Dell OptiPlex XE Manuel du propriétaire

Setup and Features Information

Desktop — Front and Back View

1drive activity light

2Wi-Fi activity light

3network activity light 1

4network activity light 2

5DVD drive bay

6USB 2.0 connectors (2)

7external power button connector

8diagnostic lights (4)

9power button, power light

10 power supply diagnostic button

11 power supply diagnostic light

12 cover-release latch

13 padlock ring

14 security cable slot

15 power cable connector

16 back panel connectors

17 expansion card slots (4)

5234

Regulatory Model: D01D; Regulatory Type: D01D001 – Desktop

Regulatory Model: D01S; Regulatory Type: D01S001 – Small Form Factor

Dell™OptiPlex™XE

About Warnings

WARNING: A WARNING indicates a potential for

property damage, personal injury, or death.

November 2009

P609Nam0.fm Page 1 Thursday, October 15, 2009 5:17 PM

Small Form Factor — Front and Back View

1drive activity light

2Wi-Fi activity light

3network activity light 1

4network activity light 2

5DVD drive bay

6USB 2.0 connectors (2)

7external power button connector

8diagnostic lights (4)

9power button, power light

10 power supply diagnostic button

11 power supply diagnostic light

12 cover-release latch

13 padlock ring

14 security cable slot

15 power cable connector

16 back panel connectors

17 expansion card slots (2)

1617

P609Nam0.fm Page 2 Thursday, October 15, 2009 5:17 PM

Desktop and Small Form Factor — Back Panel

1serial connector 1

2link integrity light 2

3network adapter connector 2

4network activity light 2

5link integrity light 1

6network adapter connector 1

7network activity light 1

8serial connector 2

9Wi-Fi connector

10 PS/2 mouse connector

11 line-out connector

12 line-in/microphone connector

13 PS/2 keyboard connector

14 VGA connector

15 24V powered USB 2.0 connector

16 USB 2.0 connectors (4)

17 DisplayPort

141517

3 4 5 6 7

P609Nam0.fm Page 3 Thursday, October 15, 2009 5:17 PM

1Connect the network cable

(optional).

2Connect the USB keyboard

or mouse (optional).

3Connect the monitor using only one of the following cables:

aThe blue VGA cable. bThe DisplayPort cable. cThe DVI cable to

DisplayPort adapter.

dThe VGA cable to

DisplayPort adapter.

4Connect the

power cable(s).

5Press the power buttons on the monitor and the computer.

Quick Setup

WARNING: Before you begin any of the procedures in this

section, read the safety information that shipped with your

computer. For additional best practices information,

see www.dell.com/regulatory_compliance.

NOTE: Some devices may not be included if you did

not order them.

P609Nam0.fm Page 4 Thursday, October 15, 2009 5:17 PM

Specifications

NOTE: The following specifications are only those required by law

to ship with your computer. For a complete and current listing of the

specifications for your computer, go to support.dell.com.

System Information

Chipset Intel®Q45/ICH10DO Embedded Chipset

Processor

•Intel

Core™2 E7400

•Intel

Pentium

Dual Core E5300

•Intel

Celeron

440

Video

Video type:

Integrated

integrated on system board

Discrete

PCI-E x16 dual-channel graphics card

with one DVI port and one DisplayPort

connectors.

Video memory:

Integrated

Microsoft®Windows®XP

up to 512 MB shared video memory

(with 1 GB system memory)

up to 1GB shared video memory

(with 2 GB or more of system memory)

Windows Vista®and Windows 7

up to 272 MB shared video memory

(with 1 GB system memory)

up to 784 MB shared video memory

(with 2 GB system memory)

up to 1296 MB shared video memory

(with 3 GB system memory)

up to 1808 MB shared video memory

(with 4 GB system memory)

up to 3856 MB shared video memory

(with 8 GB system memory)

NOTE: Video memory will be dynamically

assigned based on the total computer

memory and graphic applications.

Discrete

512 MB

Memory

Memory module

connector

4 DIMM slots

Memory module

capacity

1 GB, 2 GB

Memory type 1066 MHz DDR3

Minimum memory 1 GB

Maximum memory 8 GB

Video (continued)

P609Nam0.fm Page 5 Thursday, October 15, 2009 5:17 PM

Drives Desktop Small Form Factor

Externally accessible:

5.25 inch drive bays

one one (slimline)

Internally accessible:

3.5 inch SATA drive bay

two one

Available devices:

2.5 inch SATA hard drives

two two

3.5 inch SATA hard drives

two one

5.25 inch SATA DVD+/-RW

drive

one one (slimline)

Control Lights and Diagnostic Lights

Power button light Blue light — Solid blue light indicates

power-on state; blinking blue light indicates

sleep state of the computer.

Amber light — Solid amber light when the

computer does not start indicates a problem

with the system board or power supply.

Blinking amber light indicates a problem

with the system board.

Drive activity light Displays the SATA hard drive or

CD/DVD activity.

Blue light — Blinking blue light

indicates that the computer is reading

data from or writing data to the drive.

Network connectivity light Blue light — A good connection exists

between the network and the computer.

Off (no light) — The computer is not

detecting a physical connection to the network.

Diagnostic lights Four lights located on the front panel of the

computer. For information on the

diagnostic lights, see the Service Manual

available on the Dell Support website at

support.dell.com/manuals.

Wi-Fi®connectivity light Blue light — A good connection exists

between the network and the computer.

Off (no light) — The computer is not

detecting a physical connection to the network.

Power Wattage Maximum heat

dissipation

Voltage

Desktop (EPA) 300 W 1204 (BTU/hr) 100-240 VAC,

50/60 Hz, 6.0 A

Small Form

Factor (EPA)

280 W 1124 (BTU/hr) 100-240 VAC,

50/60 Hz, 5.0 A

NOTE: Heat dissipation is calculated by using the power supply

wattage rating.

NOTE: See the safety information that shipped with your computer

for important voltage–setting information.

Coin-cell battery 3 V CR2032 lithium coin cell

Control Lights and Diagnostic Lights (continued)

P609Nam0.fm Page 6 Thursday, October 15, 2009 5:17 PM

Finding More Information and Resources

See the safety and regulatory documents that shipped with your computer

and the regulatory compliance website at

www.dell.com/regulatory_compliance for more information on:

• Safety best practices

• Warranty

• Terms and Conditions

• Regulatory certification

• Ergonomics

• End User License Agreement

________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written

permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and OptiPlex are trademarks

of Dell Inc.; Microsoft, Windows, and Windows Vista are either trademarks or

registered trademarks of Microsoft Corporation in the United States and/or

other countries; Intel, Celeron, and Pentium are registered trademarks and Core

is a trademark of Intel Corporation in the U.S. and other countries; WI-FI is a

registered trademark of Wireless Ethernet Compatibly Alliance, Inc.

Other trademarks and trade names may be used in this document to refer to

either the entities claiming the marks and names or their products. Dell Inc.

disclaims any proprietary interest in trademarks and trade names other than

its own.

Physical Desktop Small Form Factor

Height 10.93 cm

(4.30 inches)

8.52 cm

(3.35 inches)

Width 39.65 cm

(15.60 inches)

28.96 cm

(11.40 inches)

Depth 34.90 cm

(13.70 inches)

32.36 cm

(12.70 inches)

Weight (Minimum) 9.38 kg (20.60 lbs) 6.48 kg (14.3 lbs)

Environmental

Temperature

Operating

10° to 45°C (50° to 113°F)

Storage

–40° to 60°C (–40° to 140°F)

Relative humidity 20% to 80% (noncondensing)

Altitude:

Operating

below 3048 m (10,000 ft)

Storage

below 10,668 m (35,000 ft)

Airborne contaminant

level

G2 or lower as defined by ISA-S71.04-1985

P609Nam0.fm Page 7 Thursday, October 15, 2009 5:17 PM
