The HDMI02DPX Camera Manual
Notes
1
To show the Camera Control Panel, move your mouse to the left of the video window. See Sec.5.2 for details
2
Move the mouse cursor to the top of the video window, a Measurement Toolbar will pop up for calibration and measurement operations.
When user left-clicks the Float/Fixed button on the Measurement Toolbar, the Measurement Toolbar will be fixed. In this case the
Camera Control Panel will not pop up automatically even if users move mouse cursor to left side of the video window. Only when user
left-clicks the button on the Measurement Toolbar to exit from measuring procedure will they be able to do other operations on the
Camera Control Panel, or the Synthesis Camera Control Toolbar. During the measuring process, when a specific measuring object is
selected, an Object Location & Attributes Control Bar will appear for changing location and
properties of the selected object. See Sec.7.3 for details
3
When users move mouse cursor to the bottom of the video window, the Synthesis Camera Control Toolbar will pop up automatically.
. See Sec.5.4 for details.
5.2 The Camera Control Panel on the Left Side of the Video Window
The Camera Control Panel controls the camera to achieve the best video or image quality according to the specific
applications; It will pop up automatically when the mouse cursor is moved to the left side of the video window. Left-
clicking button to achieve Display/Auto Hide switch of the Camera Control Panel.
Camera Control Panel
Function
Function
Description
Snap Capture image and save it to the SD card
Record Record video and save it to the SD card
Auto Exposure
When Auto Exposure is checked, the system will automatically adjust exposure time and
gain according to the value of exposure compensation
Available when Auto Exposure is checked. Slide to left or right to adjust Exposure
Compensation
according
to
the
current
video
brightness
to
achieve
proper
brightness
value
Exposure
Time
Available when Auto Exposure is not checked. Slide to left or right to reduce or increase
exposure time, adjusting brightness of the video
Gain
Adjust Gain to reduce or increase brightness of video. The Noise will be reduced or
increased accordingly
Red Slide to left or right to decrease or increase the proportion of Red in RGB on video
Green Slide to left or right to decrease or increase the proportion of Green in RGB on video
Blue Slide to left or right to decrease or increase the proportion of Blue in RGB on the video
White Balance adjustment according to the video continuously
Adjust the Red or Blue item to set the video White Balance.
ROI White Balance
White Balance could be adjusted when the ROI region is changed according to content
inside the ROI region.
Sharpness Adjust Sharpness level of the video
Denoise Slide left or right to denoise the video
Saturation Adjust Saturation level of the video
Gamma
Adjust Gamma level of the video. Slide to the right side to increase gamma and to the left
to decrease gamma.
Contrast
Adjust Contrast level of the video. Slide to the right side to increase contrast and to the
left to decrease contrast.
DC
For DC illumination, there will be no fluctuation in light source so no need for
compensating light flickering
AC(50HZ) Check AC(50HZ) to eliminate flickering caused by 50Hz light source
AC(60HZ) Check AC(60HZ) to eliminate flickering caused by 60Hz light source
Default Restore all the settings in the Camera Control Panel to default values
