Facelook X1 User’s Manual
IMPORTANT SAFETY INFORMATION
This section presents important information intended to ensure safe and effective use of
this product.
Read this section carefully and store it in an accessible location.
SAFETY PRECAUTIONS
When the device cannot be exited or terminated, reset and restart it by powering off
and on again.
When using the device, avoid hard objects from impact and knock, and do not
scratch with sharp objects to prevent damage to the device casing.
Wipe the display and panel lightly with a soft cloth and other materials. Avoid using
water and detergent.
In the installation and use of this product, all nation and region electrical regulations
must be checked.
If the device does not work properly, do not disassemble it for repair, otherwise the
device warranty will be invalid.
Avoid extreme high temperature (or low temperature), high humidity, vibration,
radiation, chemical corrosion and other harsh or extreme environments during
installation and use.
3/ 24
Facelook X1 User’s Manual
CONTENTS
1. OVERVIEW 4
1.1 INTRODUCTION 4
1.2 PACKING LIST 4
1.3 APPEARANCE AND COMPONENTS 5
1.3.1 APPEARANCE 5
1.3.2 DIMENSION 5
1.3.3 CONNECTORS 6
2. INSTALLATION AND OPERATION 7
2.1 WALL-MOUNT INSTALLATION 7
2.1.1 INSTALLATION AND FIXING 7
2.2 CONNECTING NETWORK 8
2.2.1 CONNECT TO PC DIRECTLY 8
2.2.2 CONNECT BY LAN 9
2.3 WEB CONFIGURATION 10
2.3.1 LOGIN DEVICE 10
2.3.2 VIEW DEVICE INFORMATION 11
2.3.3 PERSONNEL MANAGEMENT 11
2.3.4 EQUIPMENT MANAGEMENT 14
2.3.5 ACCESS CONTROL SETTINGS 17
2.3.6 COMMUNICATION MANAGEMENT 17
2.3.7 SYSTEM MANAGEMENT 18
3. SPECIFICATION 19
3.1 PRODUCT FEATURES 19
3.2 TECHNICAL SPECIFICATIONS 20
3.2.1 TEMPERATURE DETECT SPECIFICATIONS 20
3.2.2 FACIAL RECOGNITION SPECIFICATIONS 20
3.2.3 CAMERA SPECIFICATIONS 21
3.2.4 INTERFACES 21
3.2.5 HARDWARE SPECIFICATIONS 22
4. FAQ 23
APPENDIX A GATE PRINCIPLE AND CONNECTION 24
4/ 24
Facelook X1 User’s Manual
1. OVERVIEW
1.1 INTRODUCTION
Facelook X1 is a facial recognition and body temperature detection device which is
capable of detecting temperature abnormity without actual physical contact at different
application fields. It alerts when abnormal body temperature and recognizes face while
wearing or without wearing a mask.
It is widely used in schools, hospitals, shops, companies, stations and buildings for body
temperature detection, personnel verification and attendance. The high body temperature
people will be detected and quarantined, and the safety of environment is highly secured.
1.2 PACKING LIST
Packaging components may vary depending on different application.
Enclosed accessories are listed as the following:
The actual accessories are shown below:
No.
Name
Quantity
Description
1
Main Device
1
-
2
Convert Plate
1
50mm x 70mm → 75mm
3
Hood
1
-
4
Quick Installation Guide
1
-
5
Wall mount Kit
1
50mm(W) x 70mm(H)
6
Adapter
1
DC12V/2A
7
Power Cord
1
US/EU/UK/AU
5/ 24
Facelook X1 User’s Manual
1.3 APPEARANCE AND COMPONENTS
1.3.1 APPEARANCE
1.3.2 DIMENSION
Dimension:
252(L)*136(W)*26(H)mm(8 inches)
Weight: 1.7KG
6/ 24
Facelook X1 User’s Manual
1.3.3 CONNECTORS
No
Name
Description
Label
①
Network port
RJ45
-
②
Power supply
DC12V IN
DC12V IN
③
USB
(Reserved)
-
④
Switch Output
A+/B-
KZ_OUT
⑤
Wiegand IN
(Reserved)
WG IN
⑥
Wiegand OUT
(Reserved)
WG OUT
⑦
RS485
(Reserved)
RS485
7/ 24
Facelook X1 User’s Manual
2. INSTALLATION AND OPERATION
2.1 WALL-MOUNT INSTALLATION
2.1.1 INSTALLATION AND FIXING
Release the 2 screws and take out the wall bracket from device.
Check the installation height of the face recognition monitor. It is recommended to fix
the bracket on the wall about 1.5m height.
Carefully align and push the main unit into the bracket mounted on the wall.
Align the bracket holes and gently slide it down tightly. After connecting the wires, fix
the bottom cover with screws.
The instruction is shown as below diagram:
8/ 24
Facelook X1 User’s Manual
2.2 CONNECTING NETWORK
To configure the device, connect PC to device. Two ways can be used to connect the
device and PC. Select either one of the ways.
2.2.1 CONNECT TO PC DIRECTLY
Connect device and PC with a network cable through RJ-45 port.
The default IP address on device is 192.168.2.10. Therefore, set PC IP address at the
same network segment, for example, 192.168.2.1.
Follow the steps below to set PC IP address at 192.168.2.1.
Right-click on the network icon at right side of task bar.
Select [Open Network and Sharing Center].
Click [Ethernet].
In Ethernet Status window, select [Properties].
Double-click on [Internet Protocol Version 4(TCP/IPv4)].
9/ 24
Facelook X1 User’s Manual
Select [Use the following IP address]. Fill [IP address] and [Subnet mask].
2.2.2 CONNECT BY LAN
The IP address on device is set at DHCP which automatically obtains an IP address from
LAN (Local Area Network). Simply connect both device and PC on LAN.
Power up the device and check the IP address obtained from LAN. The IP address is
shown at the lower-right corner of display.
10 / 24
Facelook X1 User’s Manual
2.3 WEB CONFIGURATION
2.3.1 LOGIN DEVICE
On PC, open web browser to login the device. It is recommended to use Google Chrome.
Input the default IP address, 192.168.2.10, or the IP obtained from LAN, in URL column.
Select the language preferred. Input the account ID and PW. The default ID and PW:
ID: admin
PW: admin345
Note:
In case the ID or password is forgotten, click [Forget Password] and provide the Mac
shown on screen to the vendor for help.
Change ID and Password
At the upper-right corner of browser, click down arrow to change the account ID and
password.
In the dialogue box, input new ID and password and click [OK] to confirm.
