Dell Precision T3600 Manuel utilisateur

DELL PRECISION™

T3600

Technical

Guidebook

TABLE OF CONTENTS

OVERVIEW

External Chassis Views 3

Motherboard Layout 4-5

MARKETING SYSTEM CONFIGURATIONS

Operating System, Chipset 6

Processor 7

Memory 8

Graphics/Video Controllers 9

Drives and Removable Storage 10-11

System Expansion Slots, External Ports/Connectors 11

Hard Drive Controller, Communications—Network Adapter, Audio and Speakers, Keyboard and Mouse 12

Security, Service and Support, Software 13

DETAILED ENGINEERING SPECIFICATIONS

System Dimensions (Physical), System Expansion Slots 14

System Level Environmental and Operating Conditions, Power 15-16

Audio—Integrated, Communications– Integrated LAN 17-18

Communications—Add in Network Interface Card (NIC) 18

Communications—Add in 1394 card, 19

Graphics/Video Controllers 20-30

Hard Drives 31-41

Optical Drive 42-43

Media Card Reader 44

BIOS Defaults 45-46

Chassis Enclosure and Ventilation Requirements 47

ADDITIONAL INFORMATION

Statement of Volatility (SOV) 48-50

PERC PCIe Controller 16

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

EXTERNAL CHASSIS VIEWS

FRONT VIEW

1 Optical drive 7 Power button, power light

2 Optical drive eject button 8 Microphone connector

3 Optical drive 9 Headphone connector

4 Optical drive eject button 10 Diagnostic lights (4)

5 USB 3.0 connector (1) 11 USB 2.0 connectors (3)

6 Drive activity light

BACK VIEW

12 Back Panel 17 Power connector

14 Blank slot (1)

15 Security cable slot

13 Active expansion slots (6) 18 Power supply unit (PSU)

release latch

16 Padlock ring

1 Line-out connector 7 Serial connector

2 Network link Integrity

light

8 USB 2.0 connectors (2)

3 Network adapter

connector

9 PS/2 keyboard

connector

4 Network activity light 10 USB 2.0 connectors (3)

BACK PANEL CONNECTORS

5 PS2/mouse connector 11 USB 3.0 connector (1)

6 Line-in/microphone

connector

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

Number Name Number Name

1 PCI slot 13 (not populated)

2 PCIe x16 slot (wired as x4) 14 AUX_LED connector

3 PCIe x16 slot 15 HDD1 fan connector

4 PCIe X1 slot 16 Battery

5 accelerated graphics port (PCIe x16) 17 Speaker enable

6 PCIe x16 slot (wired as x4) 18 System fan 1 connector

7 USB 3.0 front panel connector 19 Remote power enable

8 DIMM slots 20 (not populated)

9 Intruder 21 HDD temperature sensor connector

10 CPU1 fan socket 22 (not populated)

11 CPU1 23 System 2 fan connector

12 DIMM slots 24 (not populated)

MT System Board Components

MOTHERBOARD LAYOUT

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

Number Name

25 System fan 3 connector

26 PSWD jumper

27 Front panel & USB 2.0 connector

28 Internal speaker connector

29 Internal USB 2.0 connector

30 Optical drive connectors

31 24-pin power connector

32 Internal USB 2.0 connector

33 CPU1 power connector

MT System Board Components

MOTHERBOARD LAYOUT (CONT.)

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

MARKETING SYSTEM CONFIGURATIONS

NOTE: Oerings may vary by country. For more information regarding the conﬁguration of your computer, click

Start>Help and Support and select the option to view information about your computer.

OPERATING SYSTEM

Windows 7® operating system—

Factory Installed

Microsoft® Windows 7® Professional (32 and 64 bit)

Microsoft® Windows 7® Ultimate (32 and 64 bit)

Windows Vista® operating system—

Driver availability only via Dell.com

Windows Vista® Business SP2 (32 and 64 bit),

Windows Vista® Ultimate SP2 (32 bit and 64 bit)

Other FreeDOS drop in the box for (N-series),

Ubuntu® Linux version 11.10 (factory installed in China only)

Windows XP® operating system

Driver availability only via Dell.com

Microsoft® Windows XP® Professional (32 and 64 bit),

Note: Loading and booting an XP image requires a discrete PCIe

hard disk controller (like the PERC H310 or PERC H710P) with XP

driver

Red Hat Enterprise Linux RHEL workstation 6.1 Factory installed

RHEL 5.7 supported

CHIPSET

Chipset Intel C600 Chipset

Non-volatile memory on chipset

BIOS Conﬁguration SPI (Serial Peripheral Interface) 64Mbit (8MB) & 32Mbit (4MB)

TPM 1.2 Security Device (Trusted Platform Module)118KB

Non-TPM Available in select countries

NIC EEPROM LOM conﬁguration contained within SPI_FLASH – no dedicated

LOM EEPROM

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

PROCESSOR

NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and synchro-

nized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This allows customers to

reduce the number of conﬁgurations managed on a worldwide basis, thereby reducing their costs. They also enable companies

to implement global IT standards by locking in speciﬁc product conﬁgurations worldwide. The following GSP processors identi-

ﬁed below will be made available to Dell customers.

NOTE: Processor numbers are not a measure of performance. Processor availability subject to change and may vary by region/

country.

Intel® Eight Core Processors

Intel® Xeon E5-2665

2.4GHz, 20M, 115W VT-x, VT-d, TXT (vPro™) X

Intel® Six Core Processors

Intel® Xeon E5-1660

3.30GHz, 15M, 130W VT-x, VT-d, TXT (vPro™) X

Intel® Xeon E5-1650

3.20GHz, 12M, 130W VT-x, VT-d, TXT (vPro™) X—GSP

Intel® Four Core Processors

Intel® Xeon E5-1620

3.60GHz, 10M, 130W VT-x, VT-d, TXT (vPro™) X—GSP

Intel® Xeon E5-1607

3.00GHz, 10M, 130W VT-x, VT-d, TXT (vPro™) X—GSP

Intel® Xeon E5-1603

2.80GHz, 10M, 130W VT-x, VT-d, TXT (vPro™) X—GSP

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

MEMORY

NOTE: The Dell Precision T3600 has a four channel memory bus architecture. Dell recommends that all four memory channels

be populated with DIMMS for maximum memory performance. Please note, RDIMM ECC and NECC memory cannot be mixed.

1 The total amount of available memory will be less than 4GB on systems running 32-bit operating systems. The amount less depends on the actual

system configuration. To fully utilize 4GB or more of memory requires a 64-bit operating system.

Type: DDR3 Synch DRAM Non-ECC and RDIMM

Max Frequency 1600 MHz

DIMM Slots 4

DIMM Capacities Up to 16 GB

Minimum Memory 2 GB

Maximum System Memory 64GB1

Memory conﬁgurations

RDIMM ECC Memory

64GB (4 x 16 GB) DDR3, 1600 MHz X

32GB (4 x 8 GB) DDR3, 16000 MHz X

16GB (4 x 4 GB) DDR3, 1600 MHz X

8GB (4 x 2 GB) DDR3, 1600 MHz X

4GB1(2 x 2 GB) DDR3, 1600 MHz, X

8GB (4 x 2 GB) DDR3, 1600 MHz X

4GB1(2 x 2 GB) DDR3, 1600 MHz, X

2GB (1 x 2 GB) DDR3, 1600 MHz, X

Non- ECC Memory (NECC)

4GB1(2 x 2 GB) DDR3, 1333 MHz, X

8GB (4 x 2 GB) DDR3, 1333 MHz X

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

GRAPHICS/VIDEO CONTROLLER

NOTE: System supports full height (FH) cards unless speciﬁed

NOTE: Dual Graphic options available on select cards. Dual Graphics with NVIDIA SLI (Scalable Link Interface) options available

on NVIDIA Quadro 5000.

Optional Graphic/Video Options Included Dongle

High End 3D

6.0GB NVIDIA Quadro 6000 with (2) DP and (1) DVI (1) DP-DVI

2.5GB NVIDIA Quadro 5000 with (2) DP and (1) DVI (1), DP-DVI, (1) DVI-VGA

Mid-range 3D

2.0GB NVIDIA Quadro 4000 with (2) DP and (1) DVI (1) DP-DVI, (1) DVI-VGA

2.0GB AMD FirePro V7900 with (4) DP (1) DP-DVI

1.0GB NVIDIA Quadro 2000 with (2) DP and (1) DVI (1) DP–DVI, (1) DVI-VGA

2.0GB AMD FirePro V5900 with (2) DP and (1) DVI 1) DP–DVI

Entry 3D

1.0GB NVIDIA Quadro 600 with (1) DP and (1) DVI (1) DP–DVI, (1) DVI-VGA

1.0GB AMD FirePro V4900 with (2) DP and (1) DVI 1) DP–DVI, (1) DVI-VGA

Professional 2D

512MB NVIDIA NVS 300 with (1) DMS-59 (1) DMS-59–Dual DVI

512MB AMD FirePro 2270 with (1) DMS-59 (1) DMS-59–Dual DVI

Multi Core Compute (GPGPU)

6GB NVIDIA Tesla C2075 Computing GPGPU - no I/O

DELL™ PRECISION™ T3600 TECHNICAL GUIDEBOOK

DRIVES AND REMOVABLE STORAGE

Bays:

5.25-inch Optical Bay Supported (External) 1

Slimline Optical Bay Supported (External) 1

Optical Drives Supported (maximum) 2

Hard Drive Bay Supported (Internal) 2

Hard Drives Supported 3.5”/2.5” (maximum) 2/4

Interface:

SATA 3.0 (AHCI) 2

3.5” Hard Drives:

3TB1SATA 7200 RPM HDD X

2TB1SATA 7200 RPM HDD X

1TB1SATA 7200 RPM HDD X

500GB1SATA 7200 RPM HDD X

250GB1SATA 7200 RPM HDD X

2.5” Hard Drives:

256GB1SATA Solid State Drive X

900GB1SAS 10k RPM HDD X

600GB1SAS 10k RPM HDD X

146GB1SAS 15k RPM HDD X

500GB1SATA 7200 RPM HDD X

320GB1SATA 7200 RPM HDD X

1For hard drives, GB means 1 billion bytes; actual capacity varies with preloaded material and operating environment and will be less.
