Delta AG9064 Manuel utilisateur
Delta Networking – Agema Family
AG9064 Spine Switch
Installation Guide
agema.deltaww.com
ii
AG9064 Spine Switch
Copyright
All specications and gures are subject to change without prior notice. Actual products may look
different from the photos.
All trademarks and logos mentioned in this guide are the properties of their respective holders.
Copyright © Delta Electronics, Inc. All rights reserved.
Regulatory and Safety Information
This product has been tested in accordance to, and complies with the following safety standards and
electromagnetic compatibility (EMC) inspection standards.
Emissions
Applicable standard
• AS/NZS CISPR 32: Class A
• ICES-003
• EN55032: Class A
• VCCI Class A
• FCC CFR 47 Part 15, Subpart B Class A
Safety
Applicable standard
• EN 60950-1, Second Edition
• UL 60950-1, Second Edition
• CAN/CSA C22.2 No. 60950-1-07, Second Edition
• IEC 60950-1, Second Edition Including All National
Immunity
Applicable standard
• EN 55024
• EN 61000-3-2: Harmonic Current Emissions
• EN 61000-3-3: Voltage Fluctuations and Flicker
• EN 61000-4-2: ESD
• EN 61000-4-3: Radiated Immunity
• EN 61000-4-4: EFT
• EN 61000-4-5: Surge
• EN 61000-4-6: Low Frequency Conducted Immunity
• EN61000-4-8: Power Frequency magnetic eld
• EN61000-4-11: Voltage dips and interruption
EU RoHS Compliant
Applicable standard All AG-Series components are EU RoHS compliant
iii
Warning: Fiber Optic Port Safety
When using a ber optic port, never look at the transmit laser while it is powered
on. Also, never look directly at the ber TX port and ber cable ends when they are
powered on.
Avertissement : Consignes de sécurité concernant le port de fibre optique
Ne regardez jamais le faisceau de laser émis activé lorsque vous utilisez un port de
bre optique. Également, ne regardez jamais le port de bre TX et les extrémités du
câble du bre directement lorsqu’ils sont activés.
CAUTION
Lithium Battery Caution
Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type.
Dispose batteries according to manufacturer’s instructions.
Disposal of a BATTERY into re or a hot oven, or mechanically crushing or cutting of a BATTERY, that
can result in an EXPLOSION.
Leaving a BATTERY in an extremely high temperature surrounding environment that can result in an
EXPLOSION or the leakage of ammable liquid or gas.
A BATTERY subjected to extremely low air pressure that may result in an EXPLOSION or the leakage
of ammable liquid or gas.
Grounding Caution
This equipment must be grounded and the power cord for product should be connected to a socket-
outlet with earthing connection.
MISE EN GARDE
Mise en garde concernant la pile au lithium
Risque d’explosion si la pile est remplacée incorrectement. Remplacez-la avec une pile semblable ou
de même type uniquement. Éliminez les piles selon les directives du fabricant.
L’élimination de la PILE dans un feu, un four chaud ou un broyeur mécanique peut provoquer une
EXPLOSION.
L’exposition de la PILE à une température ambiante extrêmement élevée peut provoquer une
EXPLOSION ou la fuite d’un liquide ou d’un gaz inammable.
L’exposition de la PILE à une pression atmosphérique extrêmement basse peut provoquer une
EXPLOSION ou la fuite d’un liquide ou d’un gaz inammable.
Mise en garde concernant la mise en terre
Cet équipement doit être mis à terre et le cordon d’alimentation du produit doit être branché à une
prise mise à terre.
iv
AG9064 Spine Switch
Table of Contents
Chapter 1: Introduction -------------------------------------------------------------------1
1.1 Overview ------------------------------------------------------------------------------------ 1
1.2 Package Content ------------------------------------------------------------------------- 1
1.3 Features------------------------------------------------------------------------------------- 2
Chapter 2: Appearance and Mechanism --------------------------------------------3
2.1 Product Overview ------------------------------------------------------------------------- 3
2.2 LED Identication ------------------------------------------------------------------------- 4
2.3 System Requirements ------------------------------------------------------------------- 7
2.4 Data Center Deployment --------------------------------------------------------------- 8
2.5 Power Supply Modules ------------------------------------------------------------------ 9
2.6 Fan Tray Module -------------------------------------------------------------------------10
Chapter 3: Installation ------------------------------------------------------------------- 11
3.1 Mounting -----------------------------------------------------------------------------------11
3.2 Installing an Optional QSFP/QSFP28 Transceiver ------------------------------14
3.3 Connecting to the Console Port ------------------------------------------------------15
3.4 Connecting to a Power Source -------------------------------------------------------15
Chapter 4: Making the Network Connections ----------------------------------- 18
4.1 Twisted-pair Connections --------------------------------------------------------------18
4.2 Fiber Optic Connections ---------------------------------------------------------------19
4.3 Ethernet Cabling -------------------------------------------------------------------------20
Appendix 1 : Technical Specifications--------------------------------------------- 21
Appendix 2 : Warranty------------------------------------------------------------------- 22
Limited and Support Warranty -------------------------------------------------------------22
Technical Support -----------------------------------------------------------------------------22
1
Chapter 1: Introduction
1.1 Overview
The AG9064 is a high performance, high density, 2RU, next generation Spine switch with
target application for Enterprise Campus Backbone, Data Center and Service Provider
deployment. It has sixty-four 100GbE QSFP28 ports which provides 6.4Tbps bandwidth
congurable to multi-rate 40/100GbE at desired fabric speed. In addition to rich bandwidth,
the AG9064 supports programmability capability, enables future-proof new features and
protocols and also has comprehensive capability on layer 2 and layer 3 features, including
STP, VLAN, QinQ, Trunk, QoS, LAG, full IPv4/IPv6 routing, RIP, OSPF, IGMP, DVMRP,
PIM-DM, PIM-SM, ACL, etc. The AG9064 also aims to next generation network also supports
advanced features such as VxLAN, L2GRE, NVGRE, GENEVE, NSH, MPLS, TRIL PPB-TE
L2/L2 in L3 Tunneling, Server Virtualization VN-Tag, VEPA, ow control PFC and ETS to meet
DCB network requirements. To provide a clear path to software-dened data center, AG9064
supports ONIE for zero touch installation of alternating network operating systems.
1.2 Package Content
After unpacking this switch, check the contents to be sure you have received all the
components. Then, before beginning the installation, be sure you have all other necessary
installation equipment.
•The AG9064 switch
•AC power supply for AC version or DC power supply for DC version
•Rack-mounting kits
•2 x Velcro strips
•Installation guide
If any item is missing or damaged, contact the vendor immediately, see “Technical Support”.
2
AG9064 Spine Switch
1.3 Features
The following lists the key main features of AG9064 switch:
•64 x 100GbE QSFP28 ports, support splitter cable
•1 x OOB BMC management port
•1 x Console port (RJ-45 type)
•1 x USB port
•Hot plugging redundant power supply support
•4 Fan modules
•System / Fan / Power status LED indication
•On board high performance CPU system with large memory
•Internal power supply: 1300W (AC version) or 1300W (DC version)
•Standard 2RU chassis high
•6.4 Tbps switching bandwidth
•Automatic address learning function to build the packet-forwarding information table. The
table contains up to 264K MAC addresses
•Low pin-to-pin latency: Cut-Through & Store and Forward Mode
•42MB of packet buffer memory
•Support Jumbo Frame up to 9Kbyte
3
Chapter 2: Appearance and Mechanism
2.1 Product Overview
2.1.1 Front View
Management port x 1
USB port x 1
QSFP28 ports x 64 RJ-45 Console port x 1
(Figure 2-1: Front View)
2.1.2 Rear View
Redundant PSU x 2
4 Fan tray slots
(Figure 2-2: Rear View)
NOTE:
The switch supports up to two PSUs. However, it might shipped with one power supply
pre-installed in the rear panel of the switch based on the SKU ordered. User can purchase
an additional PSU for redundancy.
4
AG9064 Spine Switch
2.2 LED Identification
This section provides an overview of the front and rear LEDs.
2.2.1 Front LEDs
Upper QSFP28 Port LED
Lower QSFP28 Port LED
Power 1 LED
Power 2 LED
System LED
Fan LED
(Figure 2-3: Front LED Identification)
LED Description
System LED
• Off – Power is off
• Solid Green – Normal operation
• Blinking Green – Booting
• Solid Amber – BMC hang, I/O port module fault
• Solid Red – CPU hang, System over current, System over voltage
Power 1 LED
• Solid Green – Power Supply 1 is supplied to the switch & operating normally
• Solid Red – Power Supply 1 is failed
• Off – Power is disconnected
Power 2 LED
• Solid Green – Power Supply 2 is supplied to the switch & operating normally
• Solid Red – Power Supply 2 is failed
• Off – Power is disconnected
Fan LED • Solid Green – FAN operating normally
• Solid Red – FAN is failed
100G QSFP28
slots
Four LEDs /
port
LED1 (Solid Lighting – Linkup; Blinking – Activity)
• Solid Green – 100G Operation
• Solid White – 50G Operation
• Solid Amber – 40G Operation
• Solid Blue – 25G Operation
• Solid Purple – 10G Operation
• Off – No Link
• Appearance and MechanismChapter 2
5
LED Description
100G QSFP28
slots
Four LEDs /
port
(continue)
LED 2 (Solid Lighting – Linkup; Blinking – Activity)
• Solid Blue – 25G Operation
• Solid Purple – 10G Operation
• Off – No link
LED3 (Solid Lighting – Linkup; Blinking – Activity)
• Solid White – 50G Operation
• Solid Amber – 40G Operation
• Solid Blue – 25G Operation
• Solid Purple – 10G Operation
• Off – No Link
LED 4 (Solid Lighting – Linkup; Blinking – Activity)
• Solid Blue – 25G Operation
• Solid Purple – 10G Operation
• Off – No link
Management
ports
(Two LEDs per
port)
Link LED: (on the left side)
• Off – No link is established on the port
• Solid Yellow – A valid link at 10/100Mbps is established on the port
• Solid Green – A valid link at 1000Mbps is established on the port
Act LED: (on the right side)
• Off – No link is established on the port
• Blinking Green – Activity, transmitting or receiving packet at this port
6
AG9064 Spine Switch
2.2.2 Rear LEDs
PSU LED
Fan LED
(Figure 2-4: Rear LED Identification)
LED Description
Fan LED • Green – FAN operating normally
• Red – FAN failed
PSU LED • Off – Power failure or no power
• Solid Green – Power is ok
