Dell™ OptiPlex™ 360

Service Manual

Models DCSM and DCNE

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

If you purchased a Dell™ nSeries computer, any references in this document to

Microsoft

Windows

operating systems are not applicable.

____________________

Information in this document is subject to change without notice.

Reproduction of these material in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and OptiPlex are trademarks of Dell Inc.; Intel is

a registered trademark of Intel Corporation in the U.S. and other countries; Microsoft, Windows,

Windows Vista, and the Windows Vista start button logo are either trademarks or registered trademarks

of Microsoft Corporation in the United States and/or other countries; Bluetooth is a registered

trademark of Bluetooth SIG Inc., and is used under license by Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Models DCSM and DCNE

March 2009 Rev. A01

Contents 3

Contents

1 Before Working on Your Computer . . . . . . 9

Recommended Tools. . . . . . . . . . . . . . . . . . . . 9

Before Working on Your Computer . . . . . . . . . . . . 9

Turning Off Your Computer . . . . . . . . . . . . . 10

Inside View of Your Computer . . . . . . . . . . . . . . 11

Mini Tower Computer. . . . . . . . . . . . . . . . 11

Desktop Computer . . . . . . . . . . . . . . . . . 12

System Board Components . . . . . . . . . . . . . . . 13

Mini Tower Computer System Board Components . 13

Desktop Computer System Board Components . . 15

After Working on Your Computer . . . . . . . . . . . . 17

2 Computer Cover . . . . . . . . . . . . . . . . . . . . 19

Mini Tower Computer Cover. . . . . . . . . . . . . . . 19

Removing the Mini Tower Computer Cover . . . . 19

Replacing the Mini Tower Computer Cover . . . . 21

Desktop Computer Cover . . . . . . . . . . . . . . . . 21

Removing the Desktop Computer Cover . . . . . . 21

Replacing the Desktop Computer Cover . . . . . . 23

4Contents

3 Drive Bezel. . . . . . . . . . . . . . . . . . . . . . . 25

Removing the Drive Bezel . . . . . . . . . . . . . . . . 25

Replacing the Drive Bezel . . . . . . . . . . . . . . . . 26

Removing a Drive Bezel Insert. . . . . . . . . . . . . . 27

Replacing a Drive Bezel Insert . . . . . . . . . . . . . 28

4 Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

PCI and PCI Express Cards. . . . . . . . . . . . . . . . 29

Removing a PCI or PCI Express Card From a Mini Tower Computer

Installing or Replacing a PCI or PCI Express Card in a Mini Tower

Computer . . . . . . . . . . . . . . . . . . . . . . 31

Removing a PCI or PCI Express Card From a Desktop Computer

Installing or Replacing a PCI or PCI Express Card in a Desktop

Computer . . . . . . . . . . . . . . . . . . . . . . 36

PS/2 Serial-Port Adapter. . . . . . . . . . . . . . . . . 41

Removing a PS/2 Serial-Port Adapter From a Mini Tower

Computer . . . . . . . . . . . . . . . . . . . . . . 41

Installing or Replacing a PS/2 Serial-Port Adapter in a Mini Tower

Computer . . . . . . . . . . . . . . . . . . . . . . 42

Removing a PS/2 Serial-Port Adapter From a Desktop Computer

Installing or Replacing a PS/2 Serial-Port Adapter in a Desktop

Computer . . . . . . . . . . . . . . . . . . . . . . 47

Removing a Card From the Optional Riser-Card Cage. . 50

Installing or Replacing a Card in the Optional Riser-Card Cage 52

Contents 5

5Drives. . . . . . . . . . . . . . . . . . . . . . . . . . . 55

About the Drives . . . . . . . . . . . . . . . . . . . . . 55

Recommended Drive Cable Connections . . . . . 55

Connecting Drive Cables . . . . . . . . . . . . . . 55

Drive Interface Connectors. . . . . . . . . . . . . 56

Connecting and Disconnecting Drive Cables . . . 56

Optical Drive . . . . . . . . . . . . . . . . . . . . . . . 57

Removing an Optical Drive From the Mini Tower Computer 57

Replacing or Adding an Optical Drive in the Mini Tower Computer

Removing an Optical Drive Panel Insert . . . . . . 59

Installing an Optical Drive Panel Insert . . . . . . 59

Removing the Optical Drive From the Desktop Computer 59

Replacing the Optical Drive in the Desktop Computer 60

Floppy Drive or Media Card Reader . . . . . . . . . . . 62

Removing a Floppy Drive or Media Card Reader From the Mini

Tower Computer . . . . . . . . . . . . . . . . . . 62

Replacing or Adding a Floppy Drive or Media Card Reader in the

Mini Tower Computer. . . . . . . . . . . . . . . . 64

Removing a Floppy Drive or Media Card Reader From the Desktop

Computer . . . . . . . . . . . . . . . . . . . . . . 66

Replacing or Adding a Floppy Drive or Media Card Reader in the

Desktop Computer . . . . . . . . . . . . . . . . . 68

Hard Drives. . . . . . . . . . . . . . . . . . . . . . . . 70

Removing a Hard Drive From the Mini Tower Computer 70

Replacing or Adding a Hard Drive in a Mini Tower Computer 72

Removing a Hard Drive From a Desktop Computer 76

Replacing or Adding a Hard Drive in a Desktop Computer 77

6Contents

6 I/O Panel . . . . . . . . . . . . . . . . . . . . . . . . 81

Removing the I/O Panel . . . . . . . . . . . . . . . . . 81

Replacing the I/O Panel . . . . . . . . . . . . . . . . . 83

7 Processor Heat-Sink Assembly . . . . . . . 85

Removing the Processor Heat-Sink Assembly . . . . . 85

Replacing the Processor Heat-Sink Assembly . . . . . 87

8 Memory Modules . . . . . . . . . . . . . . . . . . 89

Removing a Memory Module . . . . . . . . . . . . . . 89

Replacing or Adding a Memory Module. . . . . . . . . 90

9 Coin-Cell Battery . . . . . . . . . . . . . . . . . . 93

Removing the Coin-Cell Battery . . . . . . . . . . . . . 93

Replacing the Coin-Cell Battery . . . . . . . . . . . . . 94

10 Speakers . . . . . . . . . . . . . . . . . . . . . . . . 95

Removing a Speaker . . . . . . . . . . . . . . . . . . . 95

Replacing a Speaker. . . . . . . . . . . . . . . . . . . 97

11 Processor. . . . . . . . . . . . . . . . . . . . . . . . 99

Removing the Processor . . . . . . . . . . . . . . . . . 99

Contents 7

Replacing the Processor . . . . . . . . . . . . . . . . 100

12 Power Supply . . . . . . . . . . . . . . . . . . . . 103

Mini Tower Computer Power Supply . . . . . . . . . . 103

Removing the Power Supply From the Mini Tower Computer 103

Replacing the Power Supply in the Mini Tower Computer 104

Power Connectors in the Mini Tower Computer . . 106

Desktop Computer Power Supply . . . . . . . . . . . . 110

Removing the Power Supply From the Desktop Computer 110

Replacing the Power Supply in the Desktop Computer 111

Power Connectors in the Desktop Computer . . . 112

13 BIOS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Flashing the BIOS From a CD . . . . . . . . . . . . . . 117

Flashing the BIOS From the Hard Drive . . . . . . . . . 118

14 System Board . . . . . . . . . . . . . . . . . . . . 119

Removing the System Board . . . . . . . . . . . . . . . 119

Replacing the System Board. . . . . . . . . . . . . . . 120

15 Troubleshooting . . . . . . . . . . . . . . . . . . . 123

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Power Lights . . . . . . . . . . . . . . . . . . . . 123

Beep Codes . . . . . . . . . . . . . . . . . . . . . 124

Diagnostic Lights . . . . . . . . . . . . . . . . . . 126

Diagnostic Light Codes During POST. . . . . . . . 127

8Contents

System Messages. . . . . . . . . . . . . . . . . 134

Hardware Troubleshooter . . . . . . . . . . . . 135

Dell Diagnostics . . . . . . . . . . . . . . . . . . . . 136

When to Use the Dell Diagnostics . . . . . . . . 136

Starting the Dell Diagnostics From Your Hard Drive 136

Starting the Dell Diagnostics From the Drivers and Utilities Disc

137

Dell Diagnostics Main Menu . . . . . . . . . . . 139

Solving Problems . . . . . . . . . . . . . . . . . . . 141

Battery Problems . . . . . . . . . . . . . . . . . 141

Drive Problems . . . . . . . . . . . . . . . . . . 142

Error Messages . . . . . . . . . . . . . . . . . . 144

IEEE 1394 Device Problems . . . . . . . . . . . . 145

Keyboard Problems . . . . . . . . . . . . . . . . 145

Lockups and Software Problems . . . . . . . . . 146

Memory Problems . . . . . . . . . . . . . . . . 148

Mouse Problems . . . . . . . . . . . . . . . . . 148

Network Problems . . . . . . . . . . . . . . . . 149

Power Problems . . . . . . . . . . . . . . . . . 150

Printer Problems . . . . . . . . . . . . . . . . . 151

Scanner Problems . . . . . . . . . . . . . . . . 152

Sound and Speaker Problems . . . . . . . . . . 153

Video and Monitor Problems . . . . . . . . . . . 154

Dell Technical Update Service . . . . . . . . . . . . 156

Dell Support Utility. . . . . . . . . . . . . . . . . . . 156

Accessing the Dell Support Utility . . . . . . . . 156

Clicking the Dell Support Icon . . . . . . . . . . 156

Double-Clicking the Dell Support Icon . . . . . . 157

16 Contacting Dell . . . . . . . . . . . . . . . . . . . 159

Before Working on Your Computer 9

Before Working on Your Computer

This document provides procedures for removing and installing the

components in your computer. Unless otherwise noted, each procedure

assumes that:

• You have performed the steps in "Before Working on Your Computer" on

page 9.

• You have read the safety information that shipped with your computer.

• When replacing a component, you have already removed the original, if

installed.

NOTE: The color of your system and certain system components may appear

differently than shown in this document.

Recommended Tools

The procedures in this document may require the following tools:

• Small flat-blade screwdriver

•Phillipsscrewdriver

• Small plastic scribe

• Flash BIOS update (see the Dell Support website at

support.dell.com

)

Before Working on Your Computer

Use the following safety guidelines to help protect your computer from

potential damage and to help to ensure your own personal safety.

WARNING: Before working inside your computer, read the safety information

that shipped with your computer. For additional safety best practices information,

see the Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance.

CAUTION: Only a certified service technician should perform repairs on your

computer. Damage due to servicing that is not authorized by Dell is not covered by

your warranty.

10 Before Working on Your Computer

CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,

not on the cable itself. Some cables have connectors with locking tabs; if you are

disconnecting this type of cable, press in on the locking tabs before you

disconnect the cable. As you pull connectors apart, keep them evenly aligned to

avoid bending any connector pins. Also, before you connect a cable, ensure that

both connectors are correctly oriented and aligned.

CAUTION: To avoid damaging the computer, perform the following steps before

you begin working inside the computer.

Ensure that the work surface is flat and clean to prevent the computer

cover from being scratched.

Turn off your computer (see "Turning Off Your Computer" on page 10).

CAUTION: To disconnect a network cable, first unplug the cable from your

computer and then unplug the cable from the network device.

Disconnect all telephone or network cables from the computer.

Disconnect your computer and all attached devices from their electrical

outlets.

Press and hold the power button while the system is unplugged to ground

the system board.

CAUTION: Before touching anything inside your computer, ground yourself by

touching an unpainted metal surface, such as the metal at the back of the

computer. While you work, periodically touch an unpainted metal surface to

dissipate static electricity, which could harm internal components.

Turning Off Your Computer

CAUTION: To avoid losing data, save and close all open files and exit all open

programs before you turn off your computer.

Shut down the operating system.

Ensure that the computer and all attached devices are turned off. If your

computer and attached devices did not automatically turn off when you

shut down your operating system, press and hold the power button for

about 4 seconds to turn them off.

Autres manuels pour Vostro 360

Table des matières

Autres manuels Dell Ordinateur de bureau

Dell

Dell Inspiron 5676 Manuel d'exploitation et d'entretien

Dell

Dell Precision Workstation 380 Manuel utilisateur

Dell

Dell studio XPS Instructions d'utilisation

Dell

Dell OptiPlex 580 Manuel utilisateur

Dell

Dell OptiPlex GX620 Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

Dell

Dell Vostro 5470 Mode d’emploi

Dell

Dell Dimension 4700C Manuel utilisateur

Dell

Dell Precision T5400 Manuel utilisateur

Dell

Dell XPS /Dimension Gen 2 Manuel utilisateur

Dell

Dell Inspiron 20 3043 Manuel utilisateur

Dell

Dell PowerVault NX200 Manuel utilisateur

Dell

Dell Precision 3430 Small Form Factor Manuel utilisateur

Dell

Dell Vostro 410 Manuel utilisateur

Dell

Dell Inspiron One 0DTN4TA00 Manuel utilisateur

Dell

Dell Precision Tower 3420 Manuel utilisateur

Dell

Dell Vostro 220 - Vostro 220 Slim Desktop... Manuel du propriétaire

Dell

Dell OptiPlex FX160 Manuel utilisateur

Dell

Dell Inspiron 0VM0DJA00 Manuel utilisateur

Dell

Dell OptiPlex SX280 Manuel utilisateur

Dell

Dell Precision 5860 Tower Manuel utilisateur

Dell

Dell Dimension 4500S Manuel utilisateur

Dell

Dell OptiPlex 745 Manuel utilisateur

Dell

Dell Precision Workstation 450 Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

HP Z1 Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Compaq

Compaq iPAQ Internet Device Manuel utilisateur
