Dell Venue 7 Manuel utilisateur

Marketing model:

Venue 7 3740, Venue 7 3740 HSPA+,

Venue 8 3840, Venue 8 3840 HSPA+

Regulatory model: T01C/T02D

Regulatory type:

T01C003, T01C004/T02D003, T02D004

Dell Venue 7/8

User's Manual

NOTE: A NOTE indicates important information that helps you make

better use of your tablet.

CAUTION: A CAUTION indicates potential damage to hardware or

loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

This product is protected by U.S. and international copyright and intellectual property laws.

Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other

jurisdictions. All other marks and names mentioned herein may be trademarks of their

respective companies.

2014 – 06 Rev. A00

Contents

Features.............................................................................5

Charging the Battery.......................................................7

Inserting the MicroSD Card and

Micro-SIM Card (optional).............................................8

Getting Started..............................................................

Turning on/off the tablet...............................................................9

Finishing Android setup........................................................9

Customizing the screen......................................................10

Locking and unlocking your tablet............................................11

Touch tips..

........

............................................

......

.........................11

Status bar.........................................................................................12

Screen orientation.........................................................................12

Keys and functions........................................................................13

Apps and widgets..........................................................................13

Using Your Tablet...........................................................14

Contacts

......................................................................................14

Text entry.........................................................................................15

Managing your tablet’s storage..................................................15

Internet............................................................................17

Connecting to the Internet using Wi-Fi....................................17

Connecting to the Internet using mobile broadband...........18

Using the airplane mode........................................................18

Browsing the Internet..............................................................18

Email............................................................................................19

Cusmonizing Your Tablet......................................20

Display settings.........................................................................20

Sound settings...........................................................................21

Date, time, and time zone......................................................21

Protecting Your Tablet............................................21

Screen-unlock pattern............................................................21

PIN...............................................................................................22

Password....................................................................................22

Protecting your SIM card with the SIM lock password

(LTE/HSPA+ models only).....................................................23

Apps...........................................................................24

Camera....

.........................

..................

........

...24

Copy files to and from the tablet..........................................24

Bluetooth.....................

...........

..................................................25

Gallery.........................................................................................26

Calendar.........

............................

..................

...........................27

Clock......................

...........................................

............

...........27

Troubleshooting......................................................28

Specifications...........................................................30

Features 5

Features

Venue 7

Part Functionality

1. Front camera Use to make video calls or to capture front photos and videos.

Light sensor

Detects the ambient light to allow screen-brightness to be

adjusted automatically.

3. Micro-USB port

Connect a shielded USB cable to charge your tablet or to

connect to your computer.

Battery-charging

Flashes while the tablet is charging and stays on when the tablet.

status light

is fully charged.

5. Volume buttons

• Press to increase or decrease the volume by one level.

• Press and hold to continuously increase or decrease the volume.

Service Tag label Provide the Service Tag when contacting Dell for support.

7. Speaker Outputs sound.

MicroSD-card slot

Insert a microSD card to expand the storage on your tablet.

Micro-SIM card slot

Insert a micro-SIM card to access mobile broadband.

(LTE/HSPA+ models)

10.

Rear camera

Capture pictures and videos.

11.

Power button

• Press and hold to turn on your tablet.

• Press and release to lock or unlock the screen.

• While the tablet is turned on, press and hold to open the

options menu.

12. Microphone Use for recording sound or to input voice in other

voice-based apps.

13. Headset port

Connect headphones or headset.

11 12

2 1

510

6 Features

10 11

Part Functionality

Light sensor

Detects the ambient light to allow screen-brightness to be

adjusted automatically.

Front camera

Use to make video calls or to capture front photos and videos.

Service Tag label

Provide the Service Tag when contacting Dell for support.

Speaker

Outputs sound.

MicroSD-card slot

Insert a microSD card to expand the storage on your tablet.

Micro-SIM card slot

Insert a micro-SIM card to access mobile broadband.

(LTE/HSPA+ models)

Microphone

Use for recording sound or to input voice in other

voice-based apps.

Volume buttons

• Press to increase or decrease the volume by one level.

• Press and hold to continuously increase or decrease the volume.

Battery-charging

Flashes when the tablet is charging and stays on when the tablet

status light

is fully charged.

10.

Micro-USB port

Connect a shielded USB cable to charge your tablet or to

connect to your computer.

11.

Rear camera

Capture pictures and videos.

12.

Power button

• Press and hold to turn on your tablet.

• Press and release to lock or unlock the screen.

• While the tablet is turned on, press and hold to open the

options menu.

13.

Headset port Connect headphones or headset.

Venue 8

Features 7

Charging the Battery

NOTE

our tablet may not be fully charged when you receive it. It is recommend to

charge

the tablet for 4 hours for the first time.

CAUTION

:Use only the adapter and/or cable shipped with the tablet.

Connect the micro-USB end of the USB cable to the USB port of the tablet.

Connect the other end of the USB cable to the adapter.

Connect the power adapter to an electrical outlet.

An animated icon appears on the screen while the battery is being charged.

When the battery is fully charged, the icon is static.

Venue 7 Venue 8

NOTE: When disconnecting the tablet from the adapter, disconnect the power

adapter from the power outlet and then disconnect the cable from your tablet.

8 Features

Inserting the MicroSD Card and Micro-SIM

Card (optional)

Venue 7

Open the card-slot door

Insert the cards into the respective

slots and push the cards in until

they

click

in place

Close the card-slot door

Venue 8

Open the card-slot door

Insert the cards into the respective

slots and push the cards in until

they click in place

Close the card-slot door

NOTE:

Make sure the cards are correctly aligned and are inserted all the way.

Getting Started 9

Getting Started

Turning on/off the tablet

To turn on your tablet, press and hold the power button for 3~5 seconds.

To turn off your tablet, press the power button to open the options menu, and then

select Power off→OK.

Finishing Android setup

After you turn on your tablet for the first time, follow the prompts on the screen to finish

Android setup.

You can configure settings such as language, date and time, Wi-Fi, sign-in to your

Google account, Google location services, and so on.

10 Getting Started

Customizing the screen

After finishing Android setup, follow the instructions on the screen to customize the

home screen.
