Danfoss VLT Soft Starter MCD 600 Manuel utilisateur

Installation Guide

DeviceNet Card

VLT® Soft Starter MCD 600

Contents

1 Safety 4

1.1 Disclaimer 4

1.2 Warnings 4

1.3 Important User Information 4

2 Installation 5

2.1 Installing the Expansion Card 5

2.2 Connecting to the Network 5

2.3 Feedback LEDs 6

2.3.1 Module and Network LEDs 6

3 Configuration 8

3.1 Preparations 8

3.2 DeviceNet Network Settings 8

3.3 Enabling Network Control 8

3.4 DeviceNet Polled I/O Structure 8

3.4.1 Output and Input Data 9

4 Troubleshooting 12

4.1 Trip Codes 12

5 Parameter Handling 14

5.1 Parameter Object 14

6 Specifications 15

6.1 Connections 15

6.2 Settings 15

6.3 Power 15

6.4 Certification 15

Contents

Installation Guide | DeviceNet Card

1 Safety

1.1 Disclaimer

The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is

subject to change at any time and without prior notice. Responsibility or liability is never accepted for direct, indirect, or consequential

damage resulting from the use or application of this equipment.

1.2 Warnings

WARNING

SHOCK HAZARD

Attaching or removing accessories while the soft starter is connected to mains voltage may cause personal injury.

-Before attaching or removing accessories, isolate the soft starter from mains voltage.

WARNING

RISK OF PERSONAL INJURY AND EQUIPMENT DAMAGE

Inserting foreign objects or touching the inside of the soft starter while the expansion port cover is open may endanger

personnel and can damage the soft starter.

-Do not insert foreign objects in the soft starter with the port cover open.

-Do not touch the inside of the soft starter with the port cover open.

1.3 Important User Information

Observe all necessary safety precautions when controlling the soft starter remotely. Alert personnel that machinery may start without

warning.

The installer is responsible for following all instructions in this manual and for following correct electrical practice.

Use all internationally recognized standard practice for RS485 communication when installing and using this equipment.

Safety

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182

2 Installation

2.1 Installing the Expansion Card

Procedure

1. Push a small flat-bladed screwdriver into the slot in the center of the expansion port cover and ease the cover away from the soft

starter.

2. Line up the card with the expansion port.

3. Gently push the card along the guide rails until it clicks into the soft starter.

Example:

1 2

e77ha739.10

Illustration 1: Installation of the Expansion Cards

2.2 Connecting to the Network

Prerequisites:

The expansion card must be installed in the soft starter.

Procedure

1. Connect field wiring via the 5-way connector plug.

The DeviceNet card is powered via the connector.

Installation

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182 | 5

Example:

35 4 2 1

e77ha741.10

Illustration 2: 5-way Connector Plug

Pin Function

5 V+

4 CAN_H

3 SHIELD

2 CAN_L

1 V-

NOTICE

Network designs must decrease the maximum allowable cumulative dropline length for every device installed on the network.

Failure to do so may result in network communication errors and decreased reliability.

-Decrease the maximum allowable cumulative dropline by 400 mm per device in the network.

Example:

ODVA specifies a maximum cumulative dropline length of 156 m on a network operating at 125 kb/s. If 6 devices were installed on this

network, the total dropline length would need to be decreased to 153.6 m.

2.3 Feedback LEDs

2.3.1 Module and Network LEDs

The Module LED indicates the condition of the power supply and device operation.

The Network LED indicates the status of the communication link between the device and the network Master.

Installation

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182

Table 1: LED Descriptions

LED name LED status Description

Module Off Network power off

Green Normal operation

Red Unrecoverable fault

Red/green flashing Self-test mode

Network Off Duplicate MAC ID test has not been completed

Green flashing Online, but no connection with Master

Green Online and allocated to a Master

Red flashing One or more timed-out I/O connections

Red Failed communication between device and Master

Red/green flashing Communication failed and received an Identity communication failed request.

Installation

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182 | 7

3 Configuration

3.1 Preparations

The DeviceNet Card is a Group 2 slave device using a predefined master/slave connection set. I/O data is produced and consumed

using polled I/O messaging.

Add the soft starter to the DeviceNet manager project via the EDS file and configuration/management software tool. To operate

successfully, use the correct EDS file. An on-screen graphics bitmap file (device.bmp) is also available. The files can be downloaded

from www.danfoss.com/en/service-and-support/downloads/dds/fieldbus-configuration-files/#tab-downloads. Contact the local

supplier for further information.

3.2 DeviceNet Network Settings

Set the network communication parameters for the card via the soft starter. For details on how to configure the soft starter, see the

VLT® Soft Starter MCD 600 Operating Guide.

Parameter Description

12-5 Devicenet Address Sets the DeviceNet network address for the soft starter.

12-6 Devicenet Baud Rate Selects the baud rate for DeviceNet communications.

3.3 Enabling Network Control

The soft starter only accepts commands from the expansion card if parameter 1-1 Command Source is set to Network.

NOTICE

If the reset input is active, the soft starter does not operate. If a reset switch is not required, fit a link across terminals RESET,

COM+ on the soft starter.

3.4 DeviceNet Polled I/O Structure

Once the EDS file has been loaded, add the device to the scanner list with the following parameters:

Parameter Value

I/O connection type Polled

Poll receive size 14 bytes

Poll transmit size 2 bytes

Once the soft starter, device, and Master have been set up, configured, and powered up, the Master transmits 2 bytes of data to the

device and receives 14 bytes of data from the device.

Configuration

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182

3.4.1 Output and Input Data

Table 2: Master/Slave Polled I/O Output Data Structure

Byte Bit Function

0 0 0=Stop command

1=Start command

1 0=Enable start or stop command

1=Quick stop (coast to stop) and disable start command

2 0=Enable start or stop command

1=Reset command and disable start command

3–7 Reserved

1 0–1 0=Use soft starter remote input to select motor set

1=Use primary motor set when starting

2=Use secondary motor set when starting

3=Reserved

2–7 Reserved

Table 3: Master/Slave Polled I/O Input Data Structure

Byte Bit Function Value

0 0 Trip 1=Tripped

1 Warning 1=Warning

2 Running 0=Unknown, Not ready, Ready to start, or Tripped

1=Starting, Running, Stopping, or Jogging

3 Reserved

4 Ready 0=Start or stop command not acceptable

1=Start or stop command acceptable

5 Operating mode 0=Programming mode

1=Operating mode

6 Command source 0=Remote LCP, Digital input, Clock

1=Network

7 At reference 1=Running

Configuration

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182 | 9

Byte Bit Function Value

1 0–7 Status 0=Unknown (menu open)

2=Not ready (restart delay, restart temperature check, run simulation, reset input is

open)

3=Ready to start (including warning state)

4=Starting or running

5=Stopping

7=Tripped

8=Jog forward

9=Jog reverse

2 0–7 Trip/warning code See 4.1 Trip Codes

3 0 Initialized 1=Phase sequence bit is valid (bit 1) after 1st start

1 Phase sequence 1=Positive phase sequence

2–7 Reserved

4(1) 0–7 Motor current (low byte) Current [A]

5(1) 0–7 Motor current (high byte)

6 0–7 Current %FLC (low byte) Current as percentage of soft starter FLC setting (%)

7 0–7 Current %FLC (high byte)

8 0–7 % Motor temperature Motor thermal model (%)

9 0–7 Reserved

10 0–7 %Power factor Percentage of power factor (100%=power factor of 1)

11 0–7 Power (low byte) Power low byte, scaled by power scale

12 0–3 Power (high nibble) Power high nibble, scaled by power scale

4–5 Power scale 0=Multiply power by 10 to get W

1=Multiply power by 100 to get W

2=Power (kW)

3=Multiply power by 10 to get kW

6–7 Reserved

Configuration

Installation Guide | DeviceNet Card

AQ277154750780en-000102 / 175R1182
