DeDietrich MCA 45 Manuel utilisateur
Innovens Pro EN
MCA 45 - 65 - 90 - 115
User Guide
300024828-001-A
Contents
1 Introduction ................................................................................................4
1.1 Used symbols .......................................................4
1.2 Abbreviations ........................................................4
1.3 General ..................................................................5
1.3.1 Manufacturer's liability .............................................5
1.3.2 Installer's liability .....................................................5
1.3.3 User's liability ..........................................................5
1.4 Certifications .........................................................6
2Safety instructions and recommendations ..............................................7
2.1 Safety instructions ...............................................7
2.2 Recommendations ................................................8
3Description ..................................................................................................9
3.1 Operating principle ...............................................9
3.1.1 Gas/air setting .........................................................9
3.1.2 Combustion .............................................................9
3.2 Main parts ............................................................10
3.3 Control panel DIEMATIC iSystem .....................10
3.3.1 Description of the keys ..........................................10
3.3.2 Description of the display ......................................11
3.3.3 Browsing in the menus ..........................................13
3.4 Control panel IniControl .....................................14
3.4.1 Description of the keys ..........................................14
3.4.2 Description of the display ......................................15
4 Operating the appliance - DIEMATIC iSystem .......................................17
4.1 Putting the appliance into operation ................17
4.2 Reading out measured values ...........................17
4.3 Changing the settings ........................................19
4.3.1 Setting the set point temperatures ........................19
4.3.2 Selecting the operating mode ...............................20
4.3.3 Forcing domestic hot water production .................21
4.3.4 Setting the contrast and lighting on the
display ...................................................................21
4.3.5 Setting the time and date ......................................22
4.3.6 Selecting a timer programme ................................22
4.3.7 Customising a timer programme ...........................23
106/09/2010 - 300024828-001-A
4.3.8 Setting an annual clock .........................................25
4.4 Installation shutdown .........................................27
4.5 Frost protection ..................................................28
5 Operating the appliance - IniControl ......................................................29
5.1 Putting the appliance into operation ................29
5.2 Reading out measured values ...........................29
5.3 Changing the settings ........................................30
5.3.1 Description of the parameters ...............................30
5.3.2 Modification of the user-level parameters .............31
5.3.3 Setting the manual mode ......................................32
5.3.4 Changing the heating temperature ........................32
5.3.5 Modifying the domestic hot water temperature
setting ....................................................................32
5.4 Installation shutdown .........................................33
5.5 Frost protection ..................................................33
6 Checking and maintenance .....................................................................34
6.1 General instructions ...........................................34
6.1.1 Control panel DIEMATIC iSystem .........................34
6.2 Periodic checks ..................................................34
6.3 Filling the system ...............................................35
6.4 Bleeding the heating system .............................38
6.5 Draining the installation .....................................40
7 Troubleshooting .......................................................................................41
7.1 Anti-hunting ........................................................41
7.2 Messages (Code type Bxx or Mxx) ....................41
7.3 Faults (Code type Lxx or Dxx) ...........................43
7.3.1 Control panel DIEMATIC iSystem .........................44
7.3.2 Control panel IniControl ........................................44
7.3.3 List of errors ..........................................................44
Contents
206/09/2010 - 300024828-001-A
8 Technical characteristics ........................................................................50
8.1 Technical characteristics ...................................50
9 Energy savings .........................................................................................51
9.1 Energy-saving advice .........................................51
9.2 Recommendations ..............................................51
10 Warranty ....................................................................................................52
10.1 General ................................................................52
10.2 Warranty terms ...................................................52
306/09/2010 - 300024828-001-A
1 Introduction
1.1 Used symbols
In these instructions, various danger levels are employed to draw the
user's attention to particular information. In so doing, we wish to
safeguard the user's safety, obviate hazards and guarantee correct
operation of the appliance.
DANGER
Risk of a dangerous situation causing serious physical
injury.
WARNING
Risk of a dangerous situation causing slight physical
injury.
CAUTION
Risk of material damage.
Signals important information.
¼ Signals a referral to other instructions or other pages in the
instructions.
1.2 Abbreviations
43CE: Collective conduit for sealed boiler
4DHW: Domestic hot water
4Interscenario switch: Home automation switch that can be used
to centralise and control several scenarios
4Hi: Lower heating value LHV
4Hs: Higher heating value HHV
4IOBL: Carrier current home automation bus
4PPS: Polypropylene hardly inflammable
4PCU: Primary Control Unit - PCB for managing burner operation
4PSU: Parameter Storage Unit - Parameter storage for PCBs
PCU and SU
4SCU: Secondary Control Unit - Diematic iSystem control panel
PCB
4SU: Safety Unit - Safety PCB
43WV: 3-way valve
MCA 45 - 65 - 90 - 115 1. Introduction
06/09/2010 - 300024828-001-A 4
1.3 General
1.3.1. Manufacturer's liability
Our products are manufactured in compliance with the requirements
of the various european applicable Directives. They are therefore
delivered with [ marking and all relevant documentation.
In the interest of customers, we are continuously endeavouring to
make improvements in product quality. All the specifications stated in
this document are therefore subject to change without notice.
Our liability as the manufacturer may not be invoked in the following
cases:
4Failure to abide by the instructions on using the appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the appliance.
1.3.2. Installer's liability
The installer is responsible for the installation and inital start up of the
appliance. The installer must respect the following instructions:
4Read and follow the instructions given in the manuals provided
with the appliance.
4Carry out installation in compliance with the prevailing legislation
and standards.
4Perform the initial start up and carry out any checks necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the obligation to
check the appliance and maintain it in good working order.
4Give all the instruction manuals to the user.
1.3.3. User's liability
To guarantee optimum operation of the appliance, the user must
respect the following instructions:
4Read and abide by the instructions given in the user manual.
4Call on qualified professionals to carry out installation and initial
start up.
4Get your fitter to explain your installation to you.
4Have the required checks and services done.
4Keep the instruction manuals in good condition close to the
appliance.
1. Introduction MCA 45 - 65 - 90 - 115
506/09/2010 - 300024828-001-A
This appliance is not intended to be used by persons (including
children) whose physcial, sensory or mental capacity is impaired or
persons with no experience or knowledge, unless they have the
benefit, through the intermediary of a person responsible for their
safety, of supervision or prior instructions regarding use of the
appliance. Care should be taken to ensure that children do not play
with the appliance.
1.4 Certifications
CE identification no PIN 0063CL3333
NOx classification 5 (EN 297 pr A3, EN 656)
Type of connection Chimney: B23, B33
Flue gas outlet: C13, C33, C43, C53, C63, C83, C93
MCA 45 - 65 - 90 - 115 1. Introduction
06/09/2010 - 300024828-001-A 6
2 Safety instructions and
recommendations
2.1 Safety instructions
DANGER
If you smell gas:
1. Do not use a naked flame, do not smoke, do not
operate electrical contacts or switches ( doorbell,
light, motor, lift, etc..).
2. Isolate the gas supply.
3. Open the windows.
4. Evacuate the premises.
5. Call your fitter.
DANGER
If you smell flue gases:
1. Switch the appliance off.
2. Open the windows.
3. Evacuate the premises.
4. Call your fitter.
WARNING
Depending on the settings of the appliance:
4The temperature of the flue gas conduits may exceed
60°C.
4The temperature of the radiators may reach 85°C.
4The temperature of the domestic hot water may reach
65°C.
CAUTION
Do not neglect to service the appliance:
4For completely safe and optimum operation, you
must have your boiler regularly serviced by an
approved installer.
2. Safety instructions and recommendations MCA 45 - 65 - 90 - 115
706/09/2010 - 300024828-001-A
2.2 Recommendations
WARNING
Only qualified professionals are authorised to work on the
appliance and the instalation.
4Regularly check the water pressure in the installation (minimum
pressure 0,8 bar, recommended pressure between 1,5 and 2 bar).
4Keep the appliance accessible at all times.
4Never remove or cover labels and rating plates affixed to the
appliance. Labels and rating plates must be legible throughout the
entire lifetime of the appliance.
4The appliance should be on Summer or Antrifreeze mode rather
than switched off to guarantee the following functions:
-Anti blocking of pumps
-Frost protection
MCA 45 - 65 - 90 - 115 2. Safety instructions and recommendations
06/09/2010 - 300024828-001-A 8
3 Description
3.1 Operating principle
3.1.1. Gas/air setting
The casing fitted to the boiler is also used as an air box. Air is sucked
in by the fan and gas injected into the venturi by the fan intake. The
fan rotation speed is set according to the settings parameters, the
thermal energy requirement and the temperatures measured by the
temperature sensors. The gas and air are mixed in the venturi. The
gas/air ratio ensures that the quantities of gas and air are adjusted to
each other. This provides optimum combustion on the entire output
range. The gas/air mixture is fed into the burner on top of the
exchanger.
3.1.2. Combustion
The burner heats the heating water circulating in the heat
exchanger. At a return temperature lower than around 55°C, the flue
gases cool down to a temperature lower than the dew point, thus
causing the condensation of the water vapour contained in the flue
gases in the back side of the heat exchanger. The heat released
during this condensation process (the latent heat or condensing heat)
is also transferred to the heating water. The cooled combustion gases
are evacuated via the combustion gas outlet flue. The condensation
water is evacuated via a siphon.
3. Description MCA 45 - 65 - 90 - 115
906/09/2010 - 300024828-001-A
Autres manuels pour MCA 45
1
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels DeDietrich Chaudière
DeDietrich
DeDietrich C 330 Series Guide de dépannage
DeDietrich
DeDietrich ELIDENS Manuel utilisateur
DeDietrich
DeDietrich WHE 2.24 FF-3S Manuel utilisateur
DeDietrich
DeDietrich GTU C 330 Manuel utilisateur
DeDietrich
DeDietrich C230 ECO-A 80 Manuel de service
DeDietrich
DeDietrich Elidens DTG130-45 Manuel du propriétaire
DeDietrich
DeDietrich Vivadens MCR-P 28 BIC PLUS Manuel utilisateur
DeDietrich
DeDietrich GT 530A Series Manuel
DeDietrich
DeDietrich Innovens MCA 35 Manuel
DeDietrich
DeDietrich DTG N Manuel utilisateur
DeDietrich
DeDietrich GT 330 Manuel
DeDietrich
DeDietrich Innovens MCA 25 BIC Manuel utilisateur
DeDietrich
DeDietrich INNOVENS PRO Manuel d'utilisation
DeDietrich
DeDietrich GT 210 A Manuel utilisateur
DeDietrich
DeDietrich MCR 24 Manuel utilisateur
DeDietrich
DeDietrich Elitec DTG 130 Manuel utilisateur
DeDietrich
DeDietrich CBB Series Manuel utilisateur
DeDietrich
DeDietrich GT 220 A Manuel utilisateur
DeDietrich
DeDietrich NeOvo EcoNox EFU 22 Manuel utilisateur
DeDietrich
DeDietrich AGC 25 Manuel
Manuels Chaudière populaires d'autres marques
Vaillant
Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur
Radijator
Radijator BIO max 23.1 Manuel utilisateur
Brunner
Brunner BSV 20 Manuel utilisateur
Buderus
Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur
Potterton
Potterton 50e Fiche technique
UTICA BOILERS
UTICA BOILERS TriFire Manuel utilisateur
