Defy TWINMAID 920 Manuel utilisateur

INDEX

GET TO KNOW YOUR MACHINE

INSTALLATION

WASHING

DRAINING

RINSING

SPIN DRYING

PRECAUTIONS

AFTER USE

MAINTENANCE

HELP

DEFY SERVICE CENTRES

WARRANTY

SPECIFICATIONS

OWNER’S MANUAL

You can rely on Defy

www.defy.co.za

TWINMAID

920

Getting to know your machine

You are now the proud owner of one of the finest and most modern washing machines

that today’s technology can produce. You are going to make a great team together. But

first it will pay if you really get to know each other. This book will tell you all you need

to know about your machine, what it will do and how to do it. Please read all the instruc-

tions carefully before operating the machine .

WATER INLET WASH TIMER

15 MINUTES

WASH ACTION

SELECTOR

WASH / SPIN & DRAIN

SELECTORSPIN TIMER

5 MINUTES

The control panel

The wash and spin tubs

SPIN DRYER LID

SAFETY COVER

DRAIN HOSE

DRAIN HOSE CLAMP

POWER CORD AND PLUG

WATER INLET

WASH TANK LID

WASH TANK

FILTER BAG

FPULSATOR

WATERDRAINFILTER

AT REAR OF MACHINE

H - HIGH

M - MEDIUM

L-LOW

Accessories

SPIN TUB

LID COVER WATER SUPPLY

HOSE DRAIN HOSE

AND CLAMP

INSTALLATION

850mm. MAXIMUM

CONNECTTHEINLET

HOSE TO THE WATER TAP

AND TO THE MACHINE.

PUSH THE SMALL END OF

THE DRAIN HOSE OVER

THE PUMP OUTLET

HANGTHEBIGEND

(WITH HOOK) OVER A

DRAIN OUTLET

( A DRAIN PIPE, BATH

OR SINK)

NOT HIGHER THAN 1.5

METRES ABOVE FLOOR

LEVEL.

THE MACHINE MUST STAND ON A LEVEL SURFACE

DO NOT STAND THE MACHINE WHERE

IT IS EXPOSED TO DIRECT SUNLIGHT

OR RAIN

4TURN THE TIMER

CONTROL KNOBS

TO "0"

PUMP OUTLET

AT BACK OF

MACHINE

700mm MINIMUM

PUSH THE 3

PINPLUG

INTO A 15A.

EARTHED

WALL

SOCKET.

WARNING

THIS

APPLIANCE

MUST BE

EARTHED.

WASHING

612

1REMOVE WASH TUB LID AND HANG

IT ON THE SIDE OF THE MACHINE 2

34FILL TO THE DESIRED WATER LEVEL

DEPENDING ON THE SIZE OF THE

WASH LOAD

WASH

TUB LID ON

SWITCH ON THE POWER AT

THE WALL SOCKET

5OPEN THE TAP AND FILL THE WASH

TUB WITH WATER TO THE

DESIRED WATER LEVEL.

THEN CLOSE THE TAP.

TURN THE SELECTOR KNOB

TO NORMAL OR

HEAVYWASH

TURN THE SELECTOR KNOB

TO WASH / SPIN

ADD SOAP POWDER AS DIRECTED.

USE ONLY DETERGENT DESIGNED

FOR TWIN TUB WASHING MACHINES.

H - HIGH

M - MEDIUM

L- LOW

612

WASHING Continued.

612

9THE WASHING MACHINE WILL START

WASHING AS PER THE SELECTED

TIME AND WASH PROGRAMME

3 CM.

IMPORTANT

NEVER TURN A KNOB

FURTHER THAN THE MARKING ON THE DIAL

TURN ANTI CLOCKWISE TO RETURN TO "0"

WARNING

PLACE THE WASHING IN THE TUB

ONE ARTICLE AT A TIME

TURN THE WASH TIMER KNOB

TO THE DESIRED TIME.

GENTLE WASH - SYNTHETICS,WOOL,SILK 2-5 MIN

NORMAL WASH - COTTON ,LINEN 5-15 MIN

HEAVY WASH - VERY DIRTY WASHING 9-15 MIN

612

NOTE

15 SECONDS BEFORE COMPLETION

OF THE WASH, AN ALARM BUZZER

WILL SOUND TOREMIND THE USER

THAT THE WASH CYCLEIS NEARLY

COMPLETE

AFTER THE WASHING IS COMPLETE,

REMOVE THE WASHING FROM THE

WASH TUB AND PLACE IT IN THE

SPIN DRUM

DRAINING

612

IF REQUIRED, ANOTHER LOAD MAY BE

WASHED IN THE SAME SOAPY WATER..

IF NOT, THE MODE SELECTOR KNOB

SHOULD BE TURNED TO DRAIN

THE SOAPY WATER WILL DRAIN

FROM THE MACHINE

IMPORTANT

NEVER TURN A KNOB

FURTHER THAN THE MARKING ON THE DIAL

TURN ANTI CLOCKWISE TO RETURN TO "0"

DRAIN

WARNING

612

RINSING

612

3 CM.

REMOVE THE WASH LOAD FROM

THE SPIN DRUM AND PLACE IT IN

THE EMPTY WASH TUB

CLOSE BOTH THE INNER AND

OUTER LIDS OF THE SPIN TUB

1PLACE THE WET WASHING IN THE

SPIN DRUM, DISTRIBUTING IT

EVENLY 2

PUSH THE WASHING DOWN GENTLY

INTO THE SPIN DRUM AND PLACE

THE DISC COVER IN THE DRUM

SO THAT IT COMPLETELY COVERS

THE WASH LOAD

TURN THE SPIN TIMER KNOB

TO APPROXIMATELY 2 MINUTES

OPEN THE TAP AND FILL THE WASH

TUB WITH WATER

TO THE DESIRED LEVEL

THEN CLOSE THE TAP

612

RINSING Continued

612

AFTER RINSING TURN THE MODE SELECTOR TO DRAIN

THIS WILL DRAIN OFF THE RINSE WATER

TURN THE SELECTOR KNOB TO

NORMAL

DRAIN

TURN THE WASH TIMER KNOB TO THE

REQUIRED TIME FOR RINSING.

DELICATE RINSE - SYNTHETICS,WOOL,SILK 2-5 MIN

NORMAL RINSE - COTTON ,LINEN 5-15 MIN

HEAVY RINSE - HEAVY ROBUST FABRICS 9-15 MIN

612

SPIN DRYING

CLOSE BOTH THE INNER AND

OUTER LIDS OF THE SPIN TUB

1PLACE THE WET WASHING IN THE

SPIN DRUM, DISTRIBUTING IT

EVENLY

PUSH THE WASHING DOWN GENTLY

INTO THE SPIN DRUM AND PLACE

THE DISC COVER IN THE DRUM

SO THAT IT COMPLETELY COVERS

THE WASH LOAD

RECOMMENDED SPIN TIMES

DELICATE FABRICS

ANDSYNTHETICS

WHITES

COTTON AND LINEN

HEAVY FABRICS

COTTON

1 MINUTE

2 TO 4 MINUTES

3 TO 5 MINUTES

TURN THE SPIN TIMER KOB

TO THE DESIRED SPIN TIME

612

3 CM.

CAUTION

EVENLY DISTRIBUTE WET WASHING

IN THE SPIN DRUM.

AN OUT OF BALANCE LOAD

COULD DAMAGE THE SPIN TUB.

FAILING TO PLACE THE DISK COVER

INTO THE SPIN DRUM COULD CAUSE

THE CLOTHING TO RISE OUT OF AND

GET ENTANGLED ROUND THE DRUM

PRECAUTIONS

612 9

DO NOT TOUCH THE SPIN DRUM WHEN IT

ISROTATING

DO NOT MACHINE WASH CLOTHES SOAKED

IN PETROL,THINNERS PARAFFIN OR ANY

OTHER FLAMMABLE LIQUIDS

ALWAYS USE THE SPIN TUB DISC COVER

AS THIS PREVENTS CLOTHING FROM

RISING OUT OF THE SPIN TUB

CHECK ALL CLOTHES FOR LOOSE

BUTTONS AND TEARS

CHECK POCKETS FOR COINS ,PINS ETC.

PETROL

SORT AND SEPARATE CLOTHES BY

FABRIC , COLOUR AND DEGREE OF DIRT

USE ONLY SOAP POWDERS SPECIALLY

DESIGNED FOR TWIN TUB WASHING

MACHINES

DO NOT SPLASH WATER OVER THE

CONTROLS AS THIS COULD LEAD TO AN

ELECTRICAL PROBLEM

3 4

IMPORTANT

NEVER TRY TO TURN A KNOB FURTHER THAN THE MARKING ON THE DIAL

TURN ANTI CLOCKWISE TO RETURN THE KNOB TO "0"

DO NOT USE WATER HOTTER THAN 55 C.

VERY HOT WATER COULD DAMAGE

PARTS OF THE MACHINE

IMPORTANT
