DAPAudio EB-16 Manuel utilisateur

EB-16

ORDERCODE D143279 790-814Mhz

ORDERCODE D143282 822-846MHz

Congratulations!

You have bought a great, innovative product from DAP Audio.

The DAP Audio EB-16 brings excitement to any venue.

You can rely on DAP Audio, for more excellent audio products.

We design and manufacture professional audio equipment for the entertainment industry.

New products are being launched regularly. We work hard to keep you, our customer, satisfied.

For more information: iwant@dap-audio.info

You can get some of the best quality, best priced products on the market from DAP Audio.

So next time, turn to DAP Audio for more great audio equipment.

Always get the best -- with DAP Audio !

Thank you!

DAP Audio

DAP Audio EB-16™ Product Guide

Warning.......................................................................................................................................................................

Safety-instructions.................................................................................................................................................

Operating Determinations...................................................................................................................................

Description..................................................................................................................................................................

Features..................................................................................................................................................................

Overview................................................................................................................................................................

Installation...................................................................................................................................................................

Set Up and Operation................................................................................................................................................

Frequency ranges......................................................................................................................................................

Declaration of conformity.........................................................................................................................................

Maintenance………..............................….......................................………..………….…….………….…....................

Troubleshooting………..............................…................................………..………….…….………….….......................

Product Specifications.................................................................……………….…….…………………......................

WARNING

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present, and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be

returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Your shipment includes:

• DAP EB-16

• Storage case

• Screwdriver

• User manual

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.

Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned

without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.

Be prepared to provide the model number, serial number and a brief description of the cause for the

return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the

customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace

product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper

inside the box:

1) Your name

2) Your address

3) Your phone number

4) A brief description of the symptoms

Claims

The client has the obligation to check the delivered goods immediately upon delivery for any short-

comings and/or visible defects, or perform this check after our announcement that the goods are at their

disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be

reported to the carrier upon receipt of merchandise.

It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is

damaged due to shipping. Transportation damage has to be reported to us within one day after receipt

of the delivery.

Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with

a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless

otherwise agreed in writing.

Complaints against us must be made known in writing or by fax within 10 working days after receipt of the

invoice. After this period complaints will not be handled anymore.

Complaints will only then be considered if the client has so far complied with all parts of the agreement,

regardless of the agreement of which the obligation is resulting.

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

SAFETY INSTRUCTIONS

Every person involved with the installation, operation and maintenance of this device has to:

-be qualified

-follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to

warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-

observance of this manual or any unauthorized modification to the device.

Never remove warning or informative labels from the unit.

Never leave any cables lying around.

Do not open the device and do not modify the device.

Do not switch the system on and off in short intervals, as this would reduce the system’s life.

Do not drive the inputs with a signal level bigger, than required to drive the equipment to full

output.

Only use device indoor, avoid contact with water or other liquids.

Avoid flames and do not put close to flammable liquids or gases.

Make sure you don’t use the wrong kind of cables or defective cables.

Please turn off the power switch, when changing the power cord or signal cable, or select the

input mode switch.

If the system has been exposed to drastic temperature fluctuation (e.g. after transportation), do

not switch it on immediately. The arising condensation water might damage your system. Leave

the system switched off until it has reached room temperature.

If your Dap Audio device fails to work properly, discontinue use immediately. Pack the unit

securely (preferably in the original packing material), and return it to your Dap Audio dealer for

service.

Repairs, servicing and electric connection must be carried out by a qualified technician.

WARRANTY: Till one year after date of purchase.

OPERATING DETERMINATIONS

If this device is operated in any other way, than the one described in this manual, the product may suffer

damages and the warranty becomes void.

Improper installation can cause serious damage to people and property !

CAUTION!

Keep this device away from rain and moisture!

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dangerous electric shock when touching the wires!

Description of the device

Features

The EB-16 ia professional wireless microphone from Dap Audio. There are two types ranges available:

D143279, frequency range 790 –814Mhz

D143282, frequency range 822 –846Mhz

• PLL synthesized 16 switchable frequencies.

• Operation in the UHF range.

• Compatible with Lavalier or headset microphones.

•5V phantom power

Overview

Fig. 1

Installation

Remove all packing materials from the EB-16. Check that all foam and plastic padding is removed.

Always disconnect from electric mains power supply before cleaning or servicing.

Damages caused by non-observance are not subject to warranty.

The DAP EB-16 is a beltpack transmitter which can be used with the optional DAP EH-1 stage headset

microphone (D1416)or the optional EL-1 Lavalier microphone (D1415).

Fig. 2

A suitable (optional) receiver is the DAP ER-216 (D143079 or D143082).

Set Up and Operation

Before turning the EB-16 on, always make shure that the frequency range is allowed in your country.

Placing the batteries

1 2

1) Open the battery compartment.

2) Put 2 batteries (2x Battery UM3, AA1.5V) in the holder. Pay attention to the polarity of the batteries and

put them in correctly. Now close the battery compartment again.

3) Set the switch on top in the ON position. The LED will light green if the unit is working correctly. If the LED

lights up red, you need to change the batteries.

Altering the settings

4 5

4) Altering the channel setting. Rotate the channel switch using the supplied screwdriver.

5) Gain adjustment. Turn the trimpot using the supplied screwdriver.

Tips for achieving maximum performance.

Make sure you can always see a receiver antenna from the transmitter position.

Keep the distance from transmitter to receiver antenna as short as possible.

Point the receiver antennas away from each other at 45 degrees angle from vertical position.

Avoid placing the receiver antennas near metal surfaces and obstructions.

Replace battery as soon as low battery LED lights.

If stacking or rack mounting receivers in a multiple system setup. Do not allow antennas to cross.

Perform a walk-through before performance or presentation. If dead spots are found, adjust the

location of the receiver. If dead spots remain, mark the dead spots and avoid them.

EB-16 frequencies

D143279: 790 –814Mhz for use in: Australia, Brasil, Canada, Czech Republic, China/ Hong

Kong, Egypt, France, Germany, Greece, Hungary, Iran,

Israel, Italy, Luxemburg, Poland, Portugal, Romania, Slovakia,

Switzerland, Turkey, United Kingdom, USA.

D143282: 822 –846Mhz Mhz for use in: Australia, Brasil, Canada, Czech Republic, China/ Hong

Kong. Denmark, France, Germany, Greece, Hungary, Iran,

Italy, Japan, Luxemburg, Netherlands, Norway, Poland,

Portugal, Romania, Slovakia, Sweden, Switzerland, Turkey,

United Kingdom, USA.

Please check: DAP Audio Wireless Systems Frequency Table for more details.

DECLARATION OF CONFORMITY

We,

name : Highlite International

address : Vestastraat 2

6468 EX Kerkrade

Nederland

declare under our sole responsibility that the product:

product : EB-16 Wireless PLL 790-814

model number : D143279

to which this declaration relates in conformity with the following

European, harmonised and published standards at date of this

declaration:

E.M.C. : EN301489-1 V1.3.1

EN301489-9 V1.1.1

EN301422-2 V1.1.1

EN60065

Kerkrade, 3 September 2004,

Mr. de la Haye, general manager

DECLARATION OF CONFORMITY

We,

name : Highlite International

address : Vestastraat 2

6468 EX Kerkrade

Nederland

declare under our sole responsability that the product:

product : EB-16 Wireless PLL 822-846

model number : D143282

to which this declaration relates in conformity with the following

European, harmonised and published standards at date of this

declaration:

E.M.C. : EN301489-1 V1.3.1

EN301489-9 V1.1.1

EN301422-2 V1.1.1

EN60065

Kerkrade, 3 September 2004,

Mr. de la Haye, general manager
