Contents

1 Introduction

1-1

2 How to Program

2-1

Local Control Panel 2-1

How to operate the graphical LCP (GLCP) 2-1

Quick Menu Mode 2-10

Function Set-ups 2-13

Main Menu Mode 2-16

3 Parameter Description

3-1

Parameter Selection 3-1

Main Menu - Operation and Display - Group 0 3-1

Main Menu - Load and Motor - Group 1 3-18

Main Menu - Brakes - Group 2 3-30

Main Menu - Reference/Ramps - Group 3 3-33

Main Menu - Limits/Warnings - Group 4 3-40

Main Menu - Digital In/Out - Group 5 3-47

Main Menu - Analog In/Out - Group 6 3-80

Main Menu - Communications and Options - Group 8 3-91

Main Menu - Profibus - Group 9 3-101

Main Menu - CAN Ser. Com. Bus - Group 10 3-110

Main Menu - LonWorks - Group 11 3-117

Main Menu - Smart Logic - Group 13 3-118

Main Menu - Special Functions -Group 14 3-134

Main Menu - Adjustable Frequency Drive Information - Group 15 3-143

Main Menu - Data Readouts - Group 16 3-151

Main Menu - Data Readouts 2 - Group 18 3-162

Main Menu - Adjustable Frequency Drive Closed-loop - Group 20 3-165

Main Menu - Extended Closed-loop - FC 100 - Group 21 3-182

Main Menu - Application Functions - FC 100 - Group 22 3-196

Main Menu - Time-based Functions - FC 100 - Group 23 3-212

Main Menu - Application Functions 2 - Group 24 3-228

Main Menu - Cascade Controller - Group 25 3-235

Main Menu - Analog I/O Option MCB 109 - Group 26 3-250

4 Troubleshooting

4-1

Alarms and warnings 4-1

Alarm words 4-4

VLT

HVAC Drive Programming Guide Contents

MG.11.C6.22 - VLT®is a registered Danfoss trademark

Warning words 4-5

Extended status words 4-6

Fault messages 4-7

5 Parameter Lists

5-1

Parameter Options 5-1

Default settings 5-1

0-** Operation and Display 5-2

1-** Load / Motor 5-4

2-** Brakes 5-5

3-** Reference / Ramps 5-6

4-** Limits / Warnings 5-7

5-** Digital In / Out 5-8

6-** Analog In / Out 5-10

8-** Communication and Options 5-12

9-** Profibus 5-13

10-** CAN Fieldbus 5-14

11-** LonWorks 5-15

13-** Smart Logic Controller 5-16

14-** Special Functions 5-17

15-** FC Information 5-18

16-** Data Readouts 5-20

18-** Info & Readouts 5-22

20-** FC Closed-loop 5-23

21-** Ext. Closed-loop 5-24

22-** Application Functions 5-26

23-** Time-based Funtions 5-28

24-** Application Functions 2 5-29

25-** Cascade Controller 5-30

26-** Analog I / O Option MCB 109 5-32

6 Index

6-1

Contents VLT

HVAC Drive Programming Guide

MG.11.C6.22 - VLT®is a registered Danfoss trademark

1Introduction

VLT HVAC Drive

FC 100 Series

Software version: 2.8.x

This guide can be used with all VLT HVAC Drive adjustable frequency

drives with software version 2.8.x.

The current software version number can be read from

par.15-43

Software Version

VLT

HVAC Drive Programming Guide 1 Introduction

MG.11.C6.22 - VLT®is a registered Danfoss trademark

1-1

1 Introduction VLT

HVAC Drive Programming Guide

1-2

MG.11.C6.22 - VLT®is a registered Danfoss trademark

2 How to Program

2.1 Local Control Panel

2.1.1 How to operate the graphical LCP (GLCP)

The following instructions are valid for the GLCP (LCP 102).

The GLCP is divided into four functional groups:

1. Graphical display with status lines.

2. Menu keys and indicator lights (LEDs) - selecting mode, changing parameters and switching between display functions.

3. Navigation keys and indicator lights (LEDs).

4. Operation keys and indicator lights (LEDs).

Graphical display:

The LCD display is back lit with a total of 6 alpha-numeric lines. All data is displayed on the LCP which can show up to five operating variables while in

[Status] mode.

Display lines:

a. Status line: Status messages displaying icons and graphics.

b. Line 1-2: Operator data lines displaying data and variables de-

fined or chosen by the user. By pressing the [Status] key, up to

one extra line can be added.

c. Status line: Status messages displaying text.

VLT

HVAC Drive Programming Guide 2 How to Program

MG.11.C6.22 - VLT®is a registered Danfoss trademark

2-1

The display is divided into 3 sections:

Top section (a) shows the status when in status mode or up to 2 variables when not in status mode and in the case of an alarm/warning.

The number of the Active Set-up (selected as the Active Set-up in par.0-10

Active Set-up

) is shown. When programming in another set-up than the Active

Set-up, the number of the set-up being programmed appears to the right in brackets.

The Middle section (b) shows up to 5 variables with related unit, regardless of status. In case of an alarm/warning, the warning is shown instead of

the variables.

It is possible to toggle between three status readout displays by pressing the [Status] key.

Operating variables with different formatting are shown in each status screen - see below.

Several values or measurements can be linked to each of the displayed operating variables. The values / measurements to be displayed can be defined

via par.0-20

Display Line 1.1 Small

, par. 0-21

Display Line 1.2 Small

, par. 0-22

Display Line 1.3 Small

, par. 0-23

Display Line 2 Large

and par. 0-24

Display

Line 3 Large

, which can be accessed via [QUICK MENU], "Q3 Function Set-ups", "Q3-1 General Settings", "Q3-13 Display Settings".

Each value/measurement readout parameter selected in par.0-20

Display Line 1.1 Small

to par. 0-24

Display Line 3 Large

has its own scale and number

of digits after a possible decimal point. Larger numeric values are displayed with few digits after the decimal point.

Ex.: Current readout

5.25 A; 15.2 A 105 A.

Status display I:

This readout state is standard after start-up or initialization.

Use [INFO] to obtain information about the value/measurement linked to

the displayed operating variables (1.1, 1.2, 1.3, 2, and 3).

See the operating variables shown in the display in this illustration. 1.1,

1.2 and 1.3 are shown in small size. 2 and 3 are shown in medium size.

130BP041.10

1.1

1.3

1.2

Status display II:

See the operating variables (1.1, 1.2, 1.3, and 2) shown in the display in

this illustration.

In the example, Speed, Motor current, Motor power and Frequency are

selected as variables in the first and second lines.

1.1, 1.2 and 1.3 are shown in small size. 2 is shown in large size.

130BP062.10

1.1

1.3

1.2

2 How to Program VLT

HVAC Drive Programming Guide

2-2

MG.11.C6.22 - VLT®is a registered Danfoss trademark

Status display III:

This state displays the event and action of the Smart Logic Control. For

further information, see the section

Smart Logic Control

130BP063.10

The Bottom section always shows the state of the adjustable frequency

drive in status mode.

Display Contrast Adjustment

Press [status] and [

▲

] for darker display

Press [status] and [

▼

] for brighter display

130BP074.10

Top section

Middle section

Bottom section

Indicator lights (LEDs):

If certain threshold values are exceeded, the alarm and/or warning LED lights up. A status and alarm text appears on the control panel.

The On LED is activated when the adjustable frequency drive receives power from AC line voltage, a DC bus terminal, or an external 24 V supply. At the

same time, the back light is on.

• Green LED/On: Control section is working.

• Yellow LED/Warn.: Indicates a warning.

• Flashing Red LED/Alarm: Indicates an alarm.

VLT

HVAC Drive Programming Guide 2 How to Program

MG.11.C6.22 - VLT®is a registered Danfoss trademark

2-3

GLCP keys

Menu keys

The menu keys are divided into functions. The keys below the display and

LEDs are used for parameter set-up, including choice of display indication

during normal operation.

130BP045.10

[Status]

indicates the status of the adjustable frequency drive and/or the motor. Three different readouts can be chosen by pressing the [Status] key:

5 line readouts, 4 line readouts or Smart Logic Control.

Use

[Status]

for selecting the mode of display or for changing back to display mode from either the quick menu mode, main menu mode or alarm mode.

Also use the [Status] key to toggle single or double readout mode.

[Quick Menu]

allows quick set-up of the adjustable frequency drive. The most commonVLT HVAC Drive functions can be programmed here.

The [Quick Menu] consists of:

-MyPersonalMenu

- Quick Set-up

- Function Set-up

-ChangesMade

- Loggings

The Function Set-up provides quick and easy access to all parameters required for the majority of VLT HVAC Drive applications including most VAV and

CAV supply and return fans, cooling tower fans, primary, secondary and condenser water pumps and other pump, fan and compressor applications.

Among other features, it also includes parameters for selecting which variables to display on the LCP, digital preset speeds, scaling of analog references,

closed-loop single zone and multi-zone applications and specific functions related to fans, pumps and compressors.

The Quick Menu parameters can be accessed immediately unless a password has been created via par.0-60

Main Menu Password

, par.0-61

Access to

Main Menu w/o Password

, par.0-65

Personal Menu Password

or par.0-66

Access to Personal Menu w/o Password

It is possible to switch directly between Quick Menu mode and Main Menu mode.

[Main Menu]

is used for programming all parameters. The Main Menu parameters can be accessed immediately unless a password has been created via par.0-60

Main

Menu Password

, par.0-61

Access to Main Menu w/o Password

,par.0-65

Personal Menu Password

or par.0-66

Access to Personal Menu w/o Password

. For

the majority of VLT HVAC Drive applications, it is not necessary to access the Main Menu parameters but instead the Quick Menu, Quick Set-up and

Function Set-up provide the simplest and quickest access to parameters that are typically required.

It is possible to switch directly between Main Menu mode and Quick Menu mode.

A parameter shortcut can be carried out by pressing the [Main Menu] key for 3 seconds. The parameter shortcut allows direct access to any parameter.

[Alarm Log]

displays an alarm list of the last five alarms (numbered A1-A5). To obtain additional details about an alarm, use the arrow keys to navigate to the alarm

number and press [OK]. Information is displayed about the condition of the adjustable frequency drive before it enters alarm mode.

The Alarm log button on the LCP allows access to both the alarm log and the maintenance log.

[Back]

reverts to the previous step or layer in the navigation structure.

[Cancel]

last change or command will be canceled as long as the display has not been changed.

2 How to Program VLT

HVAC Drive Programming Guide

2-4

MG.11.C6.22 - VLT®is a registered Danfoss trademark

[Info]

displays information about a command, parameter, or function in any display window. [Info] provides detailed information when needed.

Exit Info mode by pressing either [Info], [Back], or [Cancel].

Navigation Keys

The four navigation arrows are used to navigate between the different

choices available in [Quick Menu], [Main Menu] and [Alarm Log].

Use the keys to move the cursor.

[OK] is used for choosing a parameter marked by the cursor and for

enabling the change of a parameter.

Operation Keys for local control are found at the bottom of the control

panel.

130BP046.10

[Hand On]

enables control of the adjustable frequency drive via the GLCP. [Hand On] also starts the motor, and it is now possible to enter the motor speed data by

means of the arrow keys. The key can be selected as

Enable

[1] or

Disable

[0] via par.0-40

[Hand on] Key on LCP

The following control signals will still be active when [Hand On] is activated:

• [Hand On] - [Off] - [Auto on]

• Reset

• Coasting stop inverse

•Reversing

• Set-up select lsb - Set-up select msb

• Stop command from serial communication

•Quickstop

•DCbrake

NOTE!

External stop signals activated by means of control signals or a serial bus will override a “start” command via the LCP.

VLT

HVAC Drive Programming Guide 2 How to Program

MG.11.C6.22 - VLT®is a registered Danfoss trademark

2-5

[Off]

stops the connected motor. The key can be selected as Enable [1] or Disable [0] via par.0-41

[Off] Key on LCP

. If no external stop function is selected

and the [Off] key is inactive the motor can only be stopped by disconnecting the line power supply.

[Auto on]

enables the adjustable frequency drive to be controlled via the control terminals and/or serial communication. When a start signal is applied on the control

terminals and/or the bus, the adjustable frequency drive will start. The key can be selected as Enable [1] or Disable [0] via par.0-42

[Auto on] Key on

LCP

NOTE!

An active HAND-OFF-AUTO signal via the digital inputs has higher priority than the control keys [Hand on] – [Auto on].

[Reset]

is used for resetting the adjustable frequency drive after an alarm (trip). It can be selected as

Enable

[1] or

Disable

[0] via par.0-43

[Reset] Key on

LCP

The parameter shortcut can be carried out by holding down the [Main Menu] key for 3 seconds. The parameter shortcut allows direct access to any

parameter.

2.1.2 How to operate numeric LCP (NLCP)

The following instructions are valid for the NLCP (LCP 101).

The control panel is divided into four functional groups:

1. Numeric display.

2. Menu key and indicator lights (LEDs) - changing parameters and

switching between display functions.

3. Navigation keys and indicator lights (LEDs).

4. Operation keys and indicator lights (LEDs).

NOTE!

Parameter copy is not possible with Numeric Local

Control Panel (LCP101).

Select one of the following modes:

Status Mode: Displays the status of the adjustable frequency drive or

the motor.

If an alarm occurs, the NLCP automatically switches to status mode.

A number of alarms can be displayed.

Quick Set-up or Main Menu Mode: Display parameters and parameter

settings.

Figure 2.1: Numerical LCP (NLCP)

130BP077.10

Figure 2.2: Status display example

2 How to Program VLT

HVAC Drive Programming Guide

2-6

MG.11.C6.22 - VLT®is a registered Danfoss trademark

Table des matières

Autres manuels Danfoss Entraînement CC

Danfoss

Danfoss FC 300 Manuel utilisateur

Danfoss

Danfoss VLT FC Series Manuel utilisateur

Danfoss

Danfoss vlt aqua Manuel utilisateur

Danfoss

Danfoss VLT MCA121 Mode d’emploi

Danfoss

Danfoss VLT FC 103 Manuel utilisateur

Danfoss

Danfoss FC 300 Mode d’emploi

Danfoss

Danfoss vlt aqua Mode d’emploi

Danfoss

Danfoss VLT Midi Drive FC 280 Mode d'emploi

Danfoss

Danfoss VLT OneGearDrive Manuel utilisateur

Danfoss

Danfoss VLT Brake Resistor MCE 101 Mode d’emploi

Danfoss

Danfoss VLT DriveMotor FCP 106 Manuel utilisateur

Danfoss

Danfoss VLT AQUA Drive FC 202 Mode d’emploi

Danfoss

Danfoss AME 438 SU Manuel utilisateur

Danfoss

Danfoss VLT series Manuel utilisateur

Danfoss

Danfoss VLT HVAC Basic Drive FC 101 Manuel utilisateur

Danfoss

Danfoss MCA 122 Modbus TCP Manuel utilisateur

Danfoss

Danfoss VLT HVAC Drive FC 102 Manuel utilisateur

Danfoss

Danfoss VLT PTC Thermistor Card MCB 112 Manuel utilisateur

Danfoss

Danfoss MCB 113 Manuel utilisateur

Danfoss

Danfoss FC 100 Series Mode d'emploi

Danfoss

Danfoss VLT series Manuel utilisateur

Danfoss

Danfoss VLT HVAC Drive FC 102 Manuel utilisateur

Danfoss

Danfoss VLT HVAC Drive FC 102 Manuel utilisateur

Danfoss

Danfoss VLT HVAC Drive FC 102 Manuel utilisateur

Manuels Entraînement CC populaires d'autres marques

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Manuel utilisateur

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Manuel de la liste des pièces

Chamberlain Garog

Chamberlain Garog D Series Manuel utilisateur

Parker

Parker PDS Series Manuel utilisateur

Festo

Festo DGC G Series Guide de configuration

Binks

Binks QS-5012-1-CE Manuel utilisateur

ABB

ABB ACQ580-01 Series Manuel d'installation

YASKAWA

YASKAWA CANopen SI-S3 Manuel utilisateur

GE D20A6 Manuel utilisateur

Unex

Unex MC-D-250-1000-050W-TW Manuel utilisateur

Geckodrive

Geckodrive G213V Manuel utilisateur

ABB

ABB RSYC-01 Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 700S Manuel du propriétaire

WEG

WEG DeviceNet CFW500 Manuel utilisateur

Siemens

Siemens SINAMICS G Fiche technique

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Mode d'emploi

SOMFY

SOMFY JR RU 30 Manuel utilisateur

Beckhoff

Beckhoff AX8911 Manuel de l'opérateur
