Dell™ PowerEdge™

R200 Systems

Getting Started

With Your System

Guide de mise en route

Primeiros passos com o sistema

Procedimientos iniciales con el sistema

Dell™ PowerEdge™

R200 Systems

Getting Started

With Your System

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly

forbidden.

Trademarks used in this text: Dell, the DELL logo, and PowerEdge are trademarks of Dell Inc.

Intel, Pentium, and Celeron are registered trademarks and Core is a trademark of Intel Corporation

Microsoft, Windows, and Windows Server are either trademarks or registered trademarks of Microsoft

Corporation in the United States and/or other countries Red Hat is a registered trademark of Red Hat,

Inc. SUSE is a registered trademark of Novell Inc. in the United States and other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Model SVP

August 2007 P/N MP148 Rev. A00

Getting Started Guide 3

System Features

The major hardware and software features of your system include:

• 1U/1S rack-mountable chassis with support for static rails and sliding rails.

NOTE: Use the System Setup program to view processor information.

See "Using the System Setup Program" in your Hardware Owner’s Manual.

• One of the following processors:

–Intel

Celeron

– Intel Pentium

Dual-Core™

– Intel Core 2 Duo™

– Dual-Core Intel Xeon

Processor 3000 Series

– Quad-Core Intel Xeon Processor 3200 Series.

• A minimum of 512 MB of 667-MHz or 800-MHz DDR2 SDRAM memory,

upgradable to a maximum of 8 GB by installing combinations of 512-MB,

1-GB, or 2-GB unbuffered ECC memory modules in four memory module

sockets on the system board.

• One of the following riser card options:

– One full-height, half-length, x8 lane PCIe expansion slot and one full-

height, half-length PCIe expansion slot with a x8 connector but with

a x4 lane capability.

– One full-height, half-length, 133MHz/64 bit PCI-X expansion slot and

one full-height, half-length, x8 lane PCIe expansion slot, which

includes a connector for an optional remote access controller (RAC)

card.

• One 3.5-inch CD, DVD, or combination CD-RW/DVD in a peripheral

drive bay.

• Support for the following internal hard-drive configurations:

– Up to two internal, 1-inch high, SATA hard drives with the integrated

drive controllers.

– Up to two internal, 1-inch high optional Serial-Attached SCSI (SAS)

hard drives with an optional SAS controller card.

• Optional remote access controller for remote systems management.

This option requires a riser card with support for PCI-X and PCIe RAC

connectors.

• Optional USB flash drive emulates a diskette drive or hard drive.

• One 345-W power supply.

4Getting Started Guide

• Two integrated Gigabit Ethernet network adapters, capable of supporting

10-Mbps, 100-Mbps, and 1000-Mbps data rates.

• Two system cooling fans, one power-supply cooling fan, and one optional

PCI fan for systems with a SAS/RAID controller.

• Serial connector for console redirection support.

• Security features, including chassis-intrusion detection and keylock on

the optional bezel.

• Systems management software/circuitry that monitors critical system

voltages and temperatures.

• Back-panel connectors include keyboard, video, mouse, serial, two USB,

and two NIC connectors.

• Front-panel connectors include one VGA and two USB connectors. For

more information about specific features, see "Technical Specifications"

on page 11.

The following software is included with your system:

• A System Setup program for viewing and changing system configuration

information. For more information, see "Using the System Setup Program"

in the

Hardware Owner’s Manual

• Enhanced security features, including a system and setup passwords are

available through the System Setup program.

• Video drivers for displaying application programs in high-resolution

modes.

• Systems management software and documentation CDs.

Getting Started Guide 5

Supported Operating Systems

• Microsoft

Windows Server

2008 Web, Standard, and Enterprise

(32-bit x86) Editions (

when available

)

• Microsoft Windows Server 2008 Web, Standard, Small Business Server

(Premium and Standard), and Enterprise (x64) Editions (

when available

)

• Microsoft Windows Server 2003 Web, Standard, Small Business Server

(Premium and Standard), and Enterprise (32-bit x86) Editions

(SP1 and SP2)

• Microsoft Windows Server 2003 Standard and Enterprise (x64) Editions

• Microsoft Windows Server 2003 R2 Standard, Small Business Server

(Premium and Standard), and Enterprise (32-bit x86) Editions

• Microsoft Windows Server 2003 R2 Standard and Enterprise (x64)

Editions

•RedHat

Enterprise Linux ES (versions 4 and 5) (x86_32)

• Red Hat Enterprise Linux ES (versions 4 and 5) (x86_64)

•SUSE

Linux Enterprise Server 9 (SP2 or later) (x86_64)

• SUSE Linux Enterprise Server 10 (x86_64)

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and

regulatory information. Warranty information may be included within this

document or as a separate document.

• The

Rack Installation Instructions

Rack Installation Guide

included

with your rack solution describes how to install your system into a rack.

• The

Hardware Owner’s Manual

provides information about system

features and describes how to troubleshoot the system and install or

replace system components. The

Hardware Owner’s Manual

is available

on the CDs that came with your system or on

support.dell.com

• CDs included with your system provide documentation and tools

for configuring and managing your system.

• Systems management software documentation describes the features,

requirements, installation, and basic operation of the software.

6Getting Started Guide

• Operating system documentation describes how to install (if necessary),

configure, and use the operating system software.

• Documentation for any components you purchased separately provides

information to configure and install these options.

• Updates are sometimes included with the system to describe changes

to the system, software, and/or documentation.

NOTE: Always check for updates on support.dell.com and read the updates

first because they often supersede information in other documents.

• Release notes or readme files may be included to provide last-minute

updates to the system or documentation or advanced technical reference

material intended for experienced users or technicians.

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does

not perform as expected, see your Hardware Owner’s Manual.

Dell Enterprise Training and Certification is available; see

www.dell.com/training for more information. This service may not be offered

in all locations.

Installation and Configuration

CAUTION: Before performing the following procedure, read and follow the safety

instructions and important regulatory information in your Product Information

Guide.

CAUTION: Whenever you need to lift the system, get others to assist you.

To avoid injury, do not attempt to lift the system by yourself.

This section describes the steps to set up your system for the first time.

Getting Started Guide 7

Unpacking the System

Unpack your system and identify each item.

Keep all shipping materials in case you need them later.

Installing the Rails and System in a Rack

Once you have read the "Safety Instructions" located in the rack

installation documentation for your system, install the rails and

the system in the rack.

See your rack installation documentation for instructions on installing

your system in a rack.

8Getting Started Guide

Connecting the Keyboard, Mouse, and Monitor

Connect the keyboard, mouse, and monitor (optional).

The connectors on the back of your system have icons indicating

which cable to plug into each connector. Be sure to tighten the screws

(if any) on the monitor's cable connector.
