Dalsa Spyder3 GigE Manuel utilisateur

Spyder3 GigE Quick Start Guide

03-32-10182-03

For additional information about the DALSA QuickCam application or for Product Support,

Address 605 McMurray Road, Waterloo, Ontario, Canada N2V 2E9

Voice Worldwide (519) 886-6000

Europe +49.8142.46770

Asia Pacific +813.5960.6353

Fax (519) 886-2230

E-mail Product Support ([email protected])

Worldwide Sales (sale[email protected])

European Sales ([email protected])

Asia Pacific Sales ([email protected])

Where to Find More Information

•To view the QuickCam documentation, including a user’s manual, a driver

manual and SDK documentation, point to Programs—DALSA QuickCam—

Documentation.

•The QuickCam GUI provides context sensitive help on all dialog boxes, providing

descriptions of specific fields as well as conceptual information related to those

fields.

For context sensitive help, place your cursor in the field where you want more

help and press F1.

Click the Help button on the tab in QuickCam where you want more information.

•For the complete Help, select Help—QuickCam Help on the QuickCam menu

bar. You can find topics from the Help by using the table of contents and search

tool.

Welcome to the Spyder3 GigE camera and DALSA QuickCam Quick Start

Guide. With the QuickCam application, you can begin imaging with your

Spyder3 GigE camera quickly and easily.

Before you begin, ensure that you have:

1. Camera power cable.

2. Cat 5 or Cat 6 Ethernet cables.

3. Intel PRO/1000 Ethernet card. Other gigabit Ethernet cards can be used but cause

slower data transmission.

4. A computer with the following minimum requirements:

•Processor: AMD Athlon XP 2000+ or Intel 2.0 GHz

•Memory: 512 MB DDR RAM PC2700

•Motherboard: Mid-end without embedded graphic card

•VGA card: Nvidia GForce 2 or better (ATI not recommended)

•Operating System: Windows 2000 (SP4) or Windows XP

5. Other necessary components of your system, including light sources, camera

mounts, lenses, encoders, etc.

1. the

Driver Installation Tool

Tools Launch Driver Installation Tool

2. If you are using an :

a) On the tab, right click on an Intel PRO/1000 network

interface card adapter with no installed driver (i.e. when the Device Class is

Ethernet Controller).

The following context menu appears:

b) Choose to install the QuickCam

High Performance IP Device Driver.

If you are using an :

a) On the tab, click, This button

installs the QuickCam Universal IP Filter Driver on ALL network adapters

installed on the system that are using a network driver. This excludes

PRO/1000 adapters on which the QuickCam High Performance Driver has

been installed.

Programs—DALSA QuickCam— —

Intel PRO/1000 adapter

Pro 1000 Adapters

Install High Performance IP Device Driver

NOT Intel PRO/1000 adapter

Universal IP Filter Driver Install Filter Driver…

Open . Start

On the Windows task bar click , point to

Install QuickCam driver.

Connect Ethernet cable.

Connect Cat 5 or Cat 6 cable from camera

to computer Ethernet jack.

Connect power cable.

Connect power cable from camera to +12

V to +15 V power supply.

Connect GPIO connector.

If using an external sync, external direction

control or any other external signals,

connect the GPIO.

Open QuickCam.

Start

Programs—DALSA

QuickCam—DALSA QuickCam

On the Windows task bar click , point

Camera auto-detection.

Wait while QuickCam automatically detects

your camera.

Start acquiring images.

Continuous Grab

On the QuickCam toolbar, click the

icon. The image should

be visible in the Image Output window.

Spyder3 GigE Quick Set-Up Instructions

Install QuickCam GUI.

Spyder3 GigE CDInsert the into your CD-

ROM and follow the online instructions to

install the QuickCam GUI.

Install Ethernet card.

Following the manufacturer’s instructions,

install an Ethernet card. For Gigabit

performance,you must install an Intel

PRO/1000 Ethernet card.

You will install the appropriate

QuickCam driver in step 3.

Do not install the manufacturer’s

driver.
