4.2. Nastavenie parametrov
Príprava pre zadanie hodnôt
Ak je displej akvny, stlačte dvakrát tlačidlo režimu v
intervale pod 0.3 sekundy. Systém vstúpi do MENU za-
dávania parametrov, kde sa dajú vložiť parametrami. Ak
tlačidlo opätovne dvakrát stlačíte vo vyššie uvedenom in-
tervale, vráte sa do hlavnej ponuky. Ak počas 10 sekúnd
nie je vykonaná žiadna operácia, vrá sa systém do vý-
chodiskovej ponuky sám. Ak v režime zadania parametrov
začne blikať požadovaný údaj, použite tlačidlá + a - pre
úpravu hodnoty. Krátko stlačte pre prepínanie medzi
parametrami. Stlačte toto tlačidlo dvakrát (interval <0.3
sekundy) pre opustenie čiastkovej ponuky.
Reset dát
Stlačte dvakrát tlačidlo režimu (interval <0.3 sekundy)
pre vstup do MENU. V rýchlostnej zložke sa zobrazí tC.
Po stlačení sa zobrazí ež “y”. Teraz môžu byť všetky do-
časné údaje, tz. max. rýchlosť (MAXS), priem. rýchlosť
(AVG) a čiastková vzdialenosť (TRIP) vymazaná. Krátko
stlačte tlačidlo režimu (<0.3 sekundy) pre vstup do
nastavenia km/mile. Pokiaľ nedôjde k resetu dát, bude
čiastková vzdialenosť a celkový jazdný čas zmazaný, ak
celkový jazdný čas presiahne limit 99 hod. a 59 minút.
Údaje sa nevymažú, ak je systém reakcie svetelnej sen-
zivity prepnutý na 0 alebo ak je úplne vypnutý.
Km/Mile
Ak rýchlostné zobrazenie ukazuje S7, slúži tlačidla + a -
na prepínanie medzi km/h a mph. Dajú sa teda nastaviť
kilometre alebo míle. Po nastavení krátko zatlačte tla-
čidlo režimu (<0.3 sekundy) pre vstup do nastavenia
svetelnej citlivos.
Svetelná citlivosť
Ak rýchlostné okienko zobrazuje bL0, použijte tlačidla
+/- pre voľbu úrovne od 0 do 5. Čím vyššia úroveň, tým
citlivejšie svetlo. Po nastavení krátko zatlačte tlačidlo
režimu (<0.3 sekundy) pre vstup do nastavenia jasu
podsvietenia.
Miera podsvietenia displeja
Ak rýchlostné okienko zobrazuje bL1, vyberte tlačidlami
+/- úroveň od 1 do 5. Pričom úroveň 1 znamená najnižší
jas a úroveň 5 ten najvyšší. Po nastavení krátko stlačte
tlačidlo režimu (<0.3 sekúnd) pre zadanie času automa-
ckého vypnua.
Čas automackého vypnua
Ak rýchlostné okienko zobrazuje OFF, vyberte tlačidla-
mi +/- rozsah od 1 do 9. Čísla zodpovedajú počtu mi-
nút do automackého vypnua. Potom krátko stlačte
tlačidlo režimu (<0.3 sekundy) pre zadanie varovnej
údržbovej hlášky.
Varovná hláška údržby
Ak rýchlostné okienko zobrazuje nnA, zadajte tlačidlami
+/- buď 0 alebo 1. Hodnota „0“ funkciu deakvuje, za-
aľ čo hodnota „1“ ju akvuje. Displej potom upozorní
používateľa na nutnosť vykonania údržby v závislos na
prejdenej vzdialenos a počtu nabíjacích cyklov batérie.
Ak hodnota celkovej prejdenej vzdialenos presiahne li-
mit 5 000 km (hodnotu môže výrobca pozmeniť), zobrazí
displej nápis SERVICE. Po spustení displeja bude znak
celkovej vzdialenos blikať po dobu štyroch sekúnd, aby upozornil na nutnosť servisnej údrž-
by. Ak hodnota nabíjacích cyklov batérie presiahne 100 (limit môže byť zmenený výrobcom), disp-
lej zobrazí nápis SERVICE. Po spustení displeja bude symbol batérie blikať po dobu 4 sekúnd ako
upozornenie nutnos servisnej kontroly. Funkcia údržbovej výstrahy sa dá deakvovať týmto spô-
sobom: sengs – maintenance alert (MA) – 0. Táto funkcia sa ež dá nastaviť počítačom cez USB.
Preverenie priemeru kolesa
Rýchlostný ukazovateľ zobrazuje Wd. Jednotkou merania sú palce. Zlý rozmer
kolesa môže viesť k nepresnosam v meraní. Po zadaní stlačte krátko tlačidlo
režimu (<0.3 sekundy) pre nastavenie rýchlostného limitu.
Nastavenie rýchlostného limitu
Ak rýchlostné okienko zobrazuje SPL, potom vzdialenostné okienko zobra-
zuje rýchlostný limit. Min. rýchlostný limit je 12 km/h a max. potom je 60
km/h. Po nastavení krátko stlačte tlačidlo režimu (<0.3 sekundy) pre vstup
do menu batérie.
Údaje ohľadom batérie
Rýchlostné okienko zobrazuje b01 a vzdialenostné okienko zobrazuje rých-
lostný limit. Stlačte tlačidlo režimu (<0.3 sekundy) pre listovanie v postu-
pových cykloch pospiatky. Po vložení tlačidlo opäť stlačte pre vstup do ro-
zhrania pamäťových chybových hlášok. Dané údaje sa budú zobrazovať iba
vtedy, ak je bezchybná komunikácia medzi batériou a ovládačom. Inak sa
zobrazí iba ---. Údaje k batérii nájdete v tabuľke nižšie.
Kód Popis Jednotka Kód Popis Jednotka
b01 Aktuálna teplota °C b11 Nabíjacie/Vybíjacie cykly
b04 Celkové napäe V b12 Najdlhší interval bez nabia h
b06 Priemerná prúdová hodnota A b13 Doba od posledného nabia H
b07 Zostávajúca kapacita Ah d00 Počet segmentov
b08 Celková kapacita Ah d01 Napäe segmentu 1 V
b09 Relavny stav nabia d02 Napäe segmentu 2 V
b10 Absolútny stav nabia dn Napäe segmentu n V
10 DISPLAY MANUAL DP C10.UART
PARAMETER SETTING
•Items to be Set
1 〉Data reset
2 〉Km/mile
3 〉Light sensitivity
4 〉Display backlight brightness
5 〉Automatic off time
6 〉Maintenance warning settings
7 〉Check wheel diameter
8 〉Speed Limit Setting
9 〉Speed model
10 〉Battery infromation10 error code
•Setting Preparation
1) When the display is active, press
twice (interval < 0.3 seconds). The system
will enter the MENU parameter setting
state, in which the display parameters can
be set. Press twice again (interval < 0.3
seconds) to return to the main menu.
2) If no operation is performed for 10 sec-
onds, the display will return to the normal
riding display.
3) In the parameter setting state, when the
parameter you want to set begins to ash,
press / to adjust the parameter value.
Briey press to switch between the pa-
rameters to be set. Press twice (interval
< 0.3 seconds) to exit the submenu.
•Data reset
Press twice (interval < 0.3 seconds) –
the display enters the MENU state. In the
speed eld tC is displayed. If you press ,
a "y" is also displayed. Now all temporary
data, e.g. maximum speed (MAXS), average
speed (AVG) and single trip distance (TRIP)
can be cleared. Briey press (< 0.3 sec-
onds) to enter the km/mile setting interface.
If the user does not reset the data, the single
trip distance and the accumulated total rid-
ing time will be automatically cleared when
the accumulated total riding time exceeds
99 hours and 59 minutes.
* The data will not be cleared when the
display’s light-sensing function is set to 0 or
when it is switched off!
•Km/mile
When the speed eld displays S7, press
/ to switch between km/h and mph, or
to set km or mile. After this setting, briey
press (< 0.3 seconds) to enter the
setting interface of light sensitivity. Default
display is km.
•Light Sensitivity
When the speed eld displays bL0, press
/ to choose a gure between 0 and 5.
The higher the chosen gure, the higher the
light sensitivity.
10 DISPLAY MANUAL DP C10.UART
PARAMETER SETTING
•Items to be Set
1 〉Data reset
2 〉Km/mile
3 〉Light sensitivity
4 〉Display backlight brightness
5 〉Automatic off time
6 〉Maintenance warning settings
7 〉Check wheel diameter
8 〉Speed Limit Setting
9 〉Speed model
10 〉Battery infromation10 error code
•Setting Preparation
1) When the display is active, press
twice (interval < 0.3 seconds). The system
will enter the MENU parameter setting
state, in which the display parameters can
be set. Press twice again (interval < 0.3
seconds) to return to the main menu.
2) If no operation is performed for 10 sec-
onds, the display will return to the normal
riding display.
3) In the parameter setting state, when the
parameter you want to set begins to ash,
press / to adjust the parameter value.
Briey press to switch between the pa-
rameters to be set. Press twice (interval
< 0.3 seconds) to exit the submenu.
•Data reset
Press twice (interval < 0.3 seconds) –
the display enters the MENU state. In the
speed eld tC is displayed. If you press ,
a "y" is also displayed. Now all temporary
data, e.g. maximum speed (MAXS), average
speed (AVG) and single trip distance (TRIP)
can be cleared. Briey press (< 0.3 sec-
onds) to enter the km/mile setting interface.
If the user does not reset the data, the single
trip distance and the accumulated total rid-
ing time will be automatically cleared when
the accumulated total riding time exceeds
99 hours and 59 minutes.
* The data will not be cleared when the
display’s light-sensing function is set to 0 or
when it is switched off!
•Km/mile
When the speed eld displays S7, press
/ to switch between km/h and mph, or
to set km or mile. After this setting, briey
press (< 0.3 seconds) to enter the
setting interface of light sensitivity. Default
display is km.
•Light Sensitivity
When the speed eld displays bL0, press
/ to choose a gure between 0 and 5.
The higher the chosen gure, the higher the
light sensitivity.
10 DISPLAY MANUAL DP C10.UART
PARAMETER SETTING
•Items to be Set
1 〉Data reset
2 〉Km/mile
3 〉Light sensitivity
4 〉Display backlight brightness
5 〉Automatic off time
6 〉Maintenance warning settings
7 〉Check wheel diameter
8 〉Speed Limit Setting
9 〉Speed model
10 〉Battery infromation10 error code
•Setting Preparation
1) When the display is active, press
twice (interval < 0.3 seconds). The system
will enter the MENU parameter setting
state, in which the display parameters can
be set. Press twice again (interval < 0.3
seconds) to return to the main menu.
2) If no operation is performed for 10 sec-
onds, the display will return to the normal
riding display.
3) In the parameter setting state, when the
parameter you want to set begins to ash,
press / to adjust the parameter value.
Briey press to switch between the pa-
rameters to be set. Press twice (interval
< 0.3 seconds) to exit the submenu.
•Data reset
Press twice (interval < 0.3 seconds) –
the display enters the MENU state. In the
speed eld tC is displayed. If you press ,
a "y" is also displayed. Now all temporary
data, e.g. maximum speed (MAXS), average
speed (AVG) and single trip distance (TRIP)
can be cleared. Briey press (< 0.3 sec-
onds) to enter the km/mile setting interface.
If the user does not reset the data, the single
trip distance and the accumulated total rid-
ing time will be automatically cleared when
the accumulated total riding time exceeds
99 hours and 59 minutes.
* The data will not be cleared when the
display’s light-sensing function is set to 0 or
when it is switched off!
•Km/mile
When the speed eld displays S7, press
/ to switch between km/h and mph, or
to set km or mile. After this setting, briey
press (< 0.3 seconds) to enter the
setting interface of light sensitivity. Default
display is km.
•Light Sensitivity
When the speed eld displays bL0, press
/ to choose a gure between 0 and 5.
The higher the chosen gure, the higher the
light sensitivity.
11
DISPLAY MANUAL DP C10.UART
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
backlight brightness.
•Display Backlight Brightness
When the speed eld displays bL1, press
/ to choose a gure between 1 and 5.
The gure 1 represents the lowest brightness
while 5 indicates the highest display back-
light brightness.
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
automatic off time.
•Automatic Off Time
When the speed eld displays OFF, press
/ to choose a gure between 1 and 9.
The gures indicate the minutes that it takes
to automatically shut down the display.
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
maintenance warning.
•Maintenance Warning (can be deacti-
vated)
When the speed eld displays nnA, press
/ to choose either 0 or 1. 0 disables the
function while 1 enables it.
1) The display will prompt maintenance
necessity based on such information as the
accumulated riding distance and the battery
charge cycles.
2) When the accumulated total riding dis-
tance exceeds 5,000 km (can be customized
by the manufacturer), the display will show
the symbol . When the display is
started up, the sign for accumulated riding
distance will ash for 4 seconds, indicating
that maintenance is necessary.
3) When the number of battery charge cy-
cles exceeds 100 (can be customized by the
manufacturer), the display will the symbol
. When the display is started up,
the sign for battery will ash for 4 seconds,
indicating that maintenance is necessary.
4) The maintenance alert function can be
disabled: settings ->maintenance alert (MA)
-> 0. (Maintenance alert can also be set via
a computer. This requires a USB connection.
See also the parameter setting instructions).
PARAMETER SETTING
11
DISPLAY MANUAL DP C10.UART
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
backlight brightness.
•Display Backlight Brightness
When the speed eld displays bL1, press
/ to choose a gure between 1 and 5.
The gure 1 represents the lowest brightness
while 5 indicates the highest display back-
light brightness.
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
automatic off time.
•Automatic Off Time
When the speed eld displays OFF, press
/ to choose a gure between 1 and 9.
The gures indicate the minutes that it takes
to automatically shut down the display.
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
maintenance warning.
•Maintenance Warning (can be deacti-
vated)
When the speed eld displays nnA, press
/ to choose either 0 or 1. 0 disables the
function while 1 enables it.
1) The display will prompt maintenance
necessity based on such information as the
accumulated riding distance and the battery
charge cycles.
2) When the accumulated total riding dis-
tance exceeds 5,000 km (can be customized
by the manufacturer), the display will show
the symbol . When the display is
started up, the sign for accumulated riding
distance will ash for 4 seconds, indicating
that maintenance is necessary.
3) When the number of battery charge cy-
cles exceeds 100 (can be customized by the
manufacturer), the display will the symbol
. When the display is started up,
the sign for battery will ash for 4 seconds,
indicating that maintenance is necessary.
4) The maintenance alert function can be
disabled: settings ->maintenance alert (MA)
-> 0. (Maintenance alert can also be set via
a computer. This requires a USB connection.
See also the parameter setting instructions).
PARAMETER SETTING
11
DISPLAY MANUAL DP C10.UART
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
backlight brightness.
•Display Backlight Brightness
When the speed eld displays bL1, press
/ to choose a gure between 1 and 5.
The gure 1 represents the lowest brightness
while 5 indicates the highest display back-
light brightness.
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
automatic off time.
•Automatic Off Time
When the speed eld displays OFF, press
/ to choose a gure between 1 and 9.
The gures indicate the minutes that it takes
to automatically shut down the display.
After this setting, briey press (< 0.3
seconds) to enter the setting interface of
maintenance warning.
•Maintenance Warning (can be deacti-
vated)
When the speed eld displays nnA, press
/ to choose either 0 or 1. 0 disables the
function while 1 enables it.
1) The display will prompt maintenance
necessity based on such information as the
accumulated riding distance and the battery
charge cycles.
2) When the accumulated total riding dis-
tance exceeds 5,000 km (can be customized
by the manufacturer), the display will show
the symbol . When the display is
started up, the sign for accumulated riding
distance will ash for 4 seconds, indicating
that maintenance is necessary.
3) When the number of battery charge cy-
cles exceeds 100 (can be customized by the
manufacturer), the display will the symbol
. When the display is started up,
the sign for battery will ash for 4 seconds,
indicating that maintenance is necessary.
4) The maintenance alert function can be
disabled: settings ->maintenance alert (MA)
-> 0. (Maintenance alert can also be set via
a computer. This requires a USB connection.
See also the parameter setting instructions).
PARAMETER SETTING
SK10 Návod na obsluhu a údržbu elektrobicykla
Návod na obsluhu a údržbu elektrobicykla
