Dell™2208WFPFlatPanelMonitorUser'sGuide

Notes, Notices, and Cautions



Information in this document is subject to change without notice.

©2007DellInc.Allrightsreserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex, Latitude, PowerEdge, PowerVault, PowerApp, and Dell OpenManage are trademarks of Dell

Inc;Microsoft, Windows, and Windows NT areregisteredtrademarksofMicrosoftCorporation;Adobe is a trademark of Adobe Systems Incorporated, which may be registered in

certain jurisdictions.ENERGYSTAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product

meets the ENERGY STAR guidelines for energy efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model 2208WFP

August 2007 Rev. A00



About Your Monitor

Product Features

Identifying Parts and Controls

Monitor Specifications

Universal Serial Bus (USB) Interface

Plug and Play Capability

Maintenance Guidelines



Setting Up the Monitor

Attaching the Stand the Monitor

Connecting Your Monitor

Organizing the Cables

Attaching the Soundbar (Optional)

Removing the Stand

Operating the Monitor

Using the Front Panel Controls

Using the On-Screen Display (OSD)

Setting the Optimal Resolution

Using the Dell Soundabr (Optional)

Using the Tilt, Swivel, and Vertical Extension

Rotating the Monitor

Adjusting the Rotating Settings of Your Operating System

Solving Problems

Monitor Specific Troubleshooting

Common Problems

Product Specific Problems

Universal Serial Bus (USB) Specific Problems

Dell™Soundbar Troubleshooting

Appendix

Safety Instructions

FCC Notice (U.S. Only) and Other Regulatory Information

Contacting Dell



NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page



About Your Monitor

Dell™2208WFPFlatPanelMonitorUser'sGuide

Product Features

The 2208WFP flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD). The monitor features include:

■22-inch (573.6 mm) viewable area display.

■1680x1050resolution,plusfull-screen support for lower resolutions.

■Wide viewing angle to allow viewing from a sitting or standing position, or moving side-to-side.

■Tilt, swivel, vertical extension and rotate adjustment capabilities.

■Removable pedestal and VESA 100 mm mounting holes for flexible mounting solutions.

■Plug and play capability if supported by your system.

■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

■Software and documentation CD includes an information file (INF), Image color Matching File (ICM), and product documentation.

■Energy Saver feature for Energy Star compliance.

■Security lock slot.

Identifying Parts and Features

Front View

Product Features

Identifying Parts and Controls

Monitor Specifications

Universal Serial Bus (USB) Interface

Plug and Play Capability

Maintenance Guidelines

Front View

Back View

Side View

Front panel controls

Label

Description

Input Source select

OSDMenu/Selectbutton

Brightness & Contrast/Down (-) button

Auto-adjust/Up (+) button

Power button (with power light indicator)

Back view

Back View with monitor stand

Label



Description

VESA mounting holes (100mm)

(Behind attached base plate)

Use to mount the monitor.



Barcode serial number label

Refer to this lable if you need to contact Dell for

technical support.

Security lock slot

Use a security lock with the slot to help secure your

monitor.

Dell Soundbar mounting brackets

Attach the optional Dell Soundbar.

Regulatory rating label

Lists the regulatory approvals.

Stand removeal button

Press to release the stand.

Cable management hole

Help organize cables by placing them through the hole.

Lock down/release button

Push the monitor down, press the button to unlock the

monitor, and then lift the monitor to the desired height.

Bottom View

USB

connectors

(downstream)



Leftview



Right view



Label

Description

AC power cord connector.

DC power connector for Dell Soundbar.

DVI connector

VGA connector

USB upstream port

USB connector port

Monitor Specifications

The following sections give you information about the various power management modes and pin assignments for various connectors for your monitor.

Power Management Modes

IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotinuse.Thisisreferredtoas

Mode

*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The following table shows the power consumption and signaling

of this automatic power saving feature:

VESA Modes

Horizontal Sync

Vertical Sync

Video

Power Indicator

Power Consumption

The OSD will only function in the normal operation mode. When the menu or plus buttons are pressed in Active-

off mode, one of the following messages will be displayed:

Analog Input In Power Save Mode. Press Computer Power Button or Any Key on Keyboard or Move Mouse

Digital Input In Power Save Mode. Press Computer Power Button or Any Key on Keyboard or Move Mouse

Activate the computer and the monitor to gain access to the OSD.

* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.

Normal operation (with Dell Soundbar and USB active)

Active

Green

75 W (maximum)

Normal operation

Active

Green

45 W (typical)

Active-off mode

Inactive

Blanked

Amber

Less than 2 W

Switch off

Off

Less than 1 W

NOTE: This monitor is ENERGY STAR®-compliant as well as TCO '99/TCO '03 power management compatible.

Pin Assignments

VGA Connector

DVIConnector

Number

15-pin Side of the Connected Signal Cable

Video-Red

Video-Green

Video-Blue

GND

Self-test

GND-R

GND-G

GND-B

Computer 5V

GND-sync

GND

DDC data

H-sync

V-sync

DDC clock

Number

24-pin Side of the Connected Signal Cable

T.M.D.S. Data 2-

T.M.D.S. Data 2+

T.M.D.S. Data 2 Shield

No connector

DDC Clock

DDC Data

No connector

T.M.D.S. Data 1-

T.M.D.S. Data 1+

T.M.D.S. Data 1 Shield

No connector

+5V power

Selftest

Hot Plug Detect

T.M.D.S. Data 0-

T.M.D.S. Data 0 Shield

T.M.D.S. Data

No connector

T.M.D.S.Clock Shield

T.M.D.S. Clock+

T.M.D.S. Clock-

Universal Serial Bus (USB) Interface

This section gives you information about the USB ports that are available on the left side of your monitor.

USB Upstream Connector

USB Downstream Connector



NOTE: This monitor supports High-Speed Certified USB 2.0 interface

Transfer speed

Data Rate

Power Consumption

High speed

480 Mbps

2.5W(Max.,eachport)

Full speed

12 Mbps

2.5W(Max.,eachport)

Low speed

1.5 Mbps

2.5W(Max.,eachport)

Pin Number

4-pin Side of the connector

DMU

VCC

DPU

GND

Pin Number

4-Pin Side of the Signal Cable

VCC

DMD

DPD

GND

USB Ports

l1 upstream -rear

l4 downstream -2 on rear; 2 on left side

NOTE:USB2.0functionalityrequiresaUSB2.0-

capablecomputer

NOTE:

The monitor's USB interface works only when the monitor is on or in power save mode. If you turn off the monitor and then turn it on, the attached peripherals may take a few

seconds to resume normal functionality.

Plug and Play Capability

You can install the monitor in any Plug and Play-

compatible system. The monitor automatically provides the computer system with its Extended Display Identification Data (EDID) using Display Data

Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. Most monitor installations are automatic; you can select different settings if desired. For more

information about changing the monitor settings, see Operating the Monitor.

Flat Panel Specifications

Screen type

Active matrix -TFT LCD

Screen dimensions

22 inches (22-inch viewable image size)

Preset display area:



Horizontal

473.76mm(18.7inches)

Vertical

296.1 mm (11.7 inches)

Pixel pitch

0.282mm

Viewing angle

160°(vertical)typ,160°(horizontal)typ

Luminance output

300 CD/m ²(typ)

Contrast ratio

1000 to 1 (typ)

Faceplate coating

Antiglare with hard-coating 3H

Backlight

CCFL (4) edgelight system

Response Time

5ms typical

Resolution Specifications

Video Supported Modes

Horizontal scan range

30 kHz to 83 kHz

Vertical scan range

56Hzto76Hz

Optimal preset resolution

1680 x 1050 at 60 Hz

Highest preset resolution

1680 x 1050 at 75 Hz

Video display capabilities (DVI playback)

480i/480p/576i/576p/720p/1080i/1080p (Support HDCP)

Preset Display Modes

Display Mode

Horizontal Frequency

(kHz)

Vertical Frequency (Hz)

Pixel Clock (MHz)

Sync Polarity

(Horizontal/Vertical)

VESA, 720 x 400

31.5

70.0

28.3

-/+

VESA, 640 x 480

31.5

60.0

25.2

-/-

VESA, 640 x 480

37.5

75.0

31.5

-/-

VESA, 800 x 600

37.9

60.0

40.0

+/+

VESA, 800 x 600

46.9

75.0

49.5

+/+

VESA, 1024 x 768

48.4

60.0

65.0

-/-

VESA, 1024 x 768

60.0

75.0

78.8

+/+

VESA, 1152 x 864

67.5

75.0

108.0

+/+

VESA, 1280 x 1024

64.0

60.0

135.0

+/+

VESA, 1280 x 1024

80.0

75.0

135.0

+/+

VESA, 1680 x 1050

65.2

60.0

146.3

-/+

VESA, 1680 x 1050

64.6

60.0

119.0

+/-

Electrical Specifications

Video input signals

Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance

Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50

ohm input impedance

Synchronization input signals

Separate horizontal and vertical synchronizations, polarity-free TTL level,

SOG (Composite SYNC on green)

AC input voltage/frequency/current

100 to 240 VAC / 50 or 60 Hz +3 Hz / 2.0A (Max.)

Inrush current

120V:42A (Max.)

240V:80A (Max.)

Physical Characteristics

Connector type

15-pin D-subminiature, blue connector; DVI-D, white connector

Signal cable type

Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor

Analog: Detachable, D-Sub, 15pins, shipped attached to the monitor

Dimensions (with stand)

Height (Compressed)

14.18 inches (360.24 mm)

Height (Extended)

18.12 inches (460.24 mm)

Width

20.13 inches (511.41 mm)

Depth

5.45 inches (138.50 mm)

Dimensions (without stand)



Height

13.19 inches (334.94 mm)

Width

20.13 inches (511.41 mm)

Depth

2.56 inches (65.00 mm)

Stand dimensions



Height (Compressed)

12.58 inches (319.53 mm)

Height (Extended)

14.24 inches (361.18 mm)

Width

15.96 inches (405.30 mm)

Depth

7.73 inches (196.50 mm)

Weight



Weight with packaging

18.78 lbs (8.53 kg)

Weight with stand assembly and cables

14.87 lbs (6.75 kg)

Weight without stand assembly

(For wall mount or VESA mount considerations -

no cables)

10.88 lbs (4.94 kg)

Weight of stand assembly

3.99 lbs (1.81 kg)

Environmental Characteristics

Temperature



Operating

5°to35°C(41°to95°F)

Non-operating

Storage: -20°to60°C(-4°to140°F)

Shipping: -20°to60°C(-4°to140°F)

Humidity



Operating

10% to 80% (non-condensing)



Maintenance Guidelines

Cleaning Your Monitor

For best practices, follow the instructions in the list below while unpacking, cleaning, or handling your monitor:

lTo clean your antistatic screen, lightly dampen a soft, clean cloth with water. If possible, use a special screen-cleaning tissue or solution suitable for the

antistatic coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed air.

lUse a lightly-dampened,warmclothtocleanthemonitor.Avoidusingdetergentofanykindassomedetergentsleaveamilkyfilmonthemonitor.

lIf you notice white powder when you unpack your monitor, wipe it off with a cloth.

lHandleyourmonitorwithcareasdarker-colored monitor may scratch and show white scuff marks more than lighter-coloredmonitor.

lTo help maintain the best image quality on your monitor, use a dynamically changing screen saver and turn off your monitor when not in use.

Back to Contents Page

Non-operating

Storage: 5% to 90% (non-condensing)

Shipping: 5% to 90%(non-condensing)

Altitude



Operating

3,657.6m (12,000 ft) max

Non-operating

12,192 m (40,000 ft) max

Thermal dissipation

256.08 BTU/hour (maximum)

153.6 BTU/hour (typical)

CAUTION: Read and follow the safety instructionsbeforecleaningthemonitor.

CAUTION:Beforecleaningthemonitor,unplugthemonitorpowercablefromtheelectricaloutlet.

Back to Contents Page



Appendix

Dell™2208WFPFlatPanelMonitorUser'sGuide

Safety Instructions

FCC Notice (U.S. Only) and Other Regulatory Information

Contacting Dell

CAUTION: Safety Instructions

For information on safety instructions, see the Product Information Guide.

FCC Notices (U.S. Only) and Other Regulatory Information

For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com\regulatory_compliance.

Contacting Dell

For customers in the United States, call 800-WWW-DELL (800-999-3355).

Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be

available in your area. To contact Dell for sales, technical support, or customer service issues:

Back to Contents Page

CAUTION: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,

electrical hazards, and/or mechanical hazards.

NOTE:

If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or Dell product catalog.

Visit support.dell.com.

Verify your country or region in the Choose A Country/Region drop-downmenuatthebottomofthepage.

Click Contact Us on the left side of the page.

Select the appropriate service or support link based on your need.

Choose the method of contacting Dell that is convenient for you.

Autres manuels pour UltraSharp 2208WFP

Table des matières

Autres manuels Dell Moniteur

Dell

Dell U2410 - UltraSharp - 24" LCD Monitor Manuel utilisateur

Dell

Dell 1701FP Manuel utilisateur

Dell

Dell P2011H Manuel utilisateur

Dell

Dell U2410 - UltraSharp - 24" LCD Monitor Manuel utilisateur

Dell

Dell P2419HB Manuel

Dell

Dell P5524Q Manuel utilisateur

Dell

Dell UltraSharp U3417W Manuel utilisateur

Dell

Dell S2721DB Instructions d'utilisation

Dell

Dell SE2717H Instructions d'installation

Dell

Dell P2722HB Instructions d'utilisation

Dell

Dell P2212H Manuel utilisateur

Dell

Dell Ultra Sharp 2408WFP Instructions d'utilisation

Dell

Dell P2419HC Manuel utilisateur

Dell

Dell 2405FPW - UltraSharp - 24" LCD Monitor Instructions d'utilisation

Dell

Dell UltraSharp UP3218K Manuel utilisateur

Dell

Dell 2005FPW - UltraSharp - 20.1" LCD Monitor Manuel utilisateur

Dell

Dell U4021QW Manuel utilisateur

Dell

Dell SE2722HR Manuel utilisateur

Dell

Dell UltraSharp 34 Manuel utilisateur

Dell

Dell UltraSharp 1703FP Instructions d'utilisation

Dell

Dell S199WFP - 19" LCD Monitor Manuel utilisateur

Dell

Dell 2408WFP - UltraSharp - 24" LCD Monitor Manuel utilisateur

Dell

Dell E1920H Instructions d'utilisation

Dell

Dell XPS 17 9720 Mode d’emploi

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Philips

Philips 107C64 Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation

LG M1950D-PZ Manuel utilisateur

Sceptre

Sceptre D40 Manuel utilisateur

Hunt Electronic

Hunt Electronic HCD-15AH Manuel utilisateur
