Dell™ Inspiron™ 560/570:

Comprehensive Specifications

This document provides information that you may need when setting up,

updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration

of your computer, click Start → Help and Support and select the option to view

information about your computer.

Processor Types

Inspiron 560

•Intel

Celeron

• Intel Pentium

Dual Core

• Intel Core™2 Duo

•IntelCore2Quad

Inspiron 570

•AMD

Sempron™

• AMD Athlon™ II X2/X3/X4

• AMD Phenom™ II X2/X3/X4

Memory

Connectors four internally-accessible DDR3 DIMM sockets

Memory-module capacities 1 GB and 2 GB

Memory type 1066-MHz DDR3 DIMM;

non-ECC memory only

Memory configurations possible 1 GB, 2 GB, 3 GB, 4 GB, 5 GB, 6 GB, 7 GB,

and 8 GB

NOTE: Memory configurations of more than 4 GB

require a 64-bit operating system.

System Chipset

Inspiron 560

Inspiron 570

Intel G43

AMD 785G

Drives

Externally accessible

• two 5.25-inch bays for SATA DVD-ROM, SATA

DVD+/-RW Super Multi Drive, or Blu-ray

Disc™ combo drive

• one 3.5-inch FlexBay for an optional Media Card

Reader

Internally accessible two 3.5-inch bays for SATA hard drives

Video

Integrated

Inspiron 560

Inspiron 570

Intel GMA X4500

ATI Radeon™ HD 4200

Discrete PCI Express x16 card (optional)

Audio

Type integrated 7.1 channel, High Definition Audio

System Board Connectors

Memory four 240-pin connectors

PCI one 124-pin connector

PCI Express x1 two 36-pin connectors

PCI Express x16 one 164-pin connector

Power (system board) one 24-pin EPS 12V connector

(ATX-compatible)

Processor fan one 4-pin connector

Chassis fan one 3-pin connector

Front USB connector three 9-pin connectors

Front audio connector one 9-pin connector for 2-channel stereo sound

and microphone

SATA four 7-pin connectors

External Connectors

Network adapter one RJ45 connector

USB two front panel and four back-panel

USB 2.0-compliant connectors

Audio front panel — one headphone and one

microphone connector

back panel — six connectors for 7.1 channel

support

Video one 15-pin VGA connector and

one 19-pin HDMI connector

Communications

Wireless (optional) PCI Express WiFi card supporting 802.11a/b/g/n

Modem (optional) PCI modem

Expansion Slots

PCI

Connectors

one

Connector size

124-pin

Connector data width (maximum)

32 bit

Bus speed

33 MHz

PCI Express x16

Connectors

one

Connector size

164-pin

Connector data width (maximum)

16 PCI Express lanes

Bus speed 16 GB/s (bi-directional)

System Board Connectors

(continued)

PCI Express x1

Connectors

two

Connector size

36-pin

Connector data width (maximum)

1 PCI Express lane

Bus speed

Inspiron 560 500 MB/s (bi-directional)

Inspiron 570 1000 MB/s (bi-directional)

Power

DC Power Supply

Wattage 300 W

Maximum heat dissipation 1574 BTU/hr

NOTE: Heat dissipation is calculated by using the power supply wattage rating.

Input voltage 115/230 VAC

Input frequency 50/60 Hz

Rated output current 7/4 A

Battery

Coin-cell battery 3-V CR2032 lithium

Physical

Height 375.92 mm (14.80 inches)

Width 176.02 mm (6.93 inches)

Depth 442.98 mm (17.44 inches)

Weight (starting at) 7.9 kg (17.4 lb)

Computer Environment

Temperature range:

Operating

10°C to 35°C (50°F to 95°F)

Storage

-40°C to 65°C (-40°F to 149°F)

Expansion Slots

(continued)

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is

strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and Inspiron are trademarks of Dell Inc.; Intel, Celeron,

and Pentium are registered trademarks and Core is a trademark of Intel Corporation in the U.S. and other

countries; AMD, AMD Sempron, AMD Athlon, AMD Phenom, and ATI Radeon are trademarks of Advanced

Micro Devices, Inc; Microsoft, Windows, and the Windows start button logo are either trademarks or

registered trademarks of Microsoft Corporation in the United States and/or other countries; Blu-ray Disc

is a trademark of the Blu-ray Disc Association.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade

names other than its own.

Model: DCME and D06M Type: D06M001 November 2009 Rev. A00

Relative humidity 20% to 80% (non-condensing)

Maximum vibration (using a random-vibration spectrum that simulates user

environment):

Operating

0.25 GRMS

Storage

2.2 GRMS

Maximum shock (measured with hard drive in head-parked position and a 2-ms half-sine

pulse):

Operating

40G for 2 ms with a change in velocity of 20 in/s

(51 cm/s)

Storage

50G for 26 ms with a change in velocity of

320 in/s (813 cm/s)

Altitude (maximum):

Operating

-15.2 to 3048 m (-50 to 10,000 ft)

Storage

-15.2 to 10,668 m (-50 to 35,000 ft)

Airborne contaminant level G2 or lower as defined by

ISA-S71.04-1985

Computer Environment

(continued)
