Dell™ PowerEdge™

T105 Systems

Getting Started

With Your System

系统使用入门

開始使用系統

はじめに

시스템시작하기

Model EMT

Dell™ PowerEdge™

T105 Systems

Getting Started

With Your System

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly

forbidden.

Trademarks used in this text: Dell, the Dell logo, and PowerEdge are trademarks of Dell Inc.; AMD,

AMD Opteron, and AMD Sempron are trademarks of Advanced Micro Devices Inc.; Intel is a registered

trademark of Intel corporation in the U.S. and other countries. Microsoft, Windows, and Windows

Server are either trademarks or registered trademarks of Microsoft Corporation in the United States

and/or other countries; Red Hat and Red Hat Enterprise Linux are registered trademarks of Red Hat, Inc.;

SUSE is a registered trademark of Novell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Model EMT

April 2008 P/N WY660 Rev. A01

Contents 3

Contents

System Features . . . . . . . . . . . . . . . . . . . . . . 5

Supported Operating Systems . . . . . . . . . . . . . . . 6

Other Information You May Need . . . . . . . . . . . . . 7

Obtaining Technical Assistance . . . . . . . . . . . . . 7

Installation and Configuration. . . . . . . . . . . . . . . 8

Unpack the System . . . . . . . . . . . . . . . . . . 8

Connect the Keyboard, Mouse, and Monitor. . . . . 8

Connect the System to Power . . . . . . . . . . . . 9

Turn on the System and Monitor . . . . . . . . . . . 9

Complete the 0perating System Setup. . . . . . . . . . 10

Technical Specifications . . . . . . . . . . . . . . . . 10

4Contents

Getting Started With Your System 5

System Features

This section describes the major hardware and software features of your

system. It also provides information about other documents you may need

when setting up your system and how to obtain technical assistance.

• One dual-core or quad-core AMD™ Opteron™ 1000 processor or AMD

Sempron™ with ECC processor (when available).

NOTE: Use the System Setup program to view processor information.

See the Hardware Owner’s Manual.

• A minimum of 512 MB of 667- or 800-MHz DDR II SDRAM memory,

upgradable to a maximum of 8 GB DDR II SDRAM memory by installing

512-MB, 1-GB, or 2-GB unbuffered ECC memory modules in the four

memory module sockets on the system board, single- or dual-rank.

• Support for the following internal hard-drive (non–hot-plug)

configurations:

– Up to two internal 3.5-inch SATA hard drives with an integrated SATA

controller

– Up to two internal 3.5-inch Serial-Attached SCSI (SAS) hard drives

with a SAS controller card

• One 3.5-inch peripheral drive bay for the optional diskette drive, and

two 5.25-inch bays for the following supported drives: DVD-ROM,

combination CD-RW/DVD, DVD-RW, or tape backup device.

NOTE: DVD devices are data only.

• Support for the following RAID volumes with an optional SAS RAID

controller card: simple, spanned, striped (RAID 0), and mirrored (RAID 1).

• Support for USB 2.0.

• A chassis intrusion alert.

6Getting Started With Your System

The system board includes the following integrated features:

• Dual-channel SATA controller that supports up to two supported devices

including, DVD-ROM, CDRW/DVD combination drive, DVD-RW, and

a SATA tape backup device.

NOTE: DVD devices are data-only.

• SATA controller that supports up to two cabled SATA hard drives.

• One 32-bit, 33-MHz PCI expansion card slot, one PCI Express x1

expansion slot, and two PCI Express x8 expansion slots.

• An integrated ATI ES1000 2D graphics controller with 32 MB of graphics

memory. Maximum resolution is 1600x1200 with 65,536 colors; true-color

graphics are supported in the following resolutions: 640 x 480, 800 x 600,

1024 x 768, and 1280 x 1024.

• An integrated Gigabit NIC, capable of supporting 1000-Mbps, 100-Mbps,

or 10-Mbps data rates, with support for PXE and Wake-on-LAN.

• Eight USB 2.0-compliant connectors (two on the front, one internal for

a bootable memory key, and five on the back) capable of supporting a

diskette drive, a CD-ROM drive, a keyboard, a mouse, or a USB flash drive.

• Back-panel connectors include serial, video, five USB connectors,

and one NIC connector.

• Front-panel connectors include two USB connectors.

• Four front-panel system diagnostic LEDs for failure messaging and

notification during startup.

For more information about specific features, see "Technical Specifications"

on page 10.

Supported Operating Systems

Your system supports the following operating systems:

• Microsoft

Windows Server

2008, Standard Edition (32-bit x86)

• Microsoft Windows Server 2008, Standard Edition (64-bit x86)

• Microsoft Windows Server 2003, Standard Edition x86 and EMT64T

Getting Started With Your System 7

• Microsoft Windows Server 2003, R2 Standard and Enterprise Editions

with SP2 x86 and EM64T

• Microsoft Windows

Small Business Server 2003 R2 Standard

and Premium Editions x86 and EM64T

•RedHat

Enterprise Linux

(version 5) x86_64

•SUSE

LINUX Enterprise Server 10 x86_64

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and

regulatory information. Warranty information may be included within this

document or as a separate document.

• The

Hardware Owner’s Manual

provides information about system

features and describes how to troubleshoot the system and install or

replace system components. This document can be found on the CDs

that came with your system or on

support.dell.com

• CDs included with your system provide documentation and tools

for configuring and managing your system.

• Updates are sometimes included with the system to describe changes

to the system, software, and/or documentation.

NOTE: Always check for updates on support.dell.com and read the updates

first because they often supersede information in other documents.

• Release notes or readme files may be included to provide last-minute

updates to the system or documentation or advanced technical reference

material intended for experienced users or technicians.

• Operating system documentation describes how to install (if necessary),

configure, and use the operating system software.

• Documentation for any components you purchased separately provides

information to configure and install these options.

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does

not perform as expected, see your Hardware Owner’s Manual.

Dell Enterprise Training and Certification is available; see dell.com/training

for more information. This service may not be offered in all locations.

8Getting Started With Your System

Installation and Configuration

CAUTION: Before performing the following procedure, read and follow the safety

instructions and important regulatory information in your Product Information

Guide.

This section describes the steps to set up your system for the first time.

Unpack the System

Unpack your system and identify each item. Keep all shipping materials

in case you need them later.

Connect the Keyboard, Mouse, and Monitor

Connect the keyboard, mouse, and monitor (optional).

The connectors on the back of your system have icons indicating which

cable to plug into each connector. Be sure to tighten the screws (if any)

on the monitor's cable connector.
