Demon Powersport OUTLAW Manuel utilisateur
1
First of all, we would like to thank you for
choosing the OUTLAW electric bike.
We warmly welcome you to our Demon
Powersports family. We wish you enjoy the
numerous kilometers and happy moments with
your new bike.
After the initial shipment we have made many
improvements and modifications for the
OUTLAW including:
*Suspended seat post - Takes the shock out of the big
bumps, without the cost or complexity of suspension.
*Adjustable handlebar stem- Provides up to 1 1/2” of
rise and reach adjustment, for fully customizable riding
position.
*Upgraded Shimano derailleur- Rigid cast aluminum
construction gives smoother, more precise shifting.
*New gearing, with taller top gear for relaxed touring,
plus a lower low gear for tight, technical riding.
2
Welcome 1
Important 3
Contact Us 3
Assembly Instructions 4
Parts 4
Kickstand 4
Handle bar 4
Pedal 5
Wheel 5
Battery Charging 7
Tips 7
Operation 7
Display 8
Button Definition 9
Meter Programming and Use 11
Error Code Definition 17
Warning and Safety 18
3
IMPORTANT
Electric Bikes can be dangerous to use. The user or
consumer assumes all risk of personal injuries, damage,
or failure of the bicycle or system and all other losses or
damages to themselves and others and to any property
arising as a result of using the bicycle.
As with all mechanical components, the bicycle is subjected
to wear and high stresses. Different materials and
components may react to wear or stress fatigue in
different ways.
If the design life of a component has been exceeded, it may
suddenly fail possibly causing injuries to the rider. Any form
of crack, scratches or change of coloring in highly stressed
areas indicate that the life of the component has been
reached and it should be replaced.
Please do not hesitate to contact us. If any problems may
occur, please email us at cus[email protected] for
any customer service solutions such as replacement parts,
technical information, and any other issues.
For any other commercial or general inquires please
contact Demon Powersports at 905 475 8383 or
Email us at [email protected]
PLEASE NOTE: THIS MANUAL IS NOT INTENDED
AS A DETAILED USER, SERVICE, REPAIR OR
MAINTENANCE MANUAL. PLEASE SEEK
ASSISTANCE FROM A QUALIFIED TECHNICIAN
FOR SERVICE, REPAIRS OR MAINTENANCE.
DO NOT DISASSEMBLE, MODIFY OR
REPLACE ELECTRICAL PARTS.
4
ASSEMBLY
INSTRUCTIONS
Your bike has been pre-assembled and requires
only a few simple steps to get it ready for you to
ride:
1) Remove the outside carton after cutting the nylon
bands. Remove all the inside cardboard
protection and bubble wrap. Carefully remove
your bike from the carton and gently rest it in
place. Be careful not to cut any wires when
cutting the zip ties.
2) Ensure the following pieces are included in the
package. If there are any missing parts, please
contact Demon for help replacing missing pieces.
i) Bike
ii) Pedals
iii) Charger
iv) Key for battery pack (usually attached with
plastic tie either on the handlebar or on the
battery)
v) Assembly Tools
3) Install kickstand with the 5mm Allen key
4) Align the stem with the front wheel and tighten the
top stem bolt with 5mm Allen key enough to hold
the stem in place.
Once the handlebars are aligned and the top bolts
is slightly secured, firmly tighten the 2 side bolts
with 5mm Allen key on the stem.
5
After tightening the 2 side bolts, firmly tighten the
top bolt. After all 3 bolts have been securely
fastened, make sure there is no play in the headset
by tighten the 4 pinch screws with 4mm Allen key.
Loctite is recommend on the screw Align the brake
controls so they are facing slightly downward. Fine
tune the position to align with your arm when
seated, stem rise angle can be adjusted by loosen the
big side screw with 6mm Allen key
5) Remove the plastic protector from the fork, insert
the axle through the wheel following the orientation
in the image and Install the front wheel on the front
fork, and make sure to align the brake disk with the
Brake caliper, then fasten the wheel hub using the
quick release handle.
6) Install the headlight to the front fork with the given
long bolt and nut, tighten with the 5mm Allen key
and 10mm wrench
6
7) Using the 15mm wrench provided in the toolkit,
attach, and tighten the pedals. PLEASE NOTE – The
pedals are marked “L” for Left and “R” for Right. The
left pedal is attached by turning it counter clockwise
and the right pedal is tightened by turning it
clockwise. Make sure the pedals are tightly attached
to the crank arms to prevent stripping.
(See picture below)
8) Make sure the seat is tight enough so that you
cannot twist it out of alignment. Pull the seat clamp
handle away from the seat post and slide the seat up
or down to adjust it. Move the clamp handle inward
toward the seat post so it is held tight by the clamp.
Important! Be sure the minimum insertion marks
do not go past the top of the seat clamp and are
not visible.
7
BATTERY CHARGING
Included with your new OUTLAW is a lithium ion battery,
along with a charger, which plugs into a standard
household electric receptacle. A lithium ion battery
requires specially designed chargers. You should never
charge your battery with a substitute charger that is not
designed for this use.
Your OUTLAW battery arrives with 70% charge. It is
recommended that you fully charge the battery before your
first use. The OUTLAW battery may be charged while on the
bike or removed and charged at a location away from the
OUTLAW. To charge the battery please follow the steps
below:
- Remove the rubber cover on the charging socket
- Place the charger in a flat, secure place, and
connect the DC output plug from the charger
(round barrel connector) to the charging port on
the side of the battery pack.
- The indicator light on the charger will be red /
orange when battery is charging and will turn
green when fully charged.
The charger will charge a fully depleted battery in 3— 4
hours. If the battery will not be used for an extended
period of time, charge it fully and recharge it every 2
months. Store it in a cool, dry place. If you
experience unusual sounds or odors coming from the
charger or the battery, unplug charger immediately and
contact Demon Powersports customer service.
BATTERY CHARGING TIPS
- Recharge battery after every use. This will keep
the battery in good shape for longer time.
- Do not allow any liquids near or inside the battery
charger.
- Do not charge the battery with any other chargers
then what was originally supplied with your
OUTLAW
- Fully charge the battery before each use to extend
the life of the battery and help to reduce the
chance of over discharging the battery pack.
- Do not place the battery near fire or corrosive
substances.
OPERATION
Your OUTLAW is equipped with an LCD meter that
monitors pedal assist, speed, odometer, trip distance,
riding time, and battery energy level. To turn the meter
on, make sure the battery is fully inserted into the
OUTLAW battery holder.
8
DISPLAY
9
Button definition
Normal operation
10
Switch between Distance Mode and Speed Mode
Briefly press (0.5s) to switch the display between the
distance and speed, cycle show signal-trip distance (TRIP) →
total distance (ODO) → maximum speed (MAX) → average
speed (AVG) → remaining distance (RANGE) → energy
consumption (CALORIES) → time (TIME). Energy
consumption unit CALORIES means kCal.
Headlight / Display Backlight Switch
Press and hold (>2S) to turn on the display backlight as
well as headlight. Press and hold (>2S) again to turn off
the display backlight and the headlight. There are 5 levels
of backlight brightness that can be selected by the user
(can be set in the “Brightness”). (If the display is turned on
in a dark environment, the display backlight/ headlight will
be turned on automatically. If the display
backlight/headlight are turned off manually, they also need
to be turned on manually afterwards)
