1 How to Read these Operating Instructions

Approvals 6

Symbols 6

2 Safety

General Warning 8

Before commencing repair work 8

Special conditions 8

Avoid unintended start 9

Safe Stop Installation 9

Safe Stop of the Frequency Converter 11

IT mains 12

3 How to Install

How to Get Started 13

Pre-installation 13

Planning the Installation Site 13

Receiving the Frequency Converter 14

Transportation and Unpacking 14

Lifting 15

Mechanical Dimensions 17

Rated Power 24

Mechanical Installation 25

Terminal locations - frame size D 26

Terminal Locations - frame size E 28

Terminal Locations - frame size F 32

Cooling and Airflow 34

Field Installation of Options 39

Installation of Duct Cooling Kit in Rittal Enclosures 39

Outside installation/ NEMA 3R kit for Rittal enclosures 42

Installation on pedestal 43

Input plate option 45

Installation of Mains Shield for frequency converters 46

Frame size F Panel Options 46

Electrical Installation 49

Power Connections 49

Mains connection 64

Fuses 65

VLT AQUA High Power Operation Instructions Contents

MG.20.P3.02 - VLT®is a registered Danfoss trademark

Motor Insulation 68

Motor Bearing Currents 68

Control cable routing 69

Electrical Installation, Control Terminals 70

Connection Examples 72

Start/Stop 72

Pulse Start/Stop 72

Electrical Installation - additional 74

Electrical Installation, Control Cables 74

Switches S201, S202, and S801 76

Final Set-up and Test 77

Additional Connections 79

Mechanical Brake Control 79

Motor Thermal Protection 79

4 How to operate the frequency converter

Ways of Operation 81

How to operate graphical LCP (GLCP) 81

How to operate numeric LCP (NLCP) 86

Tips and tricks 89

5 How to programme the frequency converter

How to programme 93

Q1 My Personal Menu 94

Q2 Quick Setup 94

Q5 Changes Made 96

Q6 Loggings 97

Commonly Used Parameters - Explanations 98

Main Menu 98

Parameter Options 138

Default settings 138

Operation/Display 0-** 139

Load/Motor 1-** 141

Brakes 2-** 142

Reference / Ramps 3-** 143

Limits / Warnings 4-** 144

Digital In/Out 5-** 145

Analog In/Out 6-** 146

Comm. and Options 8-** 147

Profibus 9-** 148

CAN Fieldbus 10-** 149

Smart Logic 13-** 150

Contents VLT AQUA High Power Operation Instructions

MG.20.P3.02 - VLT®is a registered Danfoss trademark

Special Functions 14-** 151

FC Information 15-** 152

Data Readouts 16-** 154

Data Readouts 2 18-** 156

FC Closed Loop 20-** 157

Ext. Closed Loop 21-** 158

Application Functions 22-** 160

Timed Actions 23-** 162

Cascade Controller 25-** 163

Analog I/O Option MCB 109 26-** 165

Cascade CTL Option 27-** 166

Water Application Functions 29-** 168

Bypass Option 31-** 169

6 General Specifications

171

7 Troubleshooting

183

Fault messages 186

Index

192

VLT AQUA High Power Operation Instructions Contents

MG.20.P3.02 - VLT®is a registered Danfoss trademark

1 How to Read these Operating Instructions VLT AQUA High Power Operation Instructions

MG.20.P3.02 - VLT®is a registered Danfoss trademark

1 How to Read these Operating Instructions

1.1.1 Copyright, Limitation of Liability and Revision Rights

This publication contains information proprietary to Danfoss. By accepting and using this manual the user agrees that the information contained herein

will be used solely for operating equipment from Danfoss or equipment from other vendors provided that such equipment is intended for communication

with Danfoss equipment over a serial communication link. This publication is protected under the Copyright laws of Denmark and most other countries.

Danfoss does not warrant that a software program produced according to the guidelines provided in this manual will function properly in every physical,

hardware or software environment.

Although Danfoss has tested and reviewed the documentation within this manual, Danfoss makes no warranty or representation, neither expressed nor

implied, with respect to this documentation, including its quality, performance, or fitness for a particular purpose.

In no event shall Danfoss be liable for direct, indirect, special, incidental, or consequential damages arising out of the use, or the inability to use information

contained in this manual, even if advised of the possibility of such damages. In particular, Danfoss is not responsible for any costs, including but not

limited to those incurred as a result of lost profits or revenue, loss or damage of equipment, loss of computer programs, loss of data, the costs to substitute

these, or any claims by third parties.

Danfoss reserves the right to revise this publication at any time and to make changes to its contents without prior notice or any obligation to notify former

or present users of such revisions or changes.

VLT AQUA High Power Operation Instructions 1 How to Read these Operating Instructions

MG.20.P3.02 - VLT®is a registered Danfoss trademark

These Operating Instructions will introduce all aspects of your VLT AQUA Drive.

Available literature for VLT AQUA Drive:

-Operating Instructions MG.20.MX.YY provide the neccessary information for getting the drive up and running.

-Design Guide MG.20.NX.YY entails technical information about the drive design and customer applications.

-Programming Guide MG.20.OX.YY provides information on how to programme and includes complete parameter descriptions.

X = Revision number

YY = Language code

Danfoss Drives technical literature is also available online at www.danfoss.com/BusinessAreas/DrivesSolutions/Documentations/Technical+Documenta-

tion.

1.1.2 Approvals

1.1.3 Symbols

Symbols used in these Operating Instructions.

NB!

Indicates something to be noted by the reader.

Indicates a general warning.

Indicates a high-voltage warning.

*Indicates default setting

1 How to Read these Operating Instructions VLT AQUA High Power Operation Instructions

MG.20.P3.02 - VLT®is a registered Danfoss trademark

2Safety

2.1.1 Safety note

The voltage of the frequency converter is dangerous whenever connected to mains. Incorrect installation of the motor, frequency

converter or fieldbus may cause damage to the equipment, serious personal injury or death. Consequently, the instructions in this

manual, as well as national and local rules and safety regulations, must be complied with.

Safety Regulations

1. The frequency converter must be disconnected from mains if repair work is to be carried out. Check that the mains supply has been disconnected

and that the necessary time has passed before removing motor and mains plugs.

2. The [STOP/RESET] key on the control panel of the frequency converter does not disconnect the equipment from mains and is thus not to be

used as a safety switch.

3. Correct protective earthing of the equipment must be established, the user must be protected against supply voltage, and the motor must be

protected against overload in accordance with applicable national and local regulations.

4. The earth leakage currents are higher than 3.5 mA.

5. Protection against motor overload is set by par. 1-90

Motor Thermal Protection

. If this function is desired, set par. 1-90 to data value [ETR trip]

(default value) or data value [ETR warning]. Note: The function is initialised at 1.16 x rated motor current and rated motor frequency. For the

North American market: The ETR functions provide class 20 motor overload protection in accordance with NEC.

6. Do not remove the plugs for the motor and mains supply while the frequency converter is connected to mains. Check that the mains supply has

been disconnected and that the necessary time has passed before removing motor and mains plugs.

7. Please note that the frequency converter has voltage inputs other than L1, L2 and L3, when load sharing (linking of DC intermediate circuit) and

external 24 V DC have been installed. Check that all voltage inputs have been disconnected and that the necessary time has passed before

commencing repair work.

Installation at High Altitudes

Installation at high altitude:

380 - 480 V: At altitudes above 3 km, please contact Danfoss Drives regarding PELV.

525 - 690 V: At altitudes above 2 km, please contact Danfoss Drives regarding PELV.

Warning against Unintended Start

1. The motor can be brought to a stop by means of digital commands, bus commands, references or a local stop, while the frequency converter is

connected to mains. If personal safety considerations make it necessary to ensure that no unintended start occurs, these stop functions are not sufficient.

2. While parameters are being changed, the motor may start. Consequently, the stop key [STOP/RESET] must always be activated; following which data

can be modified. 3. A motor that has been stopped may start if faults occur in the electronics of the frequency converter, or if a temporary overload or

a fault in the supply mains or the motor connection ceases.

Warning:

Touching the electrical parts may be fatal - even after the equipment has been disconnected from mains.

Also make sure that other voltage inputs have been disconnected, such as external 24 V DC, load sharing (linkage of DC intermediate circuit), as well as

the motor connection for kinetic back up.

VLT AQUA High Power Operation Instructions 2 Safety

MG.20.P3.02 - VLT®is a registered Danfoss trademark

2.1.2 General Warning

Warning:

Touching the electrical parts may be fatal - even after the equipment has been disconnected from mains.

Also make sure that other voltage inputs have been disconnected, (linkage of DC intermediate circuit), as well as the motor connection

for kinetic back-up.

Before touching any potentially live parts of the frequency converter, wait at least as follows:

380 - 480 V, 110 - 250 kW, wait at least 20 minutes.

380 - 480 V, 315- 1000 kW, wait at least 40 minutes.

525 - 690 V, 45 - 400 kW, wait at least 20 minutes.

525 - 690 V, 450 - 1200 kW, wait at least 30 minutes.

Shorter time is allowed only if indicated on the nameplate for the specific unit.

Leakage Current

The earth leakage current from the frequency converter exceeds 3.5 mA. According to IEC 61800-5-1 a reinforced Protective Earth

connection must be ensured by means of: a min. 10mm² Cu or 16mm² Al PE-wire or an addtional PE wire - with the same cable cross

section as the Mains wiring - must be terminated separately.

Residual Current Device

This product can cause a D.C. current in the protective conductor. Where a residual current device (RCD) is used for extra protection,

only an RCD of Type B (time delayed) shall be used on the supply side of this product. See also RCD Application Note MN.90.GX.02.

Protective earthing of the frequency converter and the use of RCD's must always follow national and local regulations.

2.1.3 Before commencing repair work

1. Disconnect the frequency converter from mains

2. Disconnect DC bus terminals 88 and 89

3. Wait at least the time mentioned in section General Warning above

4. Remove motor cable

2.1.4 Special conditions

Electrical ratings:

The rating indicated on the nameplate of the frequency converter is based on a typical 3-phase mains power supply, within the specified voltage, current

and temperature range, which is expected to be used in most applications.

The frequency converters also support other special applications,which affect the electrical ratings of the frequency converter. Special

conditions which affect the electrical ratings might be:

• Single phase applications

• High temperature applications which require derating of the electrical ratings

• Marine applications with more severe environmental conditions.

Consult the relevant clauses in these instructions and in the VLT®AQUA Drive Design Guide for information about the electrical ratings.

Installation requirements:

The overall electrical safety of the frequency converter requires special installation considerations regarding:

• Fuses and circuit breakers for over-current and short-circuit protection

• Selection of power cables (mains, motor, brake, loadsharing and relay)

• Grid configuration (IT,TN, grounded leg, etc.)

• Safety of low-voltage ports (PELV conditions).

Consult the relevant clauses in these instructions and in the VLT®AQUA Drive Design Guide for information about the installation requirements.

2 Safety VLT AQUA High Power Operation Instructions

MG.20.P3.02 - VLT®is a registered Danfoss trademark

2.1.5 Caution

The frequency converter's DC link capacitors remain charged after power has been disconnected. To avoid an electrical shock hazard,

disconnect the frequency converter from the mains before carrying out maintenance. Before doing service on the frequency converter,

wait at least the amount of time indicated below:

Voltage Power size Min. Waiting Time

380 - 480 V 110 - 250 kW 20 minutes

315 - 1000 kW 40 minutes

525 - 690 V 45 - 400 kW 20 minutes

450- 1200 kW 30 minutes

Be aware that there may be high voltage on the DC link even when the LEDs are turned off.

2.1.6 Avoid unintended start

While the frequency converter is connected to mains, the motor can be started/stopped using digital commands, bus commands,

references or via the Local Control Panel.

• Disconnect the frequency converter from mains whenever personal safety considerations make it necessary to avoid unintended start.

• To avoid unintended start, always activate the [OFF] key before changing parameters.

• Unless terminal 37 is turned off, an electronic fault, temporary overload, a fault in the mains supply, or lost motor connection may cause a

stopped motor to start.

2.1.7 Safe Stop Installation

To carry out an installation of a Category 0 Stop (EN60204) in

conformity with Safety Category 3 (EN954-1), follow these in-

structions:

1. The bridge (jumper) between Terminal 37 and 24 V DC must be

removed. Cutting or breaking the jumper is not sufficient. Re-

move it entirely to avoid short-circuiting. See jumper on illus-

tration.

2. Connect terminal 37 to 24 V DC by a short-circuit protected ca-

ble. The 24 V DC voltage supply must be interruptible by an

EN954-1 Category 3 circuit interrupt device. If the interrupt de-

vice and the frequency converter are placed in the same instal-

lation panel, you can use an unscreened cable instead of a

screened one. Illustration 2.1: Bridge jumper between terminal 37 and 24

VDC

The illustration below shows a Stopping Category 0 (EN 60204-1) with safety Category 3 (EN 954-1). The circuit interrupt is caused by an opening door

contact. The illustration also shows how to connect a non-safety related hardware coast.

VLT AQUA High Power Operation Instructions 2 Safety

MG.20.P3.02 - VLT®is a registered Danfoss trademark

Illustration 2.2: Illustration of the essential aspects of an installation to achieve a Stopping Category 0 (EN 60204-1) with safety Category

3 (EN 954-1).

2 Safety VLT AQUA High Power Operation Instructions

MG.20.P3.02 - VLT®is a registered Danfoss trademark

Autres manuels pour vlt aqua

Table des matières

Autres manuels Danfoss Entraînement CC

Danfoss

Danfoss VLT AutomationDrive FC 300 Mode d’emploi

Danfoss

Danfoss VLT DriveMotor FCM 106 Mode d’emploi

Danfoss

Danfoss VLT AutomationDrive FC 360 Manuel utilisateur

Danfoss

Danfoss VLT HVACDrive Manuel utilisateur

Danfoss

Danfoss VLT FC Series Manuel utilisateur

Danfoss

Danfoss AME 685 Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 360 Manuel utilisateur

Danfoss

Danfoss VLT Mode d’emploi

Danfoss

Danfoss VLT AutomationDrive FC 300 Mode d’emploi

Danfoss

Danfoss VLT AutomationDrive FC 300 Manuel utilisateur

Danfoss

Danfoss VLT HVAC Drive Metasys N2 Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 360 Mode d’emploi

Danfoss

Danfoss VACON 100 industrial Manuel utilisateur

Danfoss

Danfoss VLT Active Front End AFE 302 Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 300 Manuel utilisateur

Danfoss

Danfoss VLT series Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 301 Mode d'emploi

Danfoss

Danfoss VLT FC 360 Mode d’emploi

Danfoss

Danfoss VLT AutomationDrive FC 300 Manuel utilisateur

Danfoss

Danfoss VLT 2800 Manuel utilisateur

Danfoss

Danfoss VLT Micro Drive FC 51 Series Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 302 Mode d'emploi

Danfoss

Danfoss VLT Micro Drive FC 51 Series Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 301 Manuel utilisateur

Manuels Entraînement CC populaires d'autres marques

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Manuel utilisateur

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Manuel de la liste des pièces

Chamberlain Garog

Chamberlain Garog D Series Manuel utilisateur

Parker

Parker PDS Series Manuel utilisateur

Festo

Festo DGC G Series Guide de configuration

Binks

Binks QS-5012-1-CE Manuel utilisateur

ABB

ABB ACQ580-01 Series Manuel d'installation

YASKAWA

YASKAWA CANopen SI-S3 Manuel utilisateur

GE D20A6 Manuel utilisateur

Unex

Unex MC-D-250-1000-050W-TW Manuel utilisateur

Geckodrive

Geckodrive G213V Manuel utilisateur

ABB

ABB RSYC-01 Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 700S Manuel du propriétaire

WEG

WEG DeviceNet CFW500 Manuel utilisateur

Siemens

Siemens SINAMICS G Fiche technique

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Mode d'emploi

SOMFY

SOMFY JR RU 30 Manuel utilisateur

Beckhoff

Beckhoff AX8911 Manuel de l'opérateur

Danfoss vlt aqua Manuel utilisateur

Manuels Entraînement CC populaires d'autres marques
