DeLonghi TRRS0920C Manuel utilisateur

OIL FILLED RADIATORS

IMPORTANT WARNINGS

Safety warnings

Danger!

Failure to observe the warning may result in life threatening

injury by electric shock.

-This appliance can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory

or mental capabilities or lack of ex-

perience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in

a safe way and understand the haz-

ards involved. Children shall not play

with the appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

- Children of less than 3 years should be

kept away unless continuously super-

vised.

- Children aged from 3 years and less

than 8 years shall only switch on/o

the appliance provided that it has

been placed or installed in its intend-

ed normal operating position and

they have been given supervision or

instruction concerning use of the ap-

pliance in a safe way and understand

the hazards involved. Children aged

from 3 years and less than 8 years

shall not plug in, regulate and clean

the appliance or perform user main-

tenance. CAUTION — Some parts

of this product can become very

hot and cause burns. Particular

attention has to be given where

children and vulnerable people

are present.

- This appliance is filled with a precise

quantity of oil and repairs requiring it

to be opened must be carried out by

the manufacturer or an authorised

technical assistance centre only. In the

event of oil leaks, contact the manu-

facturer or an authorised technical as-

sistance centre.

- When disposing of this appliance, re-

spect legislation on disposal of oil.

- Do not use the appliance near show-

ers, bathtubs, sinks, swimming pools,

etc.

- If the power cable has been damaged,

it must be replaced by the manufac-

turer or the technical service centre or

by a qualied person so as to avoid all

risks.

- ATTENTION: in order to avoid any dan-

ger caused by an accidental resetting

of the safety system, this appliance

must not be powered through an ex-

ternal timer.

Important!

Failure to observe the warning could result in injury or dam-

age to the appliance.

-The appliance must not be located

immediately below a xed socket-

outlet.

- The use of an extension lead is not recommended, as

overheating of the extension lead may occur during the

operation of the heater.

Danger of burns!!

Failure to observe the warning could result in burns or

scalds.

-WARNING: In order to avoid

overheating, never under any

circumstances cover the appli-

ances during operation, as this would

lead to dangerous overheating.

Please note:

This symbol indicates recommendations and important in-

formation for the user.

- Never use the heater to dry laundry.

- Never place the power cable on top of the heater while

it is hot.

- We recommend that you not place the heater in a

draught, because strong draughts of air may adversely

aect the equipment’s operational eciency.

- Only use the heater in an upright position.

- The heater must be positioned at least 30cm from fur-

niture or other objects.

- The rst time you use the appliance, operate it of at

least 15 minutes with the thermostat at maximum to

eliminate the “new” smell. A little smoke due to the

protective substances applied to the heating element

before transport may be given o.

- Position the appliance so that the plug and the outlet

can be easily reached even after installation.

- Do not use the appliance in rooms less than 4m2in

area.

- The appliance is tted with a safety device which will

switch o it in case of accidental overheating. To reset,

please contact Customer Experience, see enclosed

guarantee.

Disposing of the appliance

The appliance must not be disposed of with hou-

sehold waste, but taken to an authorised waste

separation and recycling centre.

INTRODUCTION

Thank you for choosing a De’Longhi product.

Please take a few minutes to read these instructions.

This will avoid all risks and damage to the appliance.

DESCRIPTION

(see figure on pag. 3).

A Thermostat

B Switches

C Comfortemp button

D Cord holder

E Wheel

USE

Electrical connection

- Before plugging the radiator into the mains, check

that the voltage of your mains electricity supply cor-

responds to the value V indicated on the appliance

and that the socket and power line are appropriately

dimensioned.

- CONNECT THE RADIATOR TO EFFICIENTLY EARTHED

SOCKETS ONLY.

- This appliance complies with directive on electromag-

netic compatibility.

“Easy wheel” sytem

Turn the radiator upside-down on a rug or a soft surface in

order to prevent damaging the paint nish.

Fully unfold the castors by turning them outwards (Fig.1).

Turn the radiator back to its upright position.

Important!

When in use, the radiator should always be kept vertical

(wheels at the bottom, controls at the top). Any other posi-

tion could be dangerous!

INSTRUCTIONS FOR USE

Switching on

Turn the thermostat dial clockwise to maximum.

Turn on both switches. The lights on the switches remain on

irrespective of the cycle set by the thermostat.

When the room reaches the required temperature, turn the

dial anticlockwise slowly until you hear a click.

The appliance will come on and go o automatically to main-

tain the required temperature.

Economiser

For economy of use, the switches can be used singly:

- button in position «I» only = minimum power (light on)

- button in position «II» only = medium power (light on)

- buttons in both positions «I» and «II» = maximum

power (lights on)

Using the thermostat

The thermostat operates on the basis of room temperature

and not radiator temperature.

Turn the thermostat dial anticlockwise towards the lower

numbers to reduce the temperature; turn it clockwise to-

wards the higher numbers to raise the temperature. To turn

the appliance o completely, turn the thermostat to mini-

mum and unplug from the mains.

Frost protection function

With the thermostat in position and the switches

pressed, the appliance maintains the room at a temperature

of about 5˚C, preventing freezing with minimum energy

consumption.

COMFORTEMP BUTTON

With the“COMFORTEMP”button and both switches pressed,

the appliance is automatically set to reach and maintain

what is considered to be the comfort temperature.

A green light comes on to indicate activation of “COMFOR-

TEMP”. In this mode the temperature is automatically set

only by the “COMFORTEMP”. To deactivate this mode and

return to thermostat operation, press the COMFORTEMP

button again.

MAINTENANCE

Before carrying out any operation on the radiator, unplug

from the electric mains and wait for it to cool.

The oil-lled electric radiator requires no particular main-

tenance. It is sucient to remove the dust with a soft, dry

cloth. Never use abrasive powders or solvents. If necessary

remove concentrations of dirt using a vacuum cleaner.

TECHNICAL CHARACTERISTICS

Supply voltage

See rating label

Absorbed power “

TROUBLESHOOTING

PROBLEM CAUSE SOLUTION

The appliance doesn't work Be sure it is plugged in and that the elec-

trical outlet is working.

Check for any obstruction.

The temperature may be set too low.

Plug into the power outlet.

Remove the obstruction and let the appliance

cool down. If the appliance doesn't work please

contact Customer Experience.

Set the temperature to a higher position.

5718510971_00_0817
