System Precautions

Precautions

Read these precautions and this manual carefully before using the camera.

Confirm that the camera’s packaging is undamaged before opening it. If the packaging is

damaged, please contact the relevant logistics personnel.

Do not open the housing of the camera. The warranty is voided if the housing is opened.

Keep the camera housing temperature in a range of 0 °C to +60 °C during operation.

Do not operate the camera near strong electromagnetic fields. In addition, avoid

electrostatic charging, violent vibration, and excess moisture.

To clean the device, avoid electrostatic charging by using a dry, clean absorbent cotton

cloth dampened with a small quantity of pure alcohol. Do not use methylated alcohol. To

clean the surface of the camera housing, use a soft, dry cloth. To remove severe stains, use

a soft cloth dampened with a small quantity of neutral detergent and then wipe dry. Do not

use volatile solvents such as benzene and thinners, as they can damage the surface finish.

Further cleaning instructions are below.

Though this camera supports hot plugging, it is recommended that you power down and

disconnect power to the camera before you add or replace system components.

Electrostatic discharge and the CMOS sensor

Image sensors and the camera bodies housing are susceptible to damage from electrostatic

discharge (ESD). Electrostatic charge introduced to the sensor window surface can induce

charge buildup on the underside of the window that cannot be readily dissipated by the dry

nitrogen gas in the sensor package cavity. The charge normally dissipates within 24 hours

and the sensor returns to normal operation.

The Piranha4 Color Camera

Camera Highlights

Based on Teledyne e2V’s unique CMOS color line scan sensor architecture, the Piranha4™

8k trilinear color cameras provide outstanding signal-to-noise performance for high speed

imaging.

The Piranha4 8k model has 8k resolution with a 7.5 µm x 7.5 µm pixel size for optimized

optical design. The cameras deliver a maximum line rate of 33 kHz.

Precise sensor alignment simplifies multiple camera calibration at the system level.

GenICam™ or ASCII command-compliant interfaces make the camera easier to setup,

control, and integrate. Programmable features include exposure control, flat field correction,

and gain settings. The Piranha4 camera is ideal for the inspection of printing, printed circuit

board, solar cell, film, and large format webs.

Key Features

CMOS trilinear color line scan sensor

8k pixel resolution

3 x 8192 RGB 7.5 µm x 7.5 µm pixels

Line rates up to 33 kHz x 3

24-bits RGB

Programmability

Camera Link interface

GenICam or ASCII command-compliant interfaces

Scan direction

Flat-field correction

Parallax correction

Spatial correction

White balance

Color correction matrix

Applications

Print and paper inspection

PCB inspection

Raw material surface inspection

Parcel and postal sorting

High resolution document scanning

Industrial Inspection

Camera Models

The camera is available in the following configurations:

Table 1: Camera Models Overview

Model Number

Description

P4-CC-08K03T-01-R

8k resolution, 33 kHz line rate, 7.5 µm x 7.5 µm pixel size, trilinear RGB

Table 2: Software

Software

Product Number / Version Number

Camera firmware

Embedded within camera

GenICam™ support (XML camera description file)

Embedded within camera

Sapera LT, including CamExpert GUI application and GenICam for

Camera Link imaging driver

Version 7.2 or later

Table 3: Frame Grabbers

Brand

Model

Teledyne DALSA

Xtium CL MX4

Other compatible frame grabbers may be available from third-party vendors.

Camera Performance Specifications

Table 4: Camera Performance Specifications

Characteristics

Typical Value

Unit

Sensor Characteristics at Maximum Pixel Rate

Resolution

8192 x 3

RGB Pixels

Pixel size (square)

7.5 x 7.5

µm

Line rate, maximum

33 x 3

kHz

Radiometric Performance at Maximum Pixel Rate and Minimum Camera Gain

Bit depth

3 x 8

Bits

Response non linearity

< 1

PRNU HF Max

0.5

Dynamic range

Peak Response (All Modes)

Blue (Peak at 460 nm)

DN 8-bits/(nJ/cm²)

Green (Peak at 540 nm)

9.5

DN 8-bits/(nJ/cm²)

Red (Peak at 640 nm)

DN 8-bits/(nJ/cm²)

Test conditions:

All values are given at Nominal Gain (0 dB) : Preamp Gain x1, Amp Gain 0 dB

Figures in DN are for a 8-bits format

Measured at exposure time = 200 µs and line period = 200 µs in Ext Trig Mode (Max Exposure Time)

Maximum data rate

Camera Characterization

Unit

Typ.

Max

Dark Noise RMS

LSB10bits

1.68

2.5

Dynamic Range

RMS Noise (3/4 Sat)

LSB10bits

2.27

Full Well Capacity

e- (per color)

13650

SNR (3/4 Sat)

Peak Response

DN 8-bits/(nJ/cm²)

12 (R), 9.5 (G), 7 (B)

Non Linearity

0,3

Without Flat Field Correction

FPN rms

DN10bits

0.9

FPN pk-pk

DN10bits

PRNU hf (3/4 Sat)

0.1

PRNU pk-pk (3/4 Sat)

0.7

Environmental Specifications

Storage temperature range

-20 °C to +80 °C

Humidity (storage and operation)

15% to 85% relative, non-condensing

MTBF (mean time between failures)

>100,000 hours, typical field operation

Functionality (Programmable via GenICam Control Interface)

Analog Gain

Up to 12 (x1 to x4)

Offset (Black Level)

-256 to +256

DN 8-bits

Trigger Mode

Internal and External Triggered (Timed or Full Exposure)

Mechanical and Electrical Interface

Size (w x h x l)

80 x 80 x 40.1

Weight

295

Lens Mounts

M72 x 0.75 embedded in the Front Face

Sensor alignment

±150 (X/Y) ±100 (Z)

µm

Sensor flatness

< 50

µm

Power supply

+12 to +24

Power dissipation

< 6.5

General Features

Operating temperature (front face)

0 to 60

°C

Storage temperature

-40 to 70

°C

Certifications

Table 5: Camera Certification & Compliance

Compliance

Refer to the section EC & FCC Declaration.

Flash Memory Size

Table 6: Camera Flash Memory Specifications

Flash Memory Size

32 MBytes

Supported Industry Standards

GenICam™

The camera is GenICam compliant and implements a superset of the GenICam Standard

Features Naming Convention specification V1.5.

This description takes the form of an XML device description file using the syntax defined by

the GenApi module of the GenICam specification. The camera uses the GenICam Generic

Control Protocol (GenCP V1.0) to communicate over the Camera Link HS command lane.

For more information see www.genicam.org.

Sensor Responsivity and QE

Spectral Responsivity

The responsivity graph illustrates the sensor’s response to different wavelengths of light

(excluding lens and light source characteristics).

Note: The responsivity of a color camera will measure approximately 1/6th that of a similar

monochrome camera model as a result of the effect the color filter has on the sensor and

also due to the color camera not incorporating TDI Mode.

Autres manuels pour Piranha4 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dalsa Caméra de sécurité

Dalsa

Dalsa Piranha XL PX-HM-16K12B-00-R Manuel utilisateur

Dalsa

Dalsa Spyder3 S3-14-01k40-00-R Manuel utilisateur

Dalsa

Dalsa Spyder2 S2-1-40 Series Manuel utilisateur

Dalsa

Dalsa Pantera TF 11M4 Manuel utilisateur

Dalsa

Dalsa Piranha 2 Series Manuel utilisateur

Dalsa

Dalsa Spyder 3 GigE SG-10-01k80-00-R Manuel utilisateur

Dalsa

Dalsa 1M28-SA Manuel utilisateur

Dalsa

Dalsa P-2 Series Manuel utilisateur

Dalsa

Dalsa Spyder2 S2-1-40 Series Manuel utilisateur

Dalsa

Dalsa Piranha3 Manuel utilisateur

Dalsa

Dalsa PC-30-02K80-R Manuel utilisateur

Dalsa

Dalsa 1M75-SA Manuel utilisateur

Dalsa

Dalsa Piranha 3 Series Manuel utilisateur

Dalsa

Dalsa Genie M640 Manuel utilisateur

Dalsa

Dalsa Piranha HN HN-80-08k40-R Manuel utilisateur

Dalsa

Dalsa GiGE Vision Spyder3 SG-14 Manuel utilisateur

Dalsa

Dalsa Genie Color C640 Manuel utilisateur

Dalsa

Dalsa Piranha HS Series Manuel utilisateur

Dalsa

Dalsa MotionVision CA-D6-0256W-ECEW Manuel utilisateur

Dalsa

Dalsa Piranha XL XDR PX-HM-16K06X-00-R Manuel utilisateur

Dalsa

Dalsa Stop Action 4M30 Manuel utilisateur

Dalsa

Dalsa DALSTAR 4M30 Manuel utilisateur

Dalsa

Dalsa Spyder3 GigE Manuel utilisateur

Dalsa

Dalsa Genie Nano Series Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
