Data Video DAC-8P 4K Manuel utilisateur

DAC-8P 4K

Table of Contents

FCC COMPLIANCE STATEMENT ............................................ 4

WARNINGS AND PRECAUTIONS........................................... 4

WARRANTY......................................................................... 6

STANDARD WARRANTY ..............................................................6

THREE YEAR WARRANTY ............................................................6

DISPOSAL............................................................................ 7

1. INTRODUCTION............................................................... 8

2. CONNECTIONS AND CONTROLS ....................................... 9

2.1FRONT PANEL.......................................................................9

2.2 REAR PANEL......................................................................10

3. FIRMWARE UPDATE .......................................................12

3.1 INTRODUCTION ............................................................12

3.2 PREPARATION ..............................................................12

3.2.1 SYSTEM REQUIREMENTS ..................................................12

3.2.2 FIRMWARE UPDATE PREPARATION .....................................13

3.2.3 SYSTEM CONNECTION DIAGRAM .......................................14

3.2.4 PREPARING THE FIRMWARE..............................................14

3.3 UPDATE........................................................................15

3.3.1 UPDATING THE FIRMWARE ...............................................15

3.4 HOW TO CHECK THE FIRMWARE VERSION ....................17

5. SPECIFICATIONS .............................................................21

SERVICE AND SUPPORT ......................................................24

Disclaimer of Product & Services

The information offered in this instruction manual is intended as a guide only. At all times, Datavideo

Technologies will try to give correct, complete and suitable information. However, Datavideo

Technologies cannot exclude that some information in this manual, from time to time, may not be

correct or may be incomplete. This manual may contain typing errors, omissions or incorrect

information. Datavideo Technologies always recommend that you double check the information in this

document for accuracy before making any purchase decision or using the product. Datavideo

Technologies is not responsible for any omissions or errors, or for any subsequent loss or damage

caused by using the information contained within this manual. Further advice on the content of this

manual or on the product can be obtained by contacting your local Datavideo Office or dealer.

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference

that may cause undesired operation.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use liquid

or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may

fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are provided

for ventilation. To ensure safe and reliable operation of this unit, and to

protect it from overheating, do not block or cover these openings. Do

not place this unit on a bed, sofa, rug, or similar surface, as the

ventilation openings on the bottom of the cabinet will be blocked. This

unit should never be placed near or over a heat register or radiator. This

unit should not be placed in a built-in installation unless proper

ventilation is provided.

7. This product should only be operated from the type of power source

indicated on the marking label of the AC adapter. If you are not sure of

the type of power available, consult your Datavideo dealer or your local

power company.

8. Do not allow anything to rest on the power cord. Do not locate this unit

where the power cord will be walked on, rolled over, or otherwise

stressed.

9. If an extension cord must be used with this unit, make sure that the total

of the ampere ratings on the products plugged into the extension cord

do not exceed the extension cord rating.

10. Make sure that the total amperes of all the units that are plugged into a

single wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet

ventilation slots, as they may touch dangerous voltage points or short

out parts that could result in risk of fire or electric shock. Never spill

liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not

attempt to service this product yourself. Opening or removing covers

that are marked “Do Not Remove” may expose you to dangerous

voltage points or other risks, and will void your warranty. Refer all

service issues to qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified service

personnel under the following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under normal operating

conditions. Adjust only those controls that are covered by the

operating instructions in this manual; improper adjustment of other

controls may result in damage to the unit and may often require

extensive work by a qualified technician to restore the unit to normal

operation;

e. When the product has been dropped or the cabinet has been

damaged;

f. When the product exhibits a distinct change in performance,

indicating a need for service.

Warranty

Standard Warranty

Datavideo equipment are guaranteed against any manufacturing defects

for one year from the date of purchase.

The original purchase invoice or other documentary evidence should be

supplied at the time of any request for repair under warranty.

The product warranty period beings on the purchase date. If the purchase

date is unknown, the product warranty period begins on the thirtieth day

after shipment from a Datavideo office.

Damage caused by accident, misuse, unauthorized repairs, sand, grit or

water is not covered under warranty.

Viruses and malware infections on the computer systems are not covered

under warranty.

Any errors that are caused by unauthorized third-party software

installations, which are not required by our computer systems, are not

covered under warranty.

All mail or transportation costs including insurance are at the expense of

the owner.

All other claims of any nature are not covered.

Cables and batteries are not covered under warranty.

Warranty only valid in the country or region of purchase.

Your statutory rights are not affected.

Three Year Warranty

All Datavideo products purchased after July 1st, 2017 are qualified for a

free two years extension to the standard warranty, providing the product

is registered with Datavideo within 30 days of purchase.

Certain parts with limited lifetime expectancy such as LCD panels, DVD

drives, Hard Drive, Solid State Drive, SD Card, USB Thumb Drive, Lighting,

Camera module, PCIe Card are covered for 1 year.

The three-year warranty must be registered on Datavideo's official

website or with your local Datavideo office or one of its authorized

distributors within 30 days of purchase.

Disposal

For EU Customers only - WEEE Marking

This symbol on the product or on its packaging

indicates that this product must not be disposed of

with your other household waste. Instead, it is your

responsibility to dispose of your waste equipment by

handing it over to a designated collection point for the

recycling of waste electrical and electronic equipment.

The separate collection and recycling of your waste

equipment at the time of disposal will help to conserve

natural resources and ensure that it is recycled in a manner that protects

human health and the environment. For more information about where you

can drop off your waste equipment for recycling, please contact your local city

office, your household waste disposal service or the shop where you

purchased the product.

1. Introduction

The DAC-8P4K Converter converts 12G-SDI in resolutions up to 4K50/60to 4K

HDMI, it is easy to connect the 4K HDMI signal devices and professional 12G-

SDI video equipment.

Featuring SDI input and both an SDI and an HDMI output, the audio is de-

embedded from the SDI input, and available in the HDMI output and analog

audio output.

The DAC-8P4K Converter is useful for a variety of broadcast and professional

AV applications.

Features

Supports up to DCI 4K (4096 x 2160) and UHD 4K (3840 x 2160)

12G-SDI input and loop-thru output

Supports HDMI 2.0 to 18 Gbps Video bandwidth

Supports Re-Clocking

Provides Additional 2-Channel RCA Analog Audio Output

Supports Automatic Input Signal Detection

Supports HDMI Deep Color function.

Aluminum appearance design, which is rugged and durable.

2. Connections and Controls

2.1Front Panel

12G-SDI HD/SD - SDI Input & Output (bypass)

SDI provides video signals for professional applications

and allows long distance signal transmission.

IN：12G HD/SD-SDI Input.

LOOP THRU：12G-HD/SD-SDI Loop Through Output.

Signal LED Indicator：When the input signal is

connected, this indicator will light up.

F/W UPGRADE

This USB Type C interface is used for firmware update

only.

2.2 Rear Panel

DC IN Socket

Please connect the supplied 12V DC adapter to this

interface. The connection can be secured by screwing

the outer fastening ring of the DC In plug to the

socket.

Power LED Indicator

If the DC IN 12V power is connected, this indicator will

light up.

4K HDMI OUT

This is the 4K HDMI OUT interface.
