Operating instructions and warnings

I66331X Rev. 01 26-05-14

Digipro - Digislim

Access Control

Operating instructions and warnings

Art. DIGISLIMArt. DIGIPRO

Technical data

- temperature: -20°C ÷ +50°C

- RH: ≤95%

Current and voltage:

- DC input: +12V - +24V

- AC input: ~ 12V - 24V

- Standby current: ≤80mA

- Current while using: ≤110mA

Aplicable card mode:

- EM ID Card (Default)

Eective distance: 5cm

Storage capacity:

- ZONA 1: up to 1000 passwords AND cards

- ZONA 2: up to 10 passwords OR cards

N° Description

1 Mode indicator

2 Door indicator

3 Antenna

4 Keyboard

5 Lid screw

1 SPECIFICATIONS/FEATURES

•EM internal player.

•Frequency: 125KHz.

•Eective distance: 5cm.

•ZONE 1: up to 1000 passwords AND cards

ZONE 2: up to 10 passwords OR cards

•Access by card, access by code, combined access.

•Operating with digital keyboard.

•Integrated anti-removal function.

•Two relay outputs.

•Delay release time output: 0~99s.

•IP: 65.

•Dimensions:

DigiPro :120x76x28 mm.

DigiSlim :165x45x23,5 mm

•Two relay outputs for door opening, door status detection, door opening by key. Door

status detection regards ZONE 1 only.

2 INSTALLATION

Warning: Please remove the lid carefully following the instructions. Avoid removing parts by

forcing the components.

Warning: In order to remove the lid, slightly slide upward the front part, then following Fig. 1 ,

lift the lower part of about 20° and remove it gently.

Before installing, locate the position in which the access control will be mounted. Please

proceed according to the following instructions:

•Open the device by unscrewing and removing the special screw on the bottom of the rear

base with the wrench provided.

•Use the drilling template provided to locate the exact position and to drill the holes requi -

red.

•Use the screws provided to x the rear base to the wall. Be sure to run the cables through

the large hole in the center of the rear base ( Fig. 2 and Fig. 3 ).

•Run the wiring carefully following the label on the back ( Fig. 4 ).

•Reassemble the unit and secure it using the wrench.

3 OPERATING

ZONE 1 and 2 relays can be programmed to open the lock; you can store up to a maximum of

1000 user cards (AND their codes) for ZONE 1 and up to a maximum of 10 user cards (OR 10

codes) for ZONE 2. Moreover, ZONE 1 can be programmed in 3 modes to open the lock: access

by card (card only), by card or code (you can use the card or the code) and by combined access

(card and code together). ZONE 2 can be programmed for the bell.

3.1 Access to the setting mode

•Default admin code is 1234.

•Enter the default admin code 2 times (1234 - 1234). But:

a) if the default admin code entered is 2 digits, please insert 12 - 12;

b) if the default admin code entered is 3 digits, please insert 123 - 123;

c) if the default admin code entered is 5 digits, please insert 12345 - 12345;

The rest may be deduced by analogy and the maximum is 6 digits long.

•After entering the setting mode, the yellow LED lights up.

Warning: users codes must be dierent from administrator code.

Warning: ZONE 1 codes must be dierent from ZONE 2 ones.

3.2 Setting the access mode

In setting mode:

•Press followed by , the mode yellow LED blinks, press the

and you will hear a long beep. This indicates that you can get access by card only.

•Press followed by , the mode yellow LED blinks, press the followed by , the light

by code.

•Press followed by , the mode yellow LED blinks, press the followed by , the light

by code (combined access).

•Press to exit the setting mode.

3.3 Setting the length of passwords

In setting mode:

•Press followed by , the yellow LED blinks, press the followed by and you will hear

a “BI” as reminder, then digit X (X=2, 3, 4, 5, 6):

a) if 2 - Password/code length is 2 digits (from 00 to 99).

b) if 3 - Password/code length is 3 digits (from 000 to 999).

The rest may be deduced by analogy and the maximum is 6 digits long.

The “BI” sound, indicates that the chosen length value was correctly set.

If the sound is “BI BI BI”, indicates that the chosen length value is the same in use and can’t

•Press to exit the setting mode.

Warning:

3.4 Adding user card and code (ZONE 1)

In setting mode:

Insert a 3-digit number (from 000 to 999) corresponding to the data storage box in which you

want to operate, the yellow led blinks:

a) If the red LED is lit, it indicates that in the chosen memory box data is already saved, press

the key twice to clear the memory;

b) If the green LED is on, it indicates that cards and passwords can be added in the chosen

memory box.

Steps to add cards and passwords:

•In setting mode, the yellow LED blinks.

•Insert the 3-digit number (from 000 to 999) in the data storage box in which you want to add

the user, the green LED lights up.

•Approach the card, the sound “BI” indicates that it was added. Then insert the desired pas-

sword (relative to the just added card). The password length must be the same of the admin

code. For example, if the admin code is 12 (2 is the length) you have to set a 2-digit password

(from 00 to 99). if the admin code is 123 (3 is the length) you have to set a 3-digit password

(from 000 to 999). The rest may be deduced by analogy and the maximum is 6 digits long...

The “BI” sound, indicates that the password was correctly set.

•Press to exit the setting mode.

3.5 Erasing user card and code (ZONE 1)

In setting mode:

Insert a 3-digit number (from 000 to 999) corresponding to the data storage box in which you

want to operate, if the red LED is on, it indicates that in the chosen memory box data is already

saved, press the key twice to clear the memory.

3.6 Adding user card or code (ZONE 2)

In setting mode:

•Press followed by , the yellow led blinks, insert a 2-digit number (from 00 to 09) corre-

sponding to the data storage box in which you want to operate, the yellow LED blinks.

a) If the red LED is on, it means that inside the chosen memory box data is already saved,

press the key twice to erase the memory.

b) If the green LED is on, it means that cards o passwords can be added in the chosen data

storage box.

•Approach the card, the sound “BI” indicates that you added it; OR insert the desired pas-

sword; the password length must be the same as the admin code. I.g., if the admin code is 12

(2 is the length) you must set a 2-digit password (from 00 to 99). If the admi code is 123 (3 is

the length), you must set a 3–digit password (from 000 to 999). The rest may be deduced by

analogy...The sound “BI” indicates that the password was correctly set.

•Press to exit the setting mode.

3.7 Erasing user card or code (ZONE 2)

In setting mode:

Press followed by , the yellow LED blinks, insert a 2-digit number (from 0 to 09) correspon-

ding to the data storage box in which you want to operate, if the red LED is on it indicates that

in the chosen memory box data is already saved, press the key twice to erase the memory.

3.8 Relay timing

Relay timing for ZONE 1

In setting mode:

•Press followed by , the yellow LED blinks, digit the desired value (from 00 to 99), the

inserption of the relay activation time. The set value indicates the times the relay will be

active. For example:

a) Inserting 05, it means the relay will remain active for 5 seconds.

b) Inserting 00, you must approach the card o insert the password once to activate the relay

and a second time to close it.

•Press to exit the setting mode.

Door status detecting function (ZONE 1 ONLY): When someone opens the door and enter, and

the door is closed, the device automatically detects the door status and deactivates the relay

although this is still in the activation period.

Relay timing for ZONE 2

In setting mode:

•Press followed by , the yellow LED blinks, digit the desired value (from 00 to 99), the

inserption of the relay activation time. The set value indicates the times the relay will be

active. For example:

a) Inserting 05, it means the relay will remain active for 5 seconds.

b) Inserting 00, you must approach the card o insert the password once to activate the relay

and a second time to close it.

•Press to exit the setting mode.

3.9 Erasing all user cards and codes, restoring factory settings

In setting mode:

•Press followed by , the yellow LED blinks, press the key twice, you will hear a long

password) was cancelled correctly cancelled.

•Press followed by , the yellow LED blinks, press the key twice, you will hear a long

•Press to exit the setting mode and remain on standby.

Warning:

If you enter incorrect information, you will hear a double “BI-BI” and after 30 seconds the device

will automatically return to the initial mode again accompanied by the sound “BI-BI”.

If you’re not in the settings mode and you enter an incomplete number, or if you have to unlock

the door with the card and the password (combined) but only one of the two actions is made,

the device will return to the initial mode automatically after 5 seconds. accompanied by the

double sound “BI-BI”.

Warning:

If the admin code is lost, switch the power o, hold the key, then restore power. A sound “BI”

indicates that the default admin code was successfully reset.

If codes are 2 digits-the default admin code is 12;

If codes are 3 digits-the default admin code is 123;

If codes are 4 digits-the default admin code is 1234;

If codes are 5 digits-the default admin code is 12345;

If codes are 6 digits-the default admin code is 123456 (the maximum is 6).

In setting mode:

•Press followed by , the yellow LED blinks, then insert a new administrator code two

times (the admin code length must be the same as above): the sound “BI” indicates that the

•Press to exit the setting mode.

3.11 Turn on/turn o the anti-removal alarm

In setting mode:

•Press followed by (the yellow led blinks), then press followed by , a long “BEEP”

•Press to exit the setting mode.

Warning: The built-in buzzer will continuously beep if the photoresistor is exposed to light. The

buzzer will automatically turn o within 60 seconds when the light is no longer detected, or by

entering the admin code.

3.12 Turn on/turn o the bell

In setting mode:

•Press followed by (the yellow led blinks), then press followed by , a long “BEEP”

•Press to exit the setting mode.

Warning: The bell in ZONE 2 is available if the bell function is on. Press in standby mode, the

relay will active once, activating the bell.

Warning: If the bell is enable in ZONE 2, you can’t use cards or user codes.

3.13 Adding the master card (ZONE 1 only)

In setting mode:

•Press followed by , the green LED will blinks indicating that there are no master cards

stored, otherwise, if the LED turns red it means there is already saved data, press the key

twice to clear the memory, at this point the green LED blinks, then swipe the master card, a

long “beep” will be heard to indicate that the addition was successful.

•Press to exit the setting mode.

3.14 Enter settings mode swiping the master card

To enter the setting mode:

entry;

•To exit the setting mode, bring back the master card, the LED will turn green and you will hear

Warning: The access control will be locked for 60 seconds after entering a wrong code or the

swiping an invalid card for 5 times (both the keyboard and the card recognition won’t be available

during these 60 sec.).

3.15 Adding cards groups in ZONE 1

In setting mode:

•Press followed by (the yellow led blinks), then press followed by , a “BI” will be he-

ard as reminder. Insert a 3-digit number (from 000 to 999) corresponding to the data storage

(from 000 to 999 indicating the cards quantity that can be added. For example:

a) Inserting 005 060, it means that the cards added to the memory start from 005 and they

are 60.

b) Inserting 060 150, it means that the cards added to the memory start from 060 and they

are 150.

that the card was corectly added.

Warning:

set) will be automatically saved.

•Press to exit the setting mode.

3.16 Modifying the user code of ZONE 1

In setting mode:

•Press followed by (the yellow led blinks), then press followed by , a “BI” will be

heard as reminder. Insert a 3-digit number (from 000 to 999) corresponding to the data

storage box where you want to add a new password (the password length must be the same

as the admin code).

•Press to exit the setting mode.

Warning: In order to remove the lid, slightly slide upward the front part, then following Fig. 1, lift the

lower part of about 20° and remove it gently.

Sollevare - Lift -

Soulever -

Levantar -

Autres manuels pour Digipro

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dea Contrôleurs d'accès IP

Dea

Dea Digipro Manuel du produit

Manuels Contrôleurs d'accès IP populaires d'autres marques

ZKTeco

ZKTeco SpeedFace-V5L Manuel utilisateur

Jantar

Jantar REX A-1-9 Manuel utilisateur

2N Access Unit Feuille d'instructions

Kedacom

Kedacom KSCA120 Series Manuel utilisateur

H3C

H3C WX2880X Manuel utilisateur

G4S

G4S S870-EX Mode d’emploi

PRASTEL

PRASTEL M2000PE Manuel utilisateur

Allegion

Allegion interflex IF-281 Cylinder Manuel utilisateur

TECOM

TECOM TS1067E Manuel utilisateur

Fermax

Fermax Memokey 100C Guide de l'utilisateur

Fermax

Fermax CITYLINE MEMOKEY Mode d’emploi

Software House

Software House iSTAR Pro 2U RM Mode d’emploi

AKCP

AKCP SP+ Manuel utilisateur

Bpt

Bpt HNA/102 Manuel utilisateur

Civintec

Civintec CV9601T-T-1F Manuel utilisateur

BioMax

BioMax N-X90W Manuel utilisateur

ZKTeco

ZKTeco OP-200 Manuel utilisateur

FingerTec

FingerTec s-Kadex Manuel utilisateur
