Denon DCD-900NE Manuel utilisateur

DCD-900NE

COMPACT DISC PLAYER

Owner’s Manual

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Accessories 4

Inserting the batteries 5

Operating range of the remote control unit 5

Part names and functions 6

Front panel 6

Display 8

Rear panel 9

Remote control unit 10

Connections

Connecting an amplifier 16

Connecting to a device with digital audio input connectors 17

Connecting a USB flash drive to the USB port 18

Connecting an external control device 19

Connecting the timer device 20

Connecting the power cord 21

Playback

Basic operation 23

Turning the power on 23

Switching the power to standby 23

Selecting the playback media mode 24

Switching the display’s brightness 24

Switching the pure direct mode 25

Playing CDs 26

Playing tracks in a specific order (Program playback) 28

Playing DATA CDs 29

Playing files 30

Playing a USB flash drive 32

Playing files stored on USB flash drives 33

Using the timer play function 35

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Settings

Setting the Auto Standby mode 36

Tips

Tips 38

Troubleshooting 39

Power does not turn on / Power is turned off 40

Operations cannot be performed through the remote control unit 41

Display on this unit shows nothing 41

No sound comes out 42

Sound is interrupted or noise occurs 42

Cannot playback Discs 43

USB flash drives cannot be played back 44

Appendix

Playing back Discs 45

Files 45

Playing back a USB flash drives 47

Playback order of music files 48

About folders and files 49

Cautions on using media 50

Loading discs 50

How to handle media 51

Cleaning discs 51

Explanation of terms 52

Specifications 55

Index 58

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Quick Start Guide Safety Instructions Cautions on Using Batteries Power cord

Remote control unit

(RC-1246)

2× R03/AAA batteries Audio cable

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear cover back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

Approx. 7 m

30°30°

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Part names and functions

Front panel

r t y uwq e

For details, see the next page.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

r t y uewq

APower operation button (X)

This turns the power on/off (standby). (v p. 23)

BPower indicator

This is lit as follows according to the power status:

0Power on : Green

0Standby : Off

CDisc tray

Used to insert a disc.

DPlay/Pause button (1/3)

Plays the track/Pauses the track.

EStop button (2)

Stops playback.

FReverse-skip button (8)

Returns to the start of the currently playing track.

GForward-skip button (9)

Plays the next track.

HUSB port (T)

This is used to connect USB storages (such as USB flash drives).

(v p. 18)

IRemote control sensor

This receives signals from the remote control unit. (v p. 5)

JDisplay

Various information is displayed here. (v p. 8)

KDisc tray open/close button (5)

Used to open/close the disc tray.

LSOURCE button

Select the media to play back. (v p. 24)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Display

wq tu

er y

AInformation display

Displays various information or playback elapsed time and so on of the

disc.

BPlayback mode indicators

1 : Lights up during playback.

3 : Lights up during pause.

CTOTAL indicator

Lights when the total number of tracks and total time of the CD are

displayed.

DRANDOM indicator

Lights during random playback.

ERepeat mode indicators

Lights to match the repeat mode settings.

FFolder mode indicator

0Lights up when the folder mode is set in the playback range of the

CD-R/CD-RW. (v p. 31)

0Lights up when the folder mode is set in the playback range of the

USB flash drive. (v p. 34)

GRemote control signal reception indicator

Lights when a signal is received from the remote control.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Rear panel

rq w e

AAUDIO OUT connectors

Used to connect devices equipped with analog audio inputs connectors

or an external amplifier. (v p. 16)

BDIGITAL AUDIO OUT connectors (COAXIAL/OPTICAL)

Used to connect an amplifier or D/A converter that has a digital input

connectors. (v p. 17)

CIR CONTROL connectors

Used to connect infrared receivers/transmitters in order to operate this

unit and external devices. (v p. 19)

DAC inlet (AC IN)

Used to connect the power cord. (v p. 21)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Remote control unit

The remote control provided with this unit can control a Denon integrated

network amplifier.

0“Integrated network amplifier operations” (v p. 13)

oOperating this unit

To operate this unit, press REMOTE MODE CD button to switch the

remote control operating mode to this unit.

ARemote control signal transmitter

This transmits signals from the remote control unit. (v p. 5)

BPower operation button (CD POWER X)

This turns the power on/off (standby). (v p. 23)

CRemote mode select button

(REMOTE MODE CD)

This switches the remote control operating mode to CD player.

DSystem buttons

These perform playback related operations.

ESOURCE button

Select the media to play back. (v p. 24)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index
