Daytona 64780 Instructions de montage

Visit our website at: http://www.harborfreight.com

Email our technical support at: [email protected]

64780-Black

56643-Blue

64240-Orange

64784-Green

Owner’s Manual & Safety Instructions

Save This Manual Keep this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the

back of the manual (or month and year of purchase if product has no number). Keep this manual and the

receipt in a safe and dry place for future reference. 22g

When unpacking, make sure that the product is intact

and undamaged. If any parts are missing or broken,

please call 1-888-866-5797 as soon as possible.

No portion of this manual or any artwork contained herein may be reproduced in

any shape or form without the express written consent of Harbor Freight Tools.

Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein.

Tools required for assembly and service may not be included.

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Low Profile Floor Jack

IMPORTANT SAFETY INFORMATION

1. Study, understand, and follow all instructions

before operating this device.

2. Do not exceed rated capacity.

3. Use only on hard, level surfaces.

4. Lifting device only. Immediately after lifting,

support the vehicle with appropriate means.

5. Do not move or dolly the vehicle while on the jack.

6. Failure to heed these markings may result in

personal injury and/or property damage.

7. Lift only areas of the vehicle as specified

by the vehicle manufacturer.

8. No alterations shall be made to this product.

9. Never work on, under or around a load

supported only by this device.

10. Do not adjust safety valve.

11. Wear ANSI-approved safety goggles and

heavy-duty work gloves during use.

12. Keep clear of load while lifting and lowering.

13. Lower load slowly.

14. Apply parking brake and chock tires

before lifting vehicle.

15. Lift vehicle only at manufacturer

recommended locations.

16. Inspect before every use; do not use if parts are

loose or damaged, or if leaking hydraulic fluid.

17. Do not use for aircraft purposes.

18. Do not use any objects (such as blocks of wood) in

between Saddle Pad or Saddle and lifting point.

Objects placed on the Saddle will reduce

the stability of the Jack, and could allow the

vehicle to slip off the Saddle and fall.

19. The Handle Socket will be held down by

a plastic block under tension. Wear ANSI-

approved safety goggles before freeing Handle

Socket. Hold Handle Socket down while

removing block. After removal, carefully swing

Handle Socket up until tension is released.

20. The warnings, precautions, and instructions

discussed in this manual cannot cover all

possible conditions and situations that may occur.

The operator must understand that common sense

and caution are factors, which cannot be built into

this product, but must be supplied by the operator.

SAVE THESE INSTRUCTIONS.

IMPORTANT! Before first use:

Check hydraulic oil level and fill as needed as stated on page 6. Thoroughly test the Jack for proper

operation. If it does not work properly, bleed air from its hydraulic system as stated on page 6.

Page 3For technical questions, please call 1-888-866-5797.Low Profile Floor Jack

WARNING SYMBOLS AND DEFINITIONS

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

Indicates a hazardous situation which, if not avoided,

will result in death or serious injury.

Indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

Indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

Addresses practices not related to personal injury.

Page 4 For technical questions, please call 1-888-866-5797. Low Profile Floor Jack

Specifications

Weight Capacity 3 Tons

Weight Capacity (lb.) 6,000

Maximum Height (in.) 20

Minimum Height (in.) 3.25

Handle Length (in.) 45.50

Front Wheel Diameter (in.) 2.36

Front Wheel Width (in.) 1.20

Rear Caster Diameter (in.) 2.36

Rear Caster Width (in.) 2.00

Saddle Pad Size (in.) 3.90 x 3.90 sq.

Hydraulic Oil non-detergent 22 weight

Weight (lb.) 77

Page 5For technical questions, please call 1-888-866-5797.Low Profile Floor Jack

Overview

Saddle

Handle

Foam Bumper Handle

Socket

Handle

Release Bolt

(not shown)

Lift Arm

Page 6 For technical questions, please call 1-888-866-5797. Low Profile Floor Jack

Set Up

Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this

manual including all text under subheadings therein before set up or use of this product.

Removing Shipping Block

CAUTION! The Handle Socket will be held down by a plastic block under tension.

Wear ANSI-approved safety goggles before freeing Handle Socket. Hold Handle Socket down while

removing block. After removal, carefully swing Handle Socket up until tension is released.

A plastic block holds the Handle Socket in position during shipment. This

helps prevents shipping damage. To remove it:

1. Press down on the Handle Socket to

relieve tension on the plastic block.

2. Remove plastic block from the bar.

3. Slowly raise the Handle Socket

until tension is released.

Attaching the Handle

1. Slide the Upper Handle into the Lower Handle.

Line the Button on the Lower Handle up with the

hole in the Upper Handle until it clicks into place.

2. Loosen the Set Screw and insert the grooved end

of the assembled Handle into the Handle Socket.

3. Tighten the Set Screw.

Bleeding Trapped Air

1. With the Jack fully lowered, remove both Screws

on the end of the Cover Plate that is closer to the

Saddle. Swing the Cover Plate open. See Figure A.

2. Remove the Fill Plug on top of the Cylinder.

Check that the oil level inside the Cylinder is

at the top of the Piston. See Figure B.

3. Insert the Handle into the Handle Socket

to operate the Release Valve.

4. Turn the Handle counterclockwise to open the valve.

5. Pump the Handle up and down quickly

10-15 times to force air from the system.

6. Replace the Fill Plug, close the

Cover Plate, and reinstall the Screws. Fill Plug Safety Valve Covers

Do not open or adjust.

Figure A: Hydraulic Unit

Adding Oil

NOTICE: To prevent damage and premature wear,

use only non-detergent 22 weight hydraulic jack oil.

1. With the Jack fully lowered, remove both Screws

on the end of the Cover Plate that is closer to

the Saddle. Swing the Cover Plate open.

2. Remove the Fill Plug on top of the Cylinder.

3. Add non-detergent 22 weight hydraulic jack oil

into the Fill Plug hole slowly until the oil level just

covers the top of the Piston inside the Cylinder.

4. Replace the Fill Plug, close the

Cover Plate, and reinstall the Screws.

Fill Plug

Cylinder

Piston

Oil

FILL LEVEL

Figure B: Fill Level

Page 7For technical questions, please call 1-888-866-5797.Low Profile Floor Jack

Operation

Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this

manual including all text under subheadings therein before set up or use of this product.

Lifting

Park vehicle on a flat, level, solid, surface safely away from oncoming traffic. Turn off the vehicle’s engine.

Place the vehicle’s transmission in “PARK” (if automatic) or in its lowest gear (if manual).

Set the vehicle’s emergency brake. Then, chock the wheels that are not being lifted.

1. Turn the Handle counterclockwise to lower the Jack.

Once the Jack is fully lowered, turn the

Handle firmly clockwise to close it.

2. Carefully position the Saddle of the Jack under the

vehicle manufacturer’s recommended lifting point.

(See vehicle manufacturer’s owner’s manual

for location of frame lifting point.)

3. Pump the Handle until the top of the Jack’s Saddle

has nearly reached the vehicle lifting point. Position

the Saddle directly under the vehicle’s lifting point.

4. To lift the vehicle, pump the Handle.

Use smooth, full strokes.

5. Once the vehicle is raised, slide a jack stand of

appropriate capacity (not included) under a proper

lifting point referred to in the vehicle owner’s

manual. Always use two jack stands, position them

at the same point on each side of the vehicle.

WARNING! The rated capacity of jack stands is per

pair, not the individual capacities combined unless

specifically noted on the product by the jack stand

manufacturer. Do not exceed rated jack stand

capacity. Ensure that the vehicle support points

are fully seated in the saddle of both jack stands.

Use a matched pair of jack stands per vehicle to

support one end only. Failure to do so may result

in the load suddenly falling, which may cause

personal serious injury and/or property damage.

6. Center saddle of the jack stand(s) under the vehicle’s

lifting point(s). Set the jack stand(s) to the same

height according to the manufacturer’s instructions,

making sure that they lock securely into position.

7. Slowly turn the Handle counterclockwise to lower

the vehicle onto the saddle(s) of the jack stand(s).

Then, turn the Handle firmly clockwise to close it.

Lowering

1. Carefully remove all tools, parts, etc.

from under the vehicle.

2. Position the Saddle under the lifting point.

Turn the Handle firmly clockwise and raise

load high enough to clear the jack stands,

then carefully remove jack stands.

3. Slowly turn the Handle counterclockwise

(never more than 1/2 full turn) to lower

the vehicle onto the ground.

4. Lower the Jack completely. Then, store in a

safe, dry location out of reach of children.

Page 8 For technical questions, please call 1-888-866-5797. Low Profile Floor Jack

Maintenance and Servicing

Procedures not specifically explained in this manual must

be performed only by a qualified technician.

TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment.

If abnormal noise or vibration occurs, have the problem corrected before further use.

1. BEFORE EACH USE, inspect the general

condition of the tool. Check for:

• leaking hydraulic oil,

• loose hardware or parts,

• misalignment or binding of moving parts,

• cracked, bent or broken parts, and

• any other condition that may

affect its safe operation.

Thoroughly investigate and correct the causes for

all issues that are found. Do not use Jack until all

issues are understood and properly corrected.

ALSO, BEFORE EACH USE, thoroughly test

the Jack for proper operation prior to actual use.

If the Jack’s motion seems spongy or the

Saddle does not lift completely, follow

Bleeding instructions on page 6.

2. AFTER USE, wipe dry with a clean cloth. Then,

store the Jack in a safe, dry location out of reach

of children and other non-authorized people.

NOTICE: Storing the Jack in a humid area or

exposing it to corrosive vapor voids the warranty.

3. Weekly - Jack Lubrication:

a. Lubricate according to the below steps using

only general purpose lithium grease.

b. Inject grease into each of the grease fittings.

c. Lubricate the linkages and pivot points lightly.

Note: Improper or inadequate

lubrication voids the warranty.

4. Change the hydraulic oil at least

once every three years:

a. With the Jack fully lowered, remove both Screws

on the end of the Cover Plate that is closer to

the Saddle. Swing the Cover Plate open.

b. Remove the Fill Plug on the top of the Cylinder.

c. Tip the Jack to allow the old hydraulic oil

to drain out of the Housing completely,

and dispose of the old hydraulic oil in

accordance with local regulations.

d. Follow instructions for Adding Oil on page 6.

e. Replace the Fill Plug, close the

Cover Plate, and reinstall the Screws.

f. Follow instructions for

Bleeding Trapped Air on page 6.

Fill Plug

Cylinder

Piston

Oil

FILL LEVEL

Figure C: Fill Level

Page 9For technical questions, please call 1-888-866-5797.Low Profile Floor Jack

Troubleshooting

TO PREVENT SERIOUS INJURY:

Use caution when troubleshooting a malfunctioning jack. Stay well clear of the supported load.

Completely resolve all problems before use. If the solutions presented in the Troubleshooting guide

do not solve the problem, have a qualified technician inspect and repair the jack before use.

After the jack is repaired: Test it carefully without a load by raising and lowering it fully,

checking for proper operation, BEFORE RETURNING THE JACK TO OPERATION.

DO NOT USE A DAMAGED OR MALFUNCTIONING JACK!

POSSIBLE SYMPTOMS PROBABLE SOLUTION

(Jack must not be supporting a load

while attempting a solution.)

Jack will

not lift at

capacity

Saddle

lowers

under load

Pump stroke feels

spongy or Saddle

does not lift all the way

Handle moves

up when Jack

under load

Fill Plug leaking

oil or Jack will not

lower without a load

X X

Check that Release Valve

is fully closed.

Bleed trapped air from the hydraulics.

X X X

Valves may be blocked and may not

close fully. To flush the valves:

1. Lower the Saddle and securely

close the Release Valve.

2. Manually lift the saddle

several inches.

3. Open the release valve

and force the saddle down

as quickly as possible.

X X

Jack may be low on oil.

Check the oil level and fill if needed.

See step 4 on facing page.

Jack may have air trapped

in the hydraulics.

Follow instructions for

Bleeding Trapped Air on page 6.

Jack may have too much

hydraulic oil inside, check

oil level and adjust if needed.

Fill Plug

Cylinder

Piston

Oil

FILL LEVEL

Page 10 For technical questions, please call 1-888-866-5797. Low Profile Floor Jack

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM

IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS

QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE

ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY

ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS

THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Parts List and Diagram

Parts List

Part Description Qty.

1 Upper Handle 1

2 Pin 1

3 Handle Cover 1

4 Lower Handle 1

5 Circlip 1

6 Handle Socket 1

7 Screw 1

8 Roller 1

9 Pin 1

10 Cover Plate 1

11 Limiting Rod 2

12 Right Adjustment Plate 1

13 Lock Washer 4

14 Lock Washer 1

15 Bolt 1

16 Bolt 4

17 Lock Washer 4

18 Bolt 4

19 Screw 4

20 Lock Washer 4

21 Nut 2

22 Screw 2

23 Left Adjustment Plate 1

Part Description Qty.

24 Circlip 2

25 Frame 1

26 Fixed Wheel 2

27 Washer 2

28 Circlip 2

29 Pump 1

30 Spring 2

31 Cotter Pin 1

32 Retainer Ring 2

33 Rod 1

34 Nut 2

35 Caster 2

36 Retainer Ring 2

37 Lifting Shaft 1

38 Grease Fitting 1

39 Lifting Arm 1

40 Saddle 1

41 Screw 1

42 Bolt 1

43 Washer 2

44 Rubber Pad 1

45 Lock Washer 1

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Daytona Jack

Daytona

Daytona DS300LPB Instructions de montage

Daytona

Daytona DA-15PR Instructions de montage

Daytona

Daytona DS300LRG Instructions de montage

Daytona

Daytona DS300LRBL Instructions de montage

Daytona

Daytona DS300LRB Instructions de montage

Daytona

Daytona DS300S Instructions de montage

Daytona

Daytona DJS22T Instructions de montage

Daytona

Daytona DJS3TBK Instructions de montage

Daytona

Daytona DS400SB Instructions de montage

Daytona

Daytona 64783 Instructions de montage

Daytona

Daytona DJS3TBK Instructions de montage

Daytona

Daytona DJS3TGRY Manuel utilisateur

Daytona

Daytona 64241 Instructions de montage

Daytona

Daytona 64780-Black Instructions de montage

Daytona

Daytona DS300AR Instructions de montage

Daytona

Daytona DS400S Instructions de montage

Daytona

Daytona DS300LPG Instructions de montage

Daytona

Daytona DS300LR Instructions de montage

Daytona

Daytona DA15LP Instructions de montage

Daytona

Daytona DJS3TBK Instructions de montage

Daytona

Daytona DTJ10T Instructions de montage

Daytona

Daytona DS300SG Manuel utilisateur

Daytona

Daytona DS300SB Instructions de montage

Daytona

Daytona DJ300MP Instructions de montage

Manuels Jack populaires d'autres marques

Omega Lift Equipment

Omega Lift Equipment 18122C Instructions d'utilisation

Pittsburgh

Pittsburgh 58816 Instructions de montage

Unimec

Unimec TP Manuel utilisateur

Sonic

Sonic 4800703 Manuel utilisateur

BGS technic

BGS technic 70039 Manuel utilisateur

TradeQuip

TradeQuip 1128T Manuel utilisateur

VEVOR

VEVOR TJD-12000SP-F Manuel utilisateur

ULTIMATE SPEED

ULTIMATE SPEED URW 2 A1 HYDRAULIC TROLLEY JACK Manuel utilisateur

Stels

Stels 51131 Manuel utilisateur

Bushranger

Bushranger RJX01 Manuel utilisateur

Clarke

Clarke CTJ2500QLG Manuel d'installation et d'exploitation

Valex

Valex 1650520 Manuel utilisateur

Pfaff

Pfaff Merkur M0 Manuel utilisateur

Beta

Beta 3050/K Supplément

Sealey

Sealey 1050CXHV Manuel utilisateur

Jung

Jung JH Series Manuel utilisateur

URIAH

URIAH UC200020 Manuel utilisateur

Kennedy

Kennedy KSJ010 Manuel utilisateur
