Dell E2016 Manuel utilisateur

Model: E2016

Regulatory model: E2016t

Dell E2016 Monitor

User’s Guide

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions.

All other marks and names mentioned herein may be trademarks of their respective companies.

2015 – 07 Rev. A00

Contents

About Your Monitor ..................................... 5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Monitor Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

LCD Monitor Quality and Pixel Policy. . . . . . . . . . . . . . . . . . . . . . 14

Setting Up the Monitor.................................. 15

Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Attaching the Vesa Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Connecting Your Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Removing the Vesa Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Removing the Monitor Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Wall Mounting (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Operating the Monitor .................................. 21

Turning on the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Using the Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . .21

Using the On-Screen Display (OSD) Menu . . . . . . . . . . . . . . . . . . . 23

Using Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Contents | 3

4| Contents

Troubleshooting ....................................... 35

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Product Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Appendix ..............................................40

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

FCC Notices (U.S. only) and Other Regulatory Information . . . . . . . . 40

Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Setting Up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

About Your Monitor | 5

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Make sure that you have

received all the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Somefeatures or media may not be available in certain countries.

Monitor

Stand riser

Stand base

Vesa cover

Power cable (varies by country)

6| About Your Monitor

VGA Cable

•Drivers and documentation media

•Quick Setup Guide

•Safety and Regulatory Information

Product Features

The Dell E2016 flat panel display has an active matrix, thin-film transistor (TFT), liquid

crystal display (LCD), and LED backlight. The monitor features include:

• 49.40 cm (19.45 inch) active area display (Measured diagonally) 1440 x 900

resolution, plus full-screen support for lower resolutions.

• Tilt capability.

• Removable pedestal and Video Electronics Standards Association (VESA™) 100 mm

mounting holes for flexible mounting solutions.

• Plug and play capability if supported by your system.

• On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

• Software and documentation media includes an information file (INF), Image

color Matching File (ICM), Dell Display Manager software application and product

documentation. Dell Display Manager included (comes in the CD attached with the

monitor).

• Security lock slot.

• Asset Management Capability.

• Energy Star Compliant.

• EPEAT Silver Compliant.

• RoHS compliant.

• BFR/PVC- reduced.

• Arsenic-Free glass and Mercury Free for Panel only.

• Energy Gauge shows the energy level being consumed by the monitor in real time.

• TCO Certified Displays.

• Analog backlight dimming control for flicker free display.

• CECP (for China only).

About Your Monitor | 7

Identifying Parts and Controls

Front view

Label Description

1Function buttons (For more information, see Operating the Monitor)

2Power on/off button (with LED indicator)

Back View

Label Description Use

1VESA mounting holes

(100mmx100mm - behind

attached VESA cover)

Wall mount monitor using VESA-compatible

wall mount kit (100mmx100mm).

2Regulatory label Lists the regulatory approvals.

3Security-lock slot Secures monitor with security lock

(sold separately).

4Barcode serial number label Refer to this label if you need to contact Dell for

technical support.

NOTE: Service tag printing (EMEA region only).

5Dell Soundbar mounting slots Attaches the optional Dell Soundbar.

6Cable-management slot Use to organize cables by placing them through

the slot.

8| About Your Monitor

Bottom View

Label Description Use

1AC power connector To connect the monitor power cable.

2VGA port Connect your computer with VGA cable.

Monitor Specifications

Flat Panel Specifications

Screen type Active matrix - TFT LCD

Panel type In-plane switching type

Viewable image:

Diagonal 49.40 cm (19.45 inches)

Active Area:

Horizontal 418.61 mm (16.48 inches)

Vertical 262.35 mm (10.33 inches)

Area 109821.81 mm2(170.22inch2)

Pixel pitch 0.2915 mm x 0.2915 mm

Viewing angle:

Horizontal 178° (typical)

Vertical 178° (typical)

Luminance output 250 cd/m² (typical)

Contrast ratio 1000:1 (typical)

About Your Monitor | 9

Faceplate coating AG type, hard-coating 3H

Backlight LED

Response time 6ms Typ. g-to-g with OD (Fast mode)

Color depth 16.7 million colors

Color gamut (typical) 72%* (CIE1931)

*Color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.

Resolution Specifications

Horizontal scan range 30 kHz to 83 kHz (automatic)

Vertical scan range 56 Hz to 76 Hz (automatic)

Maximum preset resolution 1440x900 at 60 Hz

Video display capabilities 480i, 576i, 480p, 576p, 720p

Preset Display Modes

Display Mode Horizontal

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/

Vertical)

720 x 400 31.47 70 28.32 -/+

640 x 480 31.47 60 25.18 -/-

640 x 480 37.50 75 31.50 -/-

800 x 600 37.88 60 40 +/+

800 x 600 46.88 75 49.50 +/+

1024 x 768 48.36 60 65 -/-

1024 x 768 60.02 75 78.75 +/+

1152 x 864 67.50 75 108 +/+

1280 x 1024 64 60 108 +/+

1280 x 1024 80 75 135 +/+

1280 x 800 49.70 60 83.50 -/+

1440 x 900 55.94 60 106.50 -/+

1440 x 900 70.60 75 136.75 -/+

10 | About Your Monitor

Electrical Specifications

Video input signals Analog RGB, 0.7 Volts +/-5%, positive polarity at

75 ohm input impedance

Synchronization input signals Separate horizontal and vertical synchronization,

polarity-free TTL level, SOG (Composite SYNC on

green)

AC input voltage/

frequency/current

100 VAC to 240 VAC/

50 Hz or 60 Hz + 3 Hz/1.5 A (Max.)

Inrush current 120 V:30 A (Max.)

240 V:60 A (Max.)

Physical Characteristics

Connector type 15-pin D-subminiature (black connector).

Signal cable type Analog: Detachable, D-Sub, 15 pins.

Dimensions (with stand):

Height 390.95 mm (15.39 inches)

Width 454.21 mm (17.88 inches)

Depth 180 mm (7.09 inches)

Dimensions (without stand):

Height 297.95 mm (11.73 inches)

Width 454.21 mm (17.88 inches)

Depth 50.99 mm (2 inches)

Stand dimensions:

Height 176.80 mm (6.96 inches)

Width 250 mm (9.84 inches)

Depth 180 mm (7.09 inches)

Weight:

With packaging 4.18 kg (9.22 lb)

With stand assembly and cables 3.05 kg (6.72 lb)

Without stand

assembly (for wall mount or VESA

mount considerations - no

cables)

2.29 kg (5.05 lb)

Stand assembly 0.52 kg (1.15 lb)
