur

Denon

Denon AVR 2808CI - AV Receiver Manuel utilisateur

Denon

Denon ADV-700 Manuel utilisateur

Denon

Denon DRA-365R Manuel utilisateur

Denon

Denon AVR-3805 Manuel utilisateur

Denon

Denon AVR-887BKE3 Manuel utilisateur

Denon

Denon AirPlay AVR-3311CI Manuel de la liste des pièces

Denon

Denon Ceol Piccolo DRA-N4 Manuel utilisateur

Denon

Denon ADV-M51 Manuel utilisateur

Denon

Denon DRA-100 Manuel utilisateur

Denon

Denon AVR-E200 Manuel utilisateur

Denon

Denon AVR-X2200W Manuel utilisateur

Denon

Denon AVR 589 - AV Receiver Dimensions

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
