Dell PowerEdge T100 Manuel utilisateur

Dell™ PowerEdge™

Getting Started

With Your System

系统使用入门

開始使用系統

はじめに

시스템시작하기

Dell™ PowerEdge™

Getting Started

With Your System

Model EMT

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly

forbidden.

Trademarks used in this text: Dell, the Dell logo, and PowerEdge are trademarks of Dell Inc.; Intel,

Celeron, Pentium, and Xeon are registered trademarks and Core is a trademark of Intel corporation

in the U.S. and other countries. Microsoft, Windows, and Windows Server are either trademarks or

registered trademarks of Microsoft Corporation in the United States and/or other countries; Red Hat

and Red Hat Enterprise Linux are registered trademarks of Red Hat, Inc. in the United States and other

countries; SUSE is a registered trademark of Novell Inc. in the United States and other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Model EMT

May 2008 P/N F268G Rev. A01

Getting Started With Your System 3

System Features

This section describes the major hardware and software features of your

system. It also provides information about other documents you may need

when setting up your system and how to obtain technical assistance.

• One of the following processors:

–Intel

Celeron

processor

– Intel Celeron Dual-Core processor

– Intel Pentium

Dual-Core processor

– Intel Core™2 Duo processor

– Dual-Core Intel Xeon

processor

– Quad-Core Intel Xeon processor

NOTE: Processor availability may differ by region.

NOTE: Use the System Setup program to view processor information.

See the Hardware Owner’s Manual.

• A minimum of 512 MB of 667- or 800-MHz DDR II SDRAM memory,

upgradable to a maximum of 8 GB DDR II SDRAM memory by installing

512-MB, 1-GB, or 2-GB unbuffered ECC memory modules in the four

memory module sockets on the system board; single or dual rank.

• Support for the following internal hard-drive (non-hot-pluggable)

configurations:

– Up to two internal 3.5-inch SATA hard drives with an integrated SATA

controller

– Up to two internal 3.5-inch Serial-Attached SCSI (SAS) hard drives

with a SAS controller card

• One 3.5-inch peripheral drive bay for the optional diskette drive, and

two 5.25-inch bays for the following supported drives: DVD-ROM,

combination CD-RW/DVD, DVD+/-RW, or backup device.

NOTE: DVD devices are data only.

4Getting Started With Your System

• Support for the following RAID volumes with an optional SAS RAID

controller card: simple, spanned, striped (RAID 0), and mirrored (RAID 1).

• A chassis intrusion alert.

The system board includes the following integrated features:

• SATA controller that supports up to two optical devices including

DVD-ROM, CDRW/DVD combination drive, and DVD+/- RW.

NOTE: DVD devices are data only.

• SATA controller that supports up to two cabled SATA hard drives.

• One 32-bit, 33-MHz expansion card slot, one PCI Express x1 expansion

slot, and two PCI Express x8 expansion slots; one with x4 bandwidth.

• An integrated ATI ES1000 graphics controller with 32 MB of graphics

memory. Maximum resolution is 1600x1200 with 65,536 colors; true-color

graphics are supported in the following resolutions: 640 x 480, 800 x 600,

1024 x 768, and 1280 x 1024.

• An integrated Gigabit NIC, capable of supporting 1000-Mbps, 100-Mbps,

or 10-Mbps data rates, with support for PXE and Wake-on-LAN.

• Front-panel connectors include two USB connectors.

• Back-panel connectors include serial, video, five USB connectors, and one

NIC connector.

• Eight USB 2.0-compliant connectors (two on the front, one internal for a

bootable memory key and Unmanaged Internal Persistent Storage (UIPS),

and five on the back) capable of supporting a diskette drive, a CD-ROM

drive, a keyboard, a mouse, or a USB flash drive.

• Four front-panel system diagnostic LEDs for failure messaging and

notification during startup.

For more information about specific features, see "Technical Specifications"

on page 8.

Supported Operating Systems

Your system supports the following operating systems:

• Microsoft

Windows Server

2008, Standard Edition (32-bit x86)

• Microsoft Windows Server 2008, Standard Edition (x64)

• Microsoft Windows Server 2003, R2 and SP2 Standard Edition(32-bit x86)

Getting Started With Your System 5

• Microsoft Windows Server 2003, R2 and SP2 Standard Edition (x64)

• Microsoft Windows Small Business Server 2003, R2 and SP2 Standard

Edition (32-bit x86)

• Microsoft Windows Small Business Server 2003, R2 and SP2 Premium

Edition (32-bit x86)

•RedHat

Enterprise Linux

ES (version 5) (x86_32)

• Red Hat Enterprise Linux ES (version 5) (x86_64)

•SUSE

Linux Enterprise Server 10 (x86_64)

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and

regulatory information. Warranty information may be included within this

document or as a separate document.

• The

Hardware Owner’s Manual

provides information about system

features and describes how to troubleshoot the system and install or

replace system components. This document can be found on

support.dell.com

• CDs or DVDs included with your system provide documentation and tools

for configuring and managing your system.

• Updates are sometimes included with the system to describe changes

to the system, software, and/or documentation.

NOTE: Always check for updates on support.dell.com and read the updates

first because they often supersede information in other documents.

• Release notes or readme files may be included to provide last-minute

updates to the system or documentation or advanced technical reference

material intended for experienced users or technicians.

• Operating system documentation describes how to install (if necessary),

configure, and use the operating system software.

• Documentation for any components you purchased separately provides

information to configure and install these options.

6Getting Started With Your System

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does

not perform as expected, see your Hardware Owner’s Manual.

Dell Enterprise Training and Certification is available; see dell.com/training

for more information. This service may not be offered in all locations.

Installation and Configuration

CAUTION: Before you begin this procedure, read and follow the safety

instructions that came with the system.

This section describes the steps to set up your system for the first time.

Unpack the System

Upack your system and identify each item. Keep all shipping materials in case

you need them later.

Connect the Keyboard, Mouse, and Monitor

Connect the keyboard, mouse, and monitor (optional).

The connectors on the back of your system have icons indicating which

cable to plug into each connector. Be sure to tighten the screws (if any)

on the monitor's cable connector.

Getting Started With Your System 7

Connect the System to Power

Connect the system’s power cable to the system. Next, plug the other end of

the power cable into a grounded electrical outlet or a separate power source such

as an uninterrupted power supply (UPS) or a power distribution unit (PDU).

Turn on the System and Monitor

Press the power button on the system and the monitor. The power indicators

should light. Adjust the monitor's controls until the displayed image is

satisfactory.

8Getting Started With Your System

Complete the 0perating System Setup

If you purchased a preinstalled operating system, see the operating system

documentation that ships with your system. To install an operating system

for the first time, see the Quick Installation Guide. Be sure the operating

system is installed before installing hardware or software not purchased

with the system.

Technical Specifications

Processor

Processor type

•Intel

Celeron

processor

• Intel Celeron Dual-Core processor

• Intel Pentium

Dual-Core processor

• Intel Core™2 Duo processor

• Dual-Core Intel Xeon

processor

• Quad-Core Intel Xeon processor

NOTE: Processor availability may differ

by region.

Expansion Bus

Bus type PCI and PCIe

Expansion slots

PCIe

0.5 GB/sec PCIe x1, 3.3-V, 12-V (slot 4)

2 GB/sec PCIe x8 with x4 bandwidth,

3.3-V, 12-V (slot 1)

4 GB/sec PCIe x8, 3.3-V, 12-V (slot 2)

PCI

One 3.3-V, half-length, 32-bit, 33-MHz

(slot 3)

Memory

Architecture 72-bit, ECC, PC-5300/6400, unbuffered,

DDR II SDRAM, DIMMs, rated for 667-

or 800-MHz operation

Memory module sockets four 240-pin
