DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual
Document # 540364, Rev IR, 02/2008 Page 5 of 15
3.0 Installation
3.1 Prior to Installation
The TSC-9104-101-x is a simple module to install. Prior to installation the
following items should be considered:
3.1.1 During the design and layout of the aircraft cabin, careful
consideration of the location of this and all other video modules is
necessary. Some of the items to consider include:
•Space
•Proximity to other devices (i.e. source equipment)
•Available power supply
•Length of cable runs
•Environmental conditions (temperature, humidity, etc.)
•Location of other aircraft systems (i.e. oxygen delivery)
•Access for service repair (if applicable)
•Convenience for user interface (if applicable)
3.1.2 The TSC-9104-101-x shall be installed to conform to the standards
designated by the customer, installing agency, and existing
conditions as to the unit location and type of installation.
3.1.3 An internal cooling fan ventilates internal components and prevents
undesirable heat buildup. Proper ventilation must be allowed for
when specifying the installation location. The closeout area of the
monitor shall have a clearance of 2 inches (5.08 cm) minimum for
the air inlet and exit areas. The closeout area of the monitor case
shall not block the air inlet or exhaust openings of the monitor case.
This fan is thermostatically controlled, it only runs when the unit is
turned on and heat build-up requires it, thus providing a much
quieter viewing experience than many monitors.
3.1.4 The monitor casing is specially designed for EMI and noise filtering,
guaranteeing a reduction in interference to ensure a high-quality
display.
3.2 Unpacking and Inspection
3.2.1 Carefully open the packaging and remove the TSC-9104-101-x.
Verify that all components have been included in the package per
the packing list. Inspect the unit for shipping damage.
3.2.2 If damage has occurred during shipping, a claim should be filed
with DeCrane Aerospace Audio International WITHIN 24 hours and
a Return Request Authorization Number shall be obtained from
