QUICK START GUIDE

ATTENTION!

For Returns or Support you MUST contact

DefenderCameras.com/Support

NEED HELP?

DefenderCameras.com/Support

Open your camera & scan this

QR code for access to the

Defender Shield Support Center.

PROTECT

Covered for the

unexpected

SUPPORT

Receive videos, tips &

updates for your product

VALUE

Exclusive access to

special oers

ACTIVATE YOUR

WARRANTY

Open your camera & scan this

QR code, or visit:

DefenderCameras.com/Warranty

WHAT’S INCLUDED

WHAT YOU’LL NEED

TV or Monitor, Hammer Drill & Appropriate Bit, Phillips (#2) Screwdriver, Ladder (if required),

Cable Protectors (if required).

4 CAMERA KIT - DFSW2K8B4

1 x 8CH Wireless Mini NVR with 1TB HDD

4 x Cameras with Antenna

1 x NVR Power Supply (12V 2A)

4 x Camera Power Supply (12V 1A)

4 x Extension Cable (16ft)

1 x Ethernet Cable (6ft)

1 x HDMI Cable (6ft)

1 x USB Mouse

4 x Camera Mounting Hardware

1 x Window Warning Sticker

4 x Drilling Template

1 x Quick Start Guide

8 CAMERA KIT - DFSW2K8B8

1 x 8CH Wireless Mini NVR with 1TB HDD

8 x Cameras with Antenna

1 x NVR Power Supply (12V 2A)

8 x Camera Power Supply (12V 1A)

8 x Extension Cable (16ft)

1 x Ethernet Cable (6ft)

1 x HDMI Cable (6ft)

1 x USB Mouse

8 x Camera Mounting Hardware

1 x Window Warning Sticker

8 x Drilling Template

1 x Quick Start Guide

FCC / IC STATEMENT

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference

that may cause undesired operation.

FCC WARNING

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-

able protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions,may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

IC STATEMENT / DÉCLA RATION IC:

This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation,

Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to

the following two conditions: (1)This device may not cause interference. (2)This device must

accept any interference, including interference that may cause undesired operation of the

device.

L’émetteur/récepteur exempt de license contenu dans le présent appareil est conforme aux

CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils

radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :

(1) L’appareil ne doit pas produire de brouillage; (2)L’appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est susceptible d’en compromettre le

fonctionnement.

This equipment complies with IC RSS-102 radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and

operated with minimum distance 20cm between the radiator and your body.

Cet équipement est conforme aux limites d’exposition aux radiations IC CNR-102 établies

pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une

distance minimale de 20 cm entre le radiateur et votre corps.

MINI WI-FI NVR SETUP

PLEASE READ FIRST!

You must connect the NVR to a monitor or TV to complete the setup. We recommend

verifying all accessories and completing the NVR setup before installing the cameras. For

the best viewing experience, we recommend using a 2K monitor or TV to view your footage.

DC12V USB HDMI® WAN RST TF

Monitor/TV

(not included)

1. Prepare for installation and NVR Setup.

AMonitor: Connect the TV or Monitor to the NVR with the HDMI cable.

BNVR Power: Connect the NVR power cable to a power outlet.

CUSB Mouse: Connect the USB mouse to the NVR.

DCamera & Camera Power Supply: Connect the Camera power supply to

the Camera and plug it into a power outlet. (NOTE: The camera is pre-paired to your

NVR. You can move the camera to your desired location after the NVR Setup Wizard

is complete).

EModem/Router: Verify your home network is on and follow steps in the NVR

Setup Wizard to connect your NVR.

2. Follow the Activation and Setup Wizard on the monitor/TV to set up the NVR.

APower LED: indicates the NVR is ON.

BRecord LED: data is being read or written to HDD.

CNetwork LED: NVR is connected to a network.

LANGUAGE

• Select your language

• Click “Next”

NVR SETUP WIZARD

NETWORK SETUP

IMPORTANT! To gain remote access, you must connect your NVR to a 2.4Ghz Internet

connection. 5Ghz Wi-Fi network is not supported.

Tip: Look for your home network that has a 2.4 beside your network name or does not have

a 5.0 beside your network name.

• Select “Wireless Network Setting”.

• Select your home 2.4Ghz network and enter your home network password.

• Click “Connect” and wait up to 1 minute for your device to successfully connect to

the Internet.

• Once your NVR is successfully connected to the Internet you will receive a

“Healthy Network” checkmark.

• Click “Next”.

Please Note: If your Network Status does not show “Healthy Network”, verify that your home

network is online. Once this is conrmed, try to connect to your home network again.

DATE AND TIME

Please Note: The Sync function will only work when your NVR is connected to the Internet.

• Select “Sync date and time with Internet time” to automatically synchronize your

date, time and time zone to the Internet time or enter manually.

• Select “Set Daylight Time Parameters” and set your “Daylight Saving Time Set”.

• Select “Save”.

• Click “Next”.

STORAGE MANAGEMENT

No changes are needed. Click “Next”.

PASSWORD

• Create your NVR password.

• Conrm your password.

• Click “Next”.

PREVIEW

No changes are needed. Click “Next”.

Note: All paired cameras will automatically

appear in your Live View screen.
