Dedrone RF-100 Manuel utilisateur

IM-Inst-RF10021en ENGLISH

INSTALLATION

Manual

RF-100

Dedrone

2 IM-Inst-RF10021en

Legal Provisions

The information contained in these documents is the property of Dedrone GmbH. Any

publication, whether in whole or in part, requires prior written approval by Dedrone GmbH.

Internal reproduction used solely for the purpose of product evaluation or other proper use

is allowed and does not require prior approval.

The declaration of conformity is available on request at support@dedrone.com.

This manual is the intellectual property of Dedrone GmbH and is protected by copyright. All

rights reserved.

Dedrone GmbH

Miramstraße 87

34123 Kassel

Germany

Fon +49 561 861799-0

Fax +49 561 861799-111

Email info@dedrone.com

Dedrone

IM-Inst-RF10021en 3

Content

1Safety..................................................................................................................................4

1.1 Symbols........................................................................................................................................4

1.2 Intended Use ...............................................................................................................................4

1.3 Safety Information .................................................................................................................... 5

2The RF-100......................................................................................................................... 6

3Unpacking .......................................................................................................................... 7

4Scope of Delivery.............................................................................................................. 7

5Installation......................................................................................................................... 8

5.1 Select the Mounting Place .......................................................................................................8

5.1.1 Mounting Location..........................................................................................................8

5.1.2 Mounting Surface ...........................................................................................................9

5.1.3 Mounting Orientation ....................................................................................................9

5.1.4 Mounting Device .............................................................................................................9

5.2 Power Supply and Required Tools........................................................................................10

5.3 Cable Requirements and Preparation (Crimp) ....................................................................11

5.4 Installation with Pole Mount................................................................................................. 12

6Integrate RF-100 in your DroneTracker ..................................................................... 14

7Cleaning ........................................................................................................................... 15

8Decommissioning ........................................................................................................... 15

8.1 Shut Down the RF-100 ........................................................................................................... 15

8.2 Dismantling ............................................................................................................................... 15

8.3 Disposal ...................................................................................................................................... 15

9Technical Data................................................................................................................. 16

1 Safety Dedrone

4 IM-Inst-RF10021en

1Safety

1.1 Symbols

Symbol Explanation

Indicates a situation which, if not avoided, can result in property damage

Information that is important for a specific goal, but is not safety-relevant

Indicates a requirement for meeting a specific goal

Desired result

A problem that might occur

Action to resolve a problem

1.2 Intended Use

The RF-100 is a passive, network-attached sensor for the detection of radio frequencies (RF). It

supplements the DroneTracker System with another level of detection. The RF-100 detects

targeted radio signals of different drones and remote controllers and sends the data, along

with an alert, to the DroneTracker System.

The RF-100 is intended for civil commercial and private use in conjunction with a DroneTracker

System.

The RF-100 is suitable for indoor and outdoor use.

Use this product only in accordance with the information provided in the enclosed

documentation and with the locally applicable legal standards and directives. Any other

application may cause personal injury or property damage.

Any use of the product other than that described in the intended use section does not qualify

as appropriate. The enclosed documentation is an integral part of this product. Keep the

documentation in a convenient place for future reference and observe all instructions

contained therein.

The type label must remain permanently attached to the product.

FCC and IC

This device complies with Industry Canada licence-exempt RSS standard(s) and complies with

Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

Dedrone 1 Safety

IM-Inst-RF10021en 5

Note: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Modifications:Any modifications made to this device that are not approved by Dedrone GmbH

may void the authority granted to the user by the FCC to operate this equipment.

Caution!

To prevent permanent exposure, the device should be installed and operated

with a minimum distance of 20 cm (7.87 in) between the device and your body.

1.3 Safety Information

Read, follow and retain all of the following safety instructions. Heed all warnings on the unit

and in the operating instructions before operation.



Warning! Setup should be carried out by trained personnel only, in accordance

with the national electric code, ANSI/NSPA, and all local country codes.



Do not attempt to service this device yourself. Refer all servicing to qualified

service personnel. This device has no user-serviceable internal parts.

Whenever any damage to the device has occurred, unplug the devices from the

power source by disconnecting the patch cable and refer servicing to qualified

service personnel. Such damages can be:

•the patch cable is damaged

•an object has fallen on the device

•the device has been dropped, or its enclosure has been damaged

•the device does not operate normally when the user follows the operating

instructions correctly



Adjust only those controls specified in the operating instructions. Improper

adjustment of other controls may cause damage to the unit.



Despite careful construction, electrical devices can cause fires. Do not mount the

RF-100 in areas containing highly flammable materials or gases. Do not mount the

RF-100 in a potentially explosive atmosphere.

Do not install product near any heat sources such as radiators, heaters, exhaust air

systems or other equipment (including amplifiers) that produce heat.

2 The RF-100 Dedrone

6 IM-Inst-RF10021en

2The RF-100

The RF-100 is a passive, network-attached sensor for the detection of radio frequencies (RF).

The RF-100 detects targeted radio signals of different drones and remote controllers and

sends the data, along with an alert, to the DroneTracker System.

Parts of the RF-100

A Power button D RF Mounting Plate

B RF-100 E Network socket (covered)

C Antenna

It scans a wide frequency band for radio frequencies and classifies them. The data is recorded

and available on the DroneTracker user interface.

Dedrone 3 Unpacking

IM-Inst-RF10021en 7

3Unpacking

This equipment should be unpacked and handled with care. Check the exterior of the packaging

for visible damage. If an item appears to have been damaged in shipment, notify the shipper

immediately.

4Scope of Delivery

Verify that all the parts listed in the scope of delivery are included. If any items are missing,

notify your Dedrone Partner.

Do not use this product if any component appears to be damaged. Please contact Dedrone in

the event of damaged goods.

1 x RF-100

4 x Antenna (2x short, 2x long)

1 x RF Mounting Plate

1 x Pole Mount

2 x Strap

1 x Bag with 2x screws Torx M5, 4x flat washer, 2x nuts

1 x Installation manual

1 x Bag with 1x environmentally sealed Ethernet crimp connector, 1x RJ45 plug

The original packing carton is the safest container in which to transport the unit and must be

used if returning the unit for service. Save it for possible future use.

5 Installation Dedrone

8 IM-Inst-RF10021en

5Installation

5.1 Select the Mounting Place

5.1.1 Mounting Location

The position of the RF-100 has strong impacts to the detection range. The RF-100 is designed

for a mast mount. Make sure that a suitable mast is available (diameter between 1.2 in to 8.66

in (40 mm to 220 mm)).

For ideal results the location should fulfill the following conditions:

□clear view over the area

□elevated position (minimum 3 m)

Select a secure installation location and mounting position for the device. Ideally, this is a

location where the device cannot be interfered with, either intentionally or accidentally.

Do not install the device near the following objects:

•Walls because these share the detection area and prevent classification of signals behind

the wall

•Any excessive heat sources

•Any overhead power lines, power circuits, or electrical lights, or where there is a chance

of electrical discharge

•Behind metal surfaces or vaporized glass because this could reduce the detection range



Note the properties of each RF-100.This is needed for service and for correct

configuration. You can find all information on the type label on the backside of the

RF-100.

We recommend the table below. The following information is important:

•Serial number

•MAC address

•Position

Serial Number MAC Address Position

Dedrone 5 Installation

IM-Inst-RF10021en 9

Overvoltage Protection

For safe mounting in an exposed position overvoltage protection must be observed.

Ensure that the mast is connected to the lightning conductor of the building. The RF-100 itself

must not be grounded directly. The lightning conductor must be installed at least 5 ft (1.5 m)

above the RF-100.

Lightning Protection Installation with a RF-100

Ensure that the location has the appropriate clearance from power and lightning conductors,

in accordance with NEC725 and NEC800 (CEC Rule 16-224 and CEC Section 60).

5.1.2 Mounting Surface

Make sure the selected mounting surface is capable of supporting the combined weight of the

RF-100 (6.8 lb (3.1 kg)) and mounting hardware under all expected conditions of load, vibration,

and temperature.

5.1.3 Mounting Orientation

The orientation of the device itself does not have any effect for the performance. Important

for a good result is the orientation of the antenna. Both antennasshould be orientated

skywards.

5.1.4 Mounting Device

To mount the RF-100 with a mount other than the one supplied, note the following

requirements for the mounting equipment:

□licensed for outdoor use

5 Installation Dedrone

10 IM-Inst-RF10021en

□safe and stiff load of 6.8 lb (3.1 kg)

□matching for the holes of the RF Mounting Plate

Dimensioning of the holes of the RF Mounting Plate

A Holes for the Mast Mount

5.2 Power Supply and Required Tools

Power Supply

The RF-100 does not need any additional power supply connection. The power supply is

provided by the connected switch with activated active PoE+ (802.3at).

•Make sure, that your network has activated active PoE+ (802.3at).

Note: Data transfer is only possible with a suitable PoE switch.

Required Tools

•Screwdriver

•Hex key: 4 mm

•Socket wrench: 8 mm (5/16") and 7 mm ( 9/32” )

•Crimping tool

For an environmentally sealed connection to the RF-100, it's necessary to crimp the

supplied connector to the laid patch cable (see 5.3 Cable Requirements and Preparation

(Crimp), page 11).

•Ladder or lift truck, depending on the mounting location

150

Autres manuels pour RF-100

Table des matières

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
