Denon DCD-800NE Manuel utilisateur

DCD-800NE

COMPACT DISC PLAYER

Owner’s Manual

You can print more than one page of a PDF onto a single sheet of paper.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Accessories 4

Inserting the batteries 5

Operating range of the remote control unit 5

Features 6

High quality sound 6

High performance 6

Part names and functions 7

Front panel 7

Display 9

Rear panel 10

Remote control unit 11

Connections

Connecting an amplifier 18

Connecting to a device with digital audio input connectors 19

Connecting a USB memory device to the USB port 20

Connecting the timer device 21

Connecting the power cord 22

Playback

Basic operation 24

Turning the power on 24

Switching the power to standby 24

Selecting the media mode 25

Switching the display’s brightness 25

Switching the Pure Direct mode 26

Playing CDs 27

Playing tracks in a specific order (Program playback) 29

Playing DATA CDs 30

Playing files 31

Playing a USB memory device 33

Playing files stored on USB memory devices 34

Using the timer play function 36

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Settings

Setting the Auto Standby mode 37

Turning Auto Standby mode off 37

Turning Auto Standby mode on 37

Tips

Tips 39

Troubleshooting 40

Power does not turn on / Power is turned off 41

Operations cannot be performed through the remote control unit 42

Display on this unit shows nothing 42

No sound comes out 43

Sound is interrupted or noise occurs 43

Cannot playback Discs 44

Appendix

Playing back Discs 45

Files 45

Playing back a USB memory devices 47

Playback order of files 49

About folders and files 49

Cautions on using media 50

Loading discs 50

How to handle media 51

Cleaning discs 51

Explanation of terms 52

Trademark information 54

Specifications 55

Index 58

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Audio cable

Quick Start Guide CD-ROM

(Owner’s Manual)

Safety Instructions

R03/AAA batteries

Remote control unit

(RC-1223)

Cautions on Using Batteries

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear cover back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

Approx. 7 m

30°30°

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Features

High quality sound

0High Bitrate and High Sampling with Advanced AL32 Processing

Plus

A high bitrate and high sampling has been achieved with Denon’s

unique data interpolation algorithm. 16 bit audio signals are converted

to a high bitrate of 32 bit and 44.1 kHz sampling signals are up-sampled

by 16x to achieve smoother recreation of sound waves. Data

interpolation is also used, predicting interpolation points from a large

number of surrounding points to provide audio as close as possible to

the original sound. This elaborate restoration of data lost during digital

recording achieves fine, distortion-free rendering, accurate sound

localizing, rich bass and recreation that is faithful to the original sound.

0DAC Master Clock Design for the Ideal Clock

To make full use of the properties of this unit’s semiconductor, it was

important to use a highly accurate clock signal for the semiconductor’s

operations. This model contains 2 oscillators, one for each frequency.

These oscillators are developed to dramatically decrease phase noise

caused by frequency displacement, achieving a more stable and more

accurate clock than ever before. The master clock is near the D/A

converter, reducing jittering to achieve faithful playback.

High performance

0Supports MP3 and WMA file playback (v p. 30)

MP3 and WMA files that have been recorded onto CD-R or CD-RW

discs can be played back on this CD player.

0Plays USB memory devices (MP3/WMA/AAC/WAV/FLAC/Apple

Lossless/AIFF/DSD).

You can play back audio files stored on a USB memory device by

connecting the USB memory device to the USB port.

0Reduced power consumption during standby

The power consumption in standby mode has been reduced to below

0.2 W in consideration of the environment.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Part names and functions

Front panel

r t y uwq e

APower operation button (X)

This turns the power on/off. (v p. 24)

BPower indicator

This is lit as follows according to the power status:

0Power on : Green

0Standby : Off

0Power off : Off

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

r t y ue

CDisc tray

Used to insert a disc.

DPlay/pause button (1/3)

Plays the track/Pauses the track.

EStop button (2)

Stops playback.

FReverse-skip button (8)

Returns to the start of the currently playing track.

GForward-skip button (9)

Plays the next track.

HUSB port (T)

This is used to connect USB storages (such as USB memory devices).

(v p. 20)

IRemote control sensor

This receives signals from the remote control unit. (v p. 5)

JDisplay

Various information is displayed here. (v p. 9)

KDisc tray open/close button (5)

Used to open/close the disc tray.

LSOURCE button

Select the media to play back. (v p. 25)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Display

wq ty

AInformation display

Displays various information or playback elapsed time and so on of the

disc.

BPlayback mode indicators

1 : Lights up during playback.

3 : Lights up during pause.

CTOTAL indicator

Lights when the total number of tracks and total time of the CD are

displayed.

DRANDOM indicator

Lights during random playback.

ERepeat mode indicators

Lights to match the repeat mode settings.

FRemote control signal reception indicator

Lights when a signal is received from the remote control.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Rear panel

rq w e

AAUDIO OUT connectors

Used to connect devices equipped with analog audio inputs connectors

or an external power amplifier. (v p. 18)

BDIGITAL AUDIO OUT connectors

Used to connect an AV receiver or D/A converter that has a digital input

connectors. (v p. 19)

CIR CONTROL connectors

Used to connect Denon network audio players with an IR controller.

DPower cord (v p. 22)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index
