Delta Electronics NovoConnect B360 Manuel utilisateur

Quick Start Guide

NovoConnect

B360

Wireless Presentation & Collaboration System

1Package Contents

NovoConnect B360

Package Contents

(a) NovoConnect B360 main unit (b) Micro-HDMI-to-HDMI cable (c) Micro-USB-to-USB power cable

(d) USB power adapter (e) NovoConnect mount

Your NovoConnect B360

NovoConnect B360

Your NovoConnect B360

Reset

DC 5VMicro HDMI

Micro SD

Connecting Your B360

Video/Audio connection1. : Connect the Micro HDMI port to the TV/projector’s HDMI input port using the

Micro-HDMI-to-HDMI cable (item (b) in “Package Contents”).

Power input2. : Connect the Micro-USB port to the power source using the Micro-USB-to-USB power cable

and the USB power adapter (items (c) and (d) in “Package Contents”).

Note: Throughout this manual, your NovoConnect B360 will be referred to as B360.

Note: You may connect an optional USB mouse, keyboard, or memory drive to the USB port.

Note: The microSD slot supports NTFS and FAT32 format. Do not use other format to avoid data damage.

USB power adapter

HDMI Input Port

Micro HDMI port

(to TV/projector)

Reset Micro-USB port

(5V power input)

USB port (Mouse,

keyboard, memory drive)

microSD slot

Power LED (Green light when power is on)

3Software Download and Installation

NovoConnect B360

Software Download and Installation

Your B360 will power up and show the NovoConnect

home screen (as shown in the gure on this page)

once it is properly connected. Follow the steps below

to download the NovoConnect presentation software

from your B360 onto your PC.

Setup Wi-Fi:

Enable Wi-Fi on your computer. Search for

and connect to the SSID shown on the bottom

right corner of the NovoConnect home screen

(e.g. NVC_DC9AB). Wait a few seconds for the

connection to be established.

Software Download:

For Windows/Mac: To download the

presentation software, enter the URL shown

on the NovoConnect home screen into your

browser and follow the instructions on the

next page to download and install.

Software Download and Installation (continued)

NovoConnect B360

Software Download and Installation (continued)

For Windows and Mac computers

Once you have opened the webpage from your B360

home screen (for example, http://192.168.43.1:8080 in

the sample home screen), select an OS type and follow

the instructions on the web page to download and

install the NovoConnect software.

For Android and iOS tablets

Download and install the App “NovoPresenter” from

Google Play or iOS App Store. After installation, you

will see the NovoPresenter icon (as shown in the gure

on this page) on your tablet.

5Managing a Presentation

NovoConnect B360

Managing a Presentation

Launching a Presentation After software installation you will be able to access the

appropriate presentation software from your PC, Mac or

tablet.

PC and Mac:

NovoConnect

Desktop Streamer NovoConnect

Desktop Streamer

Android and iPad:

NovoPresenter

Start the application to launch the control panel (shown

on the left). Follow the steps below to start or join a

presentation group:

1. IP address

(Required):

Enter the IP address shown on the

NovoConnect home screen.

2. PIN

(optional):

Check the “PIN required” box and

enter PIN if needed.

3. Your Name

(optional):

Type in your name which will be

displayed to other members of your

presentation group.

4. Click Connect to start or join the presentation

group.

Managing a Presentation (continued)

NovoConnect B360

Managing a Presentation (continued)

(A)

Roles in a Presentation Session

Click on the list tab. This will display all participants in your

presentation group. The role of each participant is indicated by

the graphic symbols shown below.

1. Host

2. Presenter

3. Participant

(B)

Assigning Roles

Move the cursor over a participant entry to change the role of a

participant:

1. The host assigns a participant as a presenter.

2. The host assigns a participant as the new host.

Click on a numbered box to assign a presenter’s

on-screen display to the corresponding

presentation screen #1-#4.

Click the center box to assign a presenter’s on-

screen display to full screen.

7Managing a Presentation (continued)

NovoConnect B360

Managing a Presentation (continued)

(D)

Screen Preview (participant authorization required)

1. Only the host can preview a participant’s screen.

2. The participant denies or allows screen preview

by toggling the button between and

presentation group.

(E) Click the Connection tab and click Disconnect to leave the

presentation group.

For More Information

NovoConnect B360

For More Information

Please refer to the B360 user manual for more information on all the features and tools available. Here is a quick

list of topics in the B360 user manual useful in making an effective presentation:

MS, PDF, and Photo document presentations•

Annotation Tools for tablets and PCs•

Browser-based content presentations•

microSD card-based document presentations•

Resetting a presentation session•

Display parameters conguration•

Wi-Fi setup•

Please go to the following site to download the B360 User Manual and to view the most up-to-date product

information:

www.deltaww.com/EduSolution

9Notes

NovoConnect B360

Notes
