Instruction Manual

SE-2850 / HS-2850 /MS-2850

4 CHANNEL UPGRADE I/O CARD

SE-2850 UPGRADE

I/O CARD

Table of Contents

FCC COMPLIANCE STATEMENT...............................................3

WARNINGS AND PRECAUTIONS.............................................3

WARRANTY ...........................................................................5

STANDARD WARRANTY .............................................................. 5

THREE YEAR WARRANTY ............................................................ 5

DISPOSAL...............................................................................6

INTRODUCTION .....................................................................7

FEATURES ................................................................................ 7

INSERTING THE DV UPGRADE I/O CARD ................................7

SERVICE & SUPPORT ..............................................................8

Disclaimer of Product & Services

The information offered in this instruction manual is intended as a guide only.

At all times, Datavideo Technologies will try to give correct, complete and

suitable information. However, Datavideo Technologies cannot exclude that

some information in this manual, from time to time, may not be correct or

may be incomplete. This manual may contain typing errors, omissions or

incorrect information. Datavideo Technologies always recommend that you

double check the information in this document for accuracy before making

any purchase decision or using the product. Datavideo Technologies is not

responsible for any omissions or errors, or for any subsequent loss or damage

caused by using the information contained within this manual. Further advice

on the content of this manual or on the product can be obtained by contacting

your local Datavideo Office or dealer.

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference

that may cause undesired operation.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use liquid

or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may

fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are provided

for ventilation. To ensure safe and reliable operation of this unit, and to

protect it from overheating, do not block or cover these openings. Do

not place this unit on a bed, sofa, rug, or similar surface, as the

ventilation openings on the bottom of the cabinet will be blocked. This

unit should never be placed near or over a heat register or radiator. This

unit should not be placed in a built-in installation unless proper

ventilation is provided.

7. This product should only be operated from the type of power source

indicated on the marking label of the AC adapter. If you are not sure of

the type of power available, consult your Datavideo dealer or your local

power company.

8. Do not allow anything to rest on the power cord. Do not locate this unit

where the power cord will be walked on, rolled over, or otherwise

stressed.

9. If an extension cord must be used with this unit, make sure that the total

of the ampere ratings on the products plugged into the extension cord

do not exceed the extension cord rating.

10. Make sure that the total amperes of all the units that are plugged into a

single wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet

ventilation slots, as they may touch dangerous voltage points or short

out parts that could result in risk of fire or electric shock. Never spill

liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not attempt

to service this product yourself. Opening or removing covers that are

marked “Do Not Remove” may expose you to dangerous voltage points

or other risks, and will void your warranty. Refer all service issues to

qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified service

personnel under the following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under normal

operating conditions. Adjust only those controls that are covered

by the operating instructions in this manual; improper adjustment

of other controls may result in damage to the unit and may often

require extensive work by a qualified technician to restore the

unit to normal operation;

e. When the product has been dropped or the cabinet has been

damaged;

f.When the product exhibits a distinct change in performance,

indicating a need for service.

Warranty

Standard Warranty

•Datavideo equipment are guaranteed against any manufacturing defects

for one year from the date of purchase.

•The original purchase invoice or other documentary evidence should be

supplied at the time of any request for repair under warranty.

•The product warranty period begins on the purchase date. If the

purchase date is unknown, the product warranty period begins on the

thirtieth day after shipment from a Datavideo office.

•Damage caused by accident, misuse, unauthorized repairs, sand, grit or

water is not covered under warranty.

•Viruses and malware infections on the computer systems are not

covered under warranty.

•Any errors that are caused by unauthorized third-party software

installations, which are not required by our computer systems, are not

covered under warranty.

•All mail or transportation costs including insurance are at the expense of

the owner.

•All other claims of any nature are not covered.

•Cables and batteries are not covered under warranty.

•Warranty only valid in the country or region of purchase.

•Your statutory rights are not affected.

Three Year Warranty

•All Datavideo products purchased after July 1st,

2017 are qualified for a free two years extension to

the standard warranty, providing the product is

registered with Datavideo within 30 days of

purchase.

•Certain parts with limited lifetime expectancy such as LCD panels, DVD

drives, Hard Drive, Solid State Drive, SD Card, USB Thumb Drive, Lighting,

Camera module, PCIe Card are covered for 1 year.

•The three-year warranty must be registered on Datavideo's official

website or with your local Datavideo office or one of its authorized

distributors within 30 days of purchase.

Disposal

For EU Customers only - WEEE Marking

This symbol on the product or on its packaging indicates

that this product must not be disposed of with your other

household waste. Instead, it is your responsibility to

dispose of your waste equipment by handing it over to a

designated collection point for the recycling of waste

electrical and electronic equipment. The separate

collection and recycling of your waste equipment at the time of disposal will

help to conserve natural resources and ensure that it is recycled in a manner

that protects human health and the environment. For more information about

where you can drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or the shop where

you purchased the product.

CE Marking is the symbol as shown on the left of this page.

The letters "CE" are the abbreviation of French phrase

"Conformité Européene" which literally means "European

Conformity". The term initially used was "EC Mark" and it

was officially replaced by "CE Marking" in the Directive 93/68/EEC in 1993. "CE

Marking" is now used in all EU official documents.

Introduction

The SE-2850 is designed for multi-camera video production. The system

includes a digital video switcher and an additional I/O board, providing the

user with the flexibility to extend the HD/SD-SDI IN from 8 to 12 channels.

Simply insert the upgrade I/O card into the empty slot at the rear of the SE-

2850.

Features

The SE-2850 Upgrade I/O Card includes:

•Additional 4 input channels

•Either 4 additional SDI inputs or 3 additional SDI and 1 HDMI input

Inserting the DV Upgrade I/O Card

The SE-2850 has been designed to allow the Upgrade I/O card to be easily

installed into the system. Follow the steps outlined below to insert the DV

Upgrade I/O Card.

1. On the rear of the SE-2850 system, locate the unused slot which is

covered by a cover plate.

2. To remove the cover plate, simply unscrew the screws mounting the

plate.

3. Insert the Upgrade I/O card into the unused slot and make sure it is fully

inserted into the main board.

4. After the Upgrade I/O card is installed, secure the card by screwing the

screws removed earlier back in.

All the trademarks are the properties of their respective owners.

Service & Support

Aug-16.2017

Please visit our website for latest manual update.

http://www.datavideo.com/product/

SE-2850+Upgrade+IO+Card

It is our goal to make your products ownership a satisfying experience. Our

supporting sta󰀨 is available to assist you in setting up and operating your

system. Please refer to our web site www.datavideo.com for answers to

common questions, support requests or contact your local o󰀩ce below.
