2.2 Install the Front Camera and Rear Camera
Take out the Cameras, and take out the Installation Tools.
Front camera real picture display Rear camera real picture display
Camera
Camera Bracket
Insert the Front Camera (shorter wire) into the Camera Bracket, and install
it in the front of the motorcycle. The triangle symbol on the camera
represents the forward direction. The bottom of the camera bracket can be
xed with stickers.
If you are concerned about the stability of the bracket, screws can be
added on both sides of the bracket, but this may damage the appearance
of the motorcycle, so please choose carefully. It is recommended to use
stickers to x the bracket.
The installation method for the rear camera is the same as the front camera.
After installation, connect the wires of the front and rear cameras to the
Dash-cam.
Installation Diagram
2.3 Install the Dash-cam Power Supply
Take out the Dash-cam Power Supply. The power supply has an output
port and an input port.
The output port has two wires, the blue wire is connected to the GPS and
the red wire is connected to the dash-cam.
The input port has three wires, colored red (positive), black (negative), and
yellow (ACC). Connect the red and black wires to the positive and negative
terminals of the motorcycle, respectively. Connect the yellow wire to the
ACC in the motorcycle fuse box.
Customer can use the auxiliary tool ---- ACC Detection Wire
Take out the ACC detection wire, wrap the black wire around the
metal body of the motorcycle, and use the red wire to touch the metal
on top of the fuse.
After the motorcycle is powered on, if the LED light on the ACC
detection wire lights up, turn o the motorcycle. If the LED light goes
out, then the fuse you tested is the ACC wire for your motorcycle.
The heat shrink tubing in the accessory bag can be put on the
connection between the lens and the host. After heating, the heat-
shrinkable sleeve will shrink and stick to the joint, which can further
enhance the waterproof eect.
How to nd out which one is the ACC wire in the motorcycle fuse box?
Use heat shrink tubing to further enhance waterproong.
2.4 Install the GPS Modules
Take out the GPS Modules and connect it to the Dash-cam Power Supply.
After installation, start the motorcycle, and the Dash-cam will automatically
turn on and enter the recording interface.
