DeLonghi HFX85W15 Series Fiche technique
Better Everyday
HFX85W15 Series
Get Started
This short guide is not
intended to explain
all the functions
of the appliance.
Please read all the
owner’s instruction booklet
before use.
AIR PURIFIER
FAN • HEATER
HFX85W15 Series
HOW IT WORKS3D COMFORT AIR PURIFIER •FAN •HEATER
2 3
Air Circulation
The heavy duty fan offers
a range of 10 different
speeds, offering you the
ultimate choice of just how
much air circulation you
need and want.
Heating
The wrap around heating
effect can be customized
further with temperature
setting, 6 fan speeds and
high/low directional
airflow option.
Air Purification
As long as your unit is on,
you will be reaping the
rewards of clean, fresh air
as the air purifier works
full time to offer the best
results possible.
A. On/Standby button
B. Lid release button
C. Air purification filter
D. Remote control
E. Control panel
F. Heater button
F1. Heating mode
G1. Temperature button
G1. Temperature indicator
(C and F)
H. ECO button
H1. ECO function
I. Airflow directional button
J. Oscillation button
K. Timer button
K1. Timer function
L. Fan speed buttons
L1. Fan speed indicator
M. Fan button
M1. Fan mode
N. Hours indicator
O. Power light indicator
P. Remote control
reception area
Q. Handle
R. Air inlets
S. Air outlets
T. Remote control holder
A
A
M1
DK1
G1
N
F1
H1
P
E
L1
O
FM
GL
H
I
S
Q
R
K
J
C
B
T
Welcome to your comfort zone –
365 days of comfort for you and your
family. Expect the perfect balance of
even, gentle airflow
from left-to-right,
and head-to-toe, without experiencing
hot spots or drafts. Enjoy fresh, clean
air as 99.9%* of fine particles such as
allergens and pollutants are removed
by the 360 degree, double layer, HEPA
type filter. You will be warmed gently
in the winter, comforted by improved
air circulation in the summer and
rewarded with clean air all year round.
*
Third party organization test on MPPS particles to
EN 1822:2010. 99.9% efficiency refers to small particles
of 5m at 60 m3/h (cooling fan speed n.5).
HFX85W15 Series
4 5
FAN
GETTING STARTED
Before turning on your unit, you need to remove the protective wrapper from the
HEPA type filter that is already installed inside.
Press the lid
release button
to expose the
filter.
Lift the filter
completely out
of the unit.
Carefully remove
the protective
wrapper.
Replace the filter
back into the
unit and align it
with the unlock
symbol.
Rotate filter counter
clockwise until the
pointer on the cover
of the filter aligns
with the lock
symbol and close
the lid.
Activating the battery
in the Remote Control
Pull and remove the battery cover
strip that is extending from the
battery compartment on the back
of the remote control. This will
activate the internal battery and
make it ready for use.
Placing the unit in a room
For safety purposes and optimum
performance, please select a flat surface
and allow at least 3 feet ( 0.9 m ) of space
on all sides of the unit and the top. This
will allow for maximum air intake as well
airflow leaving the unit.
Minimum
Distance 3 Feet
On All Sides
HEATER
Turn ON the unit. Activate fan mode. Select fan speed
from 1 to 10.
Turn ON the unit. Activate heater
mode.
Select fan speed
from 1 to 6.
Select
Temperature.
Air Purification
As long as your unit is in the ON mode, your air purification system is working and
you do not have to do, or touch anything, to activate this function.
1 2 3
1 2 43
1 2 43 5
Remove
before use
HFX85W15 Series
CHANGE FILTER
OSCILLATION
7
6
AIRFLOW DIRECTION
Turn ON / OFF the
oscillation button.
Unit oscillates from side to side.
Press button for low
or high airflow.
For low directional airflow.
1 2
1 2 3
Note
If you are in
oscillation mode
and press any
other function
button, the
oscillation function
will pause for
10-15 seconds
and then resume
automatically.
For high directional airflow.
Always use an
original DeLonghi
replacement filter
(model DLSA005)
which can be
ordered from
www.delonghi.com.
When CF appears, you
need to change the filter.
Remove plug from outlet.
Press the lid release button
to expose the filter.
Lift the old filter
completely out
of the unit.
Carefully
remove
the
protective
wrapper from
the new filter.
Rotate filter
clockwise until the
pointer on filter
aligns with the lock
symbol and
close the lid.
Rotate filter
counter-clockwise
until the pointer
on filter aligns with
the unlock symbol.
Replace the
new filter back
into the unit.
To reset Change Filter notification, press in the ON/OFF
button while at the same time plugging the unit into an outlet.
1 2 3
4 5 6 7 8
9
Better Everyday
www.delonghi.com
like us: DeLonghi North America – follow us @DeLonghiNA
